5.6. Input IN 6: MC Step Up Transformer Switchable Impedance
Rear View
Top View
5. INPUTS
Size M3 x 8 cross slot,
2 Mounting Phillips Nr 1 screwdriver
Screws
Input Right - Left and Tonearm- Ground
Connecting
Connection (GND)
Field
Right Channel: red; Left Channel: white
Gain switch
see specifications IN6
2 Mounting
see above
Screws
Magnetic
shielded
Transformer
Magnetic
shielded
Transformer
The Input Modules have one less Pin than
Pin Con-
the Output Modules, therefore the Input
nector for
Modules can only be mounted in Slot 1, 2,
Screw Ter-
or 3.
minal 1,2,3
