Important
CoaXPress LEDs
The four CoaXPress LEDs on the main bracket identify the state and activity of
connected devices.
The typical sequence of LED states is as follows:
If PoCXP is disabled
Alternating red/orange,
slow flash
If the device is
non-PoCXP
compliant
Orange, fast flash
Green, slow flash
If the sequence of LED states on your Matrox Radient eV-CXP is different from
this sequence, there could be a problem with your device or with data transfer.
Please refer to the CoaXPress LEDs section in Appendix B: Technical information
for the complete list of possible LED states.
Orange, solid Matrox Radient eV-CXP is booting.
If PoCXP is enabled
Red, slow flash
If the device is
PoCXP-compliant
Green, fast flash
Connection established.
No data is being transferred.
Data is being transferred.
Green, solid
Matrox Radient eV-CXP is
sensing for a PoCXP-
compliant device.
Matrox Radient eV-CXP is sending
power to the device, and is trying
to establish a connection.
