MSI MS-9A95 WindBOX IV Advanced Manual page 22

Getting Started
2.5" HDD/SSD (7mm)
1. Unscrew the HDD bracket and
remove it from the system.
2. Available Upon Request:
2 optional screws are available
to secure the HDD to the bracket.
Before assembly, please make
sure the HDD/SSD is compatible
with the bracket.
To install, first insert the HDD into
the HDD bracket with screw holes
aligned. Then tighten the screws
to fix the HDD to the bracket.
Important
Please make sure the HDD is properly
and completely fixed to the bracket.
3. Align the SATA data & power connectors and connect the HDD to the
system.
2-8
