MSI MS-9A95 WindBOX IV Advanced Manual page 13

Left Panel Input/Output
■ 1 x Antenna connector
■ 1 x Line-Out jack
■ 1 x S/PDIF-Out port
■ 1 x RS232/422/485 serial port
■ 1 x RS232 serial port
■ 2 x USB 2.0 ports
■ 1 x DC power jack
■ 1 x Power switch header
■ 1 x Hard disk drive LED
■ 1 x Power button
Right Panel Input/Output
■ 2 x RJ45 LAN jacks
■ 1 x DVI-I port
■ 2 x HDMI ports / DisplayPorts (optional)
■ 4 x USB 3.0 ports
■ 1 x Antenna connector
Power Supply
■ 65 watt power adapter with active PFC
■ Input: 100-240V~, 50-60Hz, 1.5A
■ Output: 19V, 3.42A
Dimension & Weight
■ 196 mm (W) x 285 mm (D) x 29 mm (H)
■ 2.45 Kg
OS Support
■ Windows 7 (32/64-bit)
■ Windows 8.1 (64-bit)
■ Windows 10 (64-bit)
■ Fedora 25
■ Ubutnu 17.04
Regulatory Compliance
■ EMC: FCC, CE, RCM, VCCI, BSMI
■ Safety: BSMI, CB, Energy Star
Environment
■ Operating Temperature:
» -10 ~ 50 C (SSD)
o
» -10 ~ 40 C (HDD)
o
■ Storage Temperature: -20 ~ 80
■ Humidity: 10 ~ 90% RH, non-condensing
C
o
MS-9A95
1-7
