Electrical Connections

3.
3.1.

Rear Connecting Panel Layout Summary

Symbol
*
(unmarked)
Connect all the appropriate connectors prior to connecting the power adapter and
activating the device.
The ExpressCube
and run the cables from the rear connector panel. Do not use this space to bunch and store
excess cable as the movement of the platform could be restricted by cable contact.
Function
Power Switch Switches ExpressCube unit ON / OFF
*Authorized Personnel Only* Removal or damage to
Calibration
the calibration seal voids certification approvals
The ExpressCube™ universal power adapter includes
4 power connections and has the following world
Power Adapter
safety approvals: UL / ULC, CE, PSE, BS, GS, FCC,
SAA
This USB port can be used by a local PC to
USB
Operate and collect data from the ExpressCube™ unit.
Connect to handheld scanner (not supplied).
Hand Scanner
The port is a male RS-232 serial interface.
RS-232 male port provides ASCII data output for either
Printer a printer or direct data logging onto a hard drive via a
local PC application (not supplied).
These connectors are used to connect ExpressCube™
External Devices external devices such as the customer display or
control box.
™
countertop unit is designed such that there is space to connect
8
Description
