Octave Phono Module Manual page 24

5.3. Input IN 3: MC XLR
Specifications
Sensitivity
Input Impedance
Gain Factor
Signal to Noise Ratio
Noise factor
Static Noise Level MC-XLR Input
Reading on the FIX Output
Upper Graph: Gain high
Lower graph: Gain low
THD + Noise in the Range of 400 Hz - 20 kHz
Reading on the FIX Output, Output Voltage 1 V RMS
5. INPUTS
0.1 - 1 mV
60 Ohm - 1 kOhm / 4.7 nF
68 dB / 60 dB
- 86.5 dB / -92.5 dB / 1 kHz
Bandpass Measurement

0.4 µV / Hz / Gain low

1.0 µV / Hz / Gain high
25
