Prestige SOLO 60, 110, 175 and 250 Boiler
Propane to Natural Instructions
Kit Part Number: PSRKIT24
Kit Includes
-
Rating Label
-
(1) Naural Gas Orifice
-
T-25 Torx Wrench
Recommended Tools
-
Standard Adjustable Wrenches
-
Phillips-head Screwdriver
-
Flat-blade Screwdriver
-
T-40 Torex Wrench
WARNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
WARNING
Failure to follow instructions below can result in
severe personal injury or damage if ignored:
-
Instructions are for a qualified installer /
service technician.
-
Read all instructions before proceeding.
-
Follow instructions in the proper order.
WARNING
For your safety, turn off electrical power
supply at service panel and allow unit to cool
before proceeding. Failure to do so can cause
severe personal injury or death.
NOTICE
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
NOTICE
Upon completion of the conversion from
Propane to Natural, affix the new rating
label included in the kit to the unit adjacent
to the existing rating label. DO NOT affix
the new label over the existing rating label.
Remove all propane labeling from the gas
valve and surrounding area.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prestige SOLO 60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TriangleTube Prestige SOLO 60

  • Page 1 Prestige SOLO 60, 110, 175 and 250 Boiler Propane to Natural Instructions Kit Part Number: PSRKIT24 Kit Includes Rating Label (1) Naural Gas Orifice T-25 Torx Wrench Recommended Tools Standard Adjustable Wrenches Phillips-head Screwdriver Flat-blade Screwdriver T-40 Torex Wrench WARNING...
  • Page 2 Prestige SOLO 60, 110, 175 and 250 Boiler Propane to Natural Instructions Conversion of Gas Valve/Venturi Assembly 1. Turn off the electrical power supply to the boiler. 2. Close the manual gas shut off valve to the unit. 3. Remove the front panel of the Prestige by removing the mounting screw(s) along the upper edge of the unit.
  • Page 3 Prestige SOLO 60, 110, 175 and 250 Boiler Propane to Natural Instructions NOTICE Blower Remove Brass Gas Valve Propane Orifice. Maintain Black Gasket on Gas Valve Use care in the reassembly of the venturi / gas valve to the blower housing not to cross thread the mounting screws.
  • Page 4 Prestige SOLO 60, 110, 175 and 250 Boiler Propane to Natural Instructions Combustion Test and Adjustments ters adjust the THROTTLE SCREW (see Fig. 3) using a flat-blade screwdrive as follows: 1. The installer should perform a complete com- bustion analysis to ensure the following com-...
  • Page 5 Prestige SOLO 60, 110, 175 and 250 Boiler Propane to Natural Instructions 5. If the combustion readings during low fire are Offset Pressure not within +/- 0.2% of the combustion level Cover Screw measured at high fire, remove the offset cover...
