SCAN 1010 Series Assembly And Instruction Manual page 4

4
Technical data and dimensions
Materials: ................................ Steel plate, galvanised sheet,
Vermicolite, Chamotte, Robax glass
Surface treatment: .......................................................................... Senotherm
Max. wood length: ..................................................................................... 50 cm
Weight Scan 1010: .....................................................................approx 135 kg
Weight big box:...............................................................................approx 32 kg
Weight little box:............................................................................approx 20 kg
Connecting piece internal diameter: .............................................. 144 mm
Connecting piece external diameter: .............................................. 148
mm
Approval type: ................................................................ Intermittent fuelling
Please note:
You get the best use of the stove by using a
"top-down lighting", see page 21.
Test in compliance with EN 13229
Scan 1010
CO Emission at 13% O 2
CO Emission at 13% O 2
Dust @ 13% O 2
No x @ 13% O 2
Efficiency
Energy efficiency index
Energy efficiency class
Nominel output
Chimney temperature EN 13229
Temperature in connecting piece
Amount of smoke
Sub-pressure EN 13229
Recommended sub-pressure in connecting piece
Required combustion air supply
Fuel
Fuel consumption
Amount of fuel
T E C H N I C A L D ATA
Intermittent fuelling means normal use of a woodstove. In other
words, you should let the fire die down until only the embers are left,
before refuelling.
The Scan 1010 was build in compliance with the homologized product
type specified in the Assembly- and Instructions Manual provided
with the product.
The DoP declaration of performance is available from scan.dk
Technical data
16 - 18
0,1
mg/Nm 3
1246
mg/Nm 3
12
mg/Nm 3
41
82
109,9
A+
7
220
264
7,4
12
19,8
2,2
1,7
Unit
%
%
kW
°C
°C
g/sek
Pa
Pa
Nm 3 /h
Wood
kg/h
kg
