Appendix
4.3 Mechanical
Outlines
4.4

Bill of Materials

4-20
4245A–USB–11/04
Figure 4-3. AT89C5131A Evaluation Board Mechanical Outlines
2.54 mm
C51 Generic Board's
Left connector
Table 4-1. Bill of Materials
Reference
C11, C12
C2
C1, C10, C14
C9, C13
C3, C4, C5, C6,
C7, C8, C15, C17,
C20, C21
C16, C19
R4, R5
R3
R15
R1, R6, R13, R19
R2
R10
R7, R8, R9
R11, R12, R14
99.06 mm
TOP
Top view
93.98 mm (37*2.54 mm)
C51 Generic Board's
Right connector
BOTTOM
Part
22 pF
2.2 nF
10 nF
100 nF
0.1 µF
10 µF
27
100
180
1K
1.5K
2.2K
4.7K
10K
AT89C5131A Starter Kit Hardware User Guide
5.08 mm
2.54 mm
