INSTALLING THE CLOSED POSITION STOP PLATE / PULL-TO-OPEN

Your Property
Step 1
● Remove the operator from the
gate post and gate brackets.
● With the gate fully open, install
the closed position stop plate
(hardware not included).
● Do not fully tighten hardware
until after the next step.
Step 2
● Swing the gate to the closed
position, and adjust the closed
position stop plate against the
fence post.
H ● Tighten the mounting hardware.
● Return the gate to the open
position and reinstall the operator
arm.
● To complete the pull-to-open
installation, proceed to
Note: For MM372W installations, the closed position stop plate should be installed on the leading edge of the PRIMARY gate leaf,
and adjusted to close against the leading edge of the SECONDARY gate leaf.
page 14.
H
1
MM371W / MM372W Installation Instructions
1
Fence Post: MM371W
Leading Edge of
Second Gate: MM372W
7
