DISPLAY DESCRIPTION

DESCRIPTION OF CONTROL BUTTONS

MENU
short press = opening the main menu and confi rmation
long press (for approx. 3 s) = return from current mode
in the basic mode = opening info
in the main menu =browsing and setting current values
simultaneous press of the
mode) = locking of the keys
simultaneous press of the
mode) = unlocking of the keys
simultaneous press of the
main menu) = return to the basic mode
Note: By pressing any button fi rst, you activate the LCD
1, Current day (in the Prog mode, selection of the
number of days to be programmed)
2, Operating mode OFF/PROG/AUTO/MANU/
=HOLIDAY
3, Current room temperature
4, Heating on indication
5, Key lock indication
6, CLOC mode indication (current day and time
setting)
7, Wireless signal transmission indication
8, Low battery indication
9, Required temperature and current time display/
list of operating modes (this line is explained in
detail for every mode)
10, Indication of anti-freeze temperature of 3°C
button:
(ENTER)
/ button:
backlight!
MENU
and buttons (in the basic
MENU
and buttons (in the basic
MENU
and / buttons (in the
