Off board spark ignition kit

Advertisement

Kit Part Number
Kit numbers vary based on boiler size. Additional differ-
ences are needed at higher altitudes. Use the table be-
low to confirm the correct replacement kit is installed
on the boiler.
Low Altitude
(0 - 5,000 ft)
PA 80
PARKIT141
PA 110
PARKIT142
PA Excellence
PARKIT142
PA 155
PARKIT143
PA 175
PARKIT144
PA 250
PARKIT145
PA 299 V2*
PARKIT146
PA 399 V2*
PARKIT147
PA 299 V1*
PARKIT148
PA 399 V1*
PARKIT149
Table 1 - Kit Numbers
*See paragraph 1.1 for more details.
1.1.
V1 and V2 PA299 and PA399 Boilers
There are two different blower/venturi arrangements
that result in two different required ignition kits. The
separate blower and venturi (V2) configuration ap-
plies to PA299s and PA399 with serial numbers after
PA11700. Units with serial numbers below PA117000
have a single piece blower venturi (V1). Some V1
models may have been converted to the V2 config-
uration as well.
Before installing the ignition kit, confirm your blow-
er/venturi configuration. See Engineering Bulletin
dated Oct. 24, 2018 for more information.
WARNING
!
Installation of the wrong replacement kit will
cause the improper operation of the boiler re-
sulting in substantial property damage, serious
injury, or death.
Revision Date: 5/16/2019
Prestige
Off Board Spark Ignition Kit
Installation Instructions
Hi Altitude
(5,000 + ft)
PARKIT151
PARKIT152
PARKIT152
PARKIT153
PARKIT154
PARKIT155
PARKIT156
PARKIT157
PARKIT158
PARKIT159
1.2.
This kit (see Fig. 1 for details) replaces the existing ignit-
er and its wiring, as well as the printed circuit board and
the front cover of the control box on all Prestige boilers .
DANGER
!
Indicates the presence of a hazardous situa-
tion which, if ignored, will result in substantial
property damage, serious injury, or death.
WARNING
!
Indicates a potentially hazardous situation
which, if ignored, can result in serious injury or
substantial property damage.
NOTICE
Indicates special instructions on installation, opera-
tion or maintenance, which are important to equip-
ment but not related to personal injury hazards.
Purpose
NOTICE
This modification disables the Alarm Relay
function which is used in several system con-
figurations. Therefore, to allow the heating sys-
tem configuration to be operational, some wire
connections must be modified and some CTRL-
Max settings changed, as required. Please refer
to paragraph 1.6 for more information.
2019-12 Prestige Igniter Replc.
1
