6.1. Output OUT 1: RCA standard
Rear View
Top View
Rear Panel
6. OUTPUTS
2 Mounting Size M3 x 8 cross slot,
Screws Phillips Nr 1 screwdriver
Upper Pair: Regulated RCA-Outputs.
Connecting
Lower Pair: Fix Level Line-RCA-Outputs.
Field
Right Channel: red; Left Channel: white
2 Mounting
see above
Screws
Pin Con-
nector for
Screw Ter-
minal 4
