Selecting the User Control for the ExpressCube

4.
The ExpressCube™ Countertop system must have an operator controller to perform the
measurement functions. The ExpressCube™ Countertop system can be controlled either by a
desktop computer using the USB interface or by using the ExpressCube™ LCD Controller. If a
display is required to monitor the ExpressCube operation, it is recommended to use the customer
display.
4.1.

ExpressCube

The use of the ExpressCube™ LCD Controller only requires the appropriate electrical connection as
described in the section above. The installation of the SizeIt™ software is not required. Proceed to
the power-up section of this user guide.
4.2.

Computer Control

The use of a computer to control the ExpressCube™ Countertop system will require the installation
and use of the SizeIt™ software. Connect the USB cable as previously described and follow the
instructions outlined in the ExpressCube™ SizeIt™ Software Installation section of this guide.
In this User Guide, the term 'control panel' [underlined] will reference the device used to
control the ExpressCube
computer running SizeIt
When the ExpressCube
Countertop system, the USB port is still active and can be used by a trained technical or
administration personnel to service the unit.
™
LCD Controller
™
Countertop System. ( i.e. ExpressCube
™
software )
™
LCD Controller is used to control the ExpressCube
13
System
TM
or
™
LCD Controller
™
local
