ExpressCube™ SizeIt™ Software Installation
5.
5.1.

Summary

The ExpressCube™ SizeIt™ software allows a local computer to operate and gather data from the
ExpressCube™ countertop unit with the USB port. This software must be installed and the USB
connected prior to powering-up the ExpressCube™ countertop unit. The software is not required if
the ExpressCube™ controller is used to control the countertop unit.
5.2.

Minimum Computer Requirements

•
Minimum 512 meg of available RAM
•
Pentium IV or better @ 2.0 GHz or better
•
Windows XP operating system
•
CD-ROM drive
•
Java version 1.5.0_06 or later
5.3.

Software Installation

1. Close down all applications currently running on the PC.
2. Insert the CD program disk into the CD-ROM drive of the computer.
3. Click the Windows 'START' button and select 'RUN'
4. Use the browse key to locate and select the 'set-up' file on the CD-ROM drive
5. Run the selected file.
Note - if you encounter recurring problems with the operation
of the program, un-install Size-It and re-install.
The person installing the software should have the appropriate system permissions to
install the software, this will vary for the system & location, and this can be especially critical
for Windows XP.
5.4.

Running the Software

Use either the Start / Program or Desktop menus
to begin the SizeIt™ program. The program will
open the control page as illustrated to the right.
Select the highest "com number" on the drop
menu to engage the USB (choice shown as
'com 7' in example at right).
The USB port will remain off when the
ExpressCube™ countertop unit is not powered.
The 'Set-up' key will not work until
communications is established on the USB link.
14
