Dual Sensor (Photoelectric /
Ionisation) Smoke Alarm & Hush
Manual
Model QPI9010
Photoelectric/Ionisation (Dual Sensor) smoke alarms are designed to
detect both the visible particles (associated with slow smouldering fires)
and invisible particles (associated with fast flaming fires). Home fires
develop in different ways and are often unpredictable. For maximum
protection against fast flaming fires and slow smouldering fires, both
ionisation and photoelectric alarms should be installed.
P/N 130417
0475-7214-06 Rev03
Nov.16, 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QPI9010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Quell QPI9010

  • Page 1 Dual Sensor (Photoelectric / Ionisation) Smoke Alarm & Hush Manual Model QPI9010 Photoelectric/Ionisation (Dual Sensor) smoke alarms are designed to detect both the visible particles (associated with slow smouldering fires) and invisible particles (associated with fast flaming fires). Home fires develop in different ways and are often unpredictable.
  • Page 2: Table Of Contents

    1800 654 435 Website www.quell.com.au Introduction Website www.quell.co.nz Models QPI9010 If you have any questions about the operation or installation of your alarm, please call 1800 654 435. Figures 1A to 1C will help you determine the correct location of safety products that will help make your home a safer place.
  • Page 3 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation Instructions By law at least one smoke alarm must be installed on each level of your home (Figure 1B). Recommended Locations • In every room where someone sleeps with the door closed. The closed door may prevent an alarm located outside from waking the sleeper.
  • Page 4: Installation

    0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation DINING KITCHEN BEDROOM BEDROOM ROOM LIVING BEDROOM HALL BEDROOM ROOM BEDROOM Smoke Alarms for Minimum Protection LIVING KITCHEN ROOM Smoke Alarms for Additional Protection Ionisation Type Smoke Alarm with Alarm Silencer (Hush ) or Photoelectric Type BASEMENT ®...
  • Page 5 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation Figure 2A CEILING 30 cm (12 in) MINIMUM DO NOT INSTALL BEST PLACEMENT ACCEPTABLE PLACEMENT SIDE WALL 500mm NOT IN THIS AREA 1000mm DEAD AIR ANYWHERE IN THIS AREA DO NOT INSTALL PEAK CEILING Figure 2B 500mm NOT IN...
  • Page 6 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation Mobile Home Installation: For Well Insulated Mobile Homes Install smoke alarms as recommended on the previous pages. In mobile homes that are not well insulated extreme heat or cold can be transferred from the outside to the inside through poorly insulated walls and roof.
  • Page 7 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation To minimise nuisance alarms avoid these locations: • Do not install within 0.9m of the following: The door to a kitchen, or a bathroom that contains a tub or shower, forced air supply ducts used for heating or cooling, ceiling or whole house ventilating fans, or other high air-flow areas.
  • Page 8 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation Mounting When mounting in a hallway, the When wall “A” line should mounting, the be parallel with “A” line should the hallway. be horizontal. Alignment Marks Remove Install Figure 3 REMOVABLE CAUTION: THIS UNIT IS SEALED. THE COVER IS NOT REMOVABLE! 1.Remove the mounting plate from the back of the alarm by holding the mounting plate and twisting the alarm anti-clock-...
  • Page 9 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation 4.Battery installation instructions are provided on the inside of the battery door. To ensure proper installation of the smoke alarm battery, follow the instructions. Battery Reminder Finger Figure 4 5.When installing the battery, press the battery reminder finger down into the battery compartment and install the battery (see Figure 4).
  • Page 10 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Installation TAMPER RESIST FEATURE: To make your smoke alarm tamper resistant, a tamper resist feature has been provided. Posts FIGURE 5 To activate this feature you must break out the four tamper resist blocks on the mounting plate (see Figure 5). Use a small screw driver or pliers.
  • Page 11: Operation

    0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Operation OPERATION: The smoke alarm is operating once a fresh battery is installed and testing is complete. When products of combustion are sensed, the unit sounds a loud 85db pulsating alarm until the air is cleared. If there is any question as to the cause of the alarm, it should be assumed that the alarm is due to an actual fire and the dwelling should be evacuated immediately.
  • Page 12: Operation

    (non-recirculating type) will also help remove these combustible products from the kitchen. This model QPI9010 has a HUSH™ control that is extremely useful in areas prone to nuisance alarms. For more information refer to OPERATION AND TESTING SECTION.
  • Page 13: Maintenance

    “OFF” arrow on the cover ( see Figure 4). The Model QPI9010 Smoke Alarm is powered by a 9V alkaline battery (lithium batteries may also be used). A fresh battery should last for one year under normal operating conditions.
  • Page 14 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Maintenance Cleaning the Alarm The alarm should be cleaned at least once a year. • To clean your alarm, remove it from the mounting plate as outlined in previous sections. You can clean the alarm by using compressed air or a vacuum cleaner hose with a soft brush attachment.
  • Page 15: Fire Safety

    0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Fire Safety WARNING: PLEASE READ CAREFULLY AND THOROUGHLY • Australian Standard AS 1670.6 states the purpose of installing smoke alarms is to provide early warning of a potentially life threatening condition and provide the maximum possible exit time. •...
  • Page 16 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Fire Safety WARNING: Please read carefully and thoroughly. • Australian Standard AS 1670.6 states the purpose of installing smoke alarms is to provide early warning of a potentially life threatening condition and provide the maximum possible exit time. •...
  • Page 17 0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page Fire Safety Additional Information Smoke Detection - Where required by applicable laws, codes, or standards for the specified occupancy, approved single and multiple-station smoke alarms shall be installed as follows: • In all sleeping rooms with the exception: Smoke alarms shall not be required in sleeping rooms in existing one and two-family dwelling units.
  • Page 18: Good Safety Habits

    Chubb Fire & Security Pty Limited ABN 47 000 067 541 A UTC Climate, Controls & Security Company 149-155 Milton Street, Ashfield NSW 2131, Australia www.quell.com.au Chubb New Zealand Limited A UTC Climate, Controls & Security Company 3 Fisher Crescent, Mt Wellington, Auckland, New Zealand www.chubb.co.nz...
  • Page 19: Warranty & Contact Details

    0475-7214-06_QPI9010(130417):_ 2015.5.22 2:12 PM Page WARRANTY & CONTACT DETAILS TEN YEAR LIMITED WARRANTY Warranty Chubb warrants to the original consumer purchaser that each new smoke alarm will be free from defects in materials and workmanship under normal use for a period of 10 years from the date of purchase.
  • Page 20: Warranty & Contact Details

    Chubb Fire & Security Pty Ltd ABN 47 000 067 541 149-155 Milton Street, Ashfield NSW 2131 Australia Telephone: 1800 654 435 Website: www.quell.com.au Chubb New Zealand Limited 3 Fisher Crescent, Mt Wellington, Auckland, New Zealand Telephone: 09 270 7288 Website: www.quell.co.nz...
