Step 1
● Assemble the gate post bracket subassembly
as shown with the Push-to-Open pivot bracket
(FM148). Must be purchased separate.
Step 2
● Attach the gate post bracket subassembly and
G
gate bracket to the operator as shown.
11"
V
8
MM371W / MM372W Installation Instructions

PUSH-TO-OPEN OPERATOR MOUNTING

Push-to-Open pivot
bracket (FM148)
G
O
11"
G
L
V
T
S
B
F
N
N
