WIRELESS ROOM THERMOSTAT

The BPT710 wireless thermostat can bring you substantial savings, not only in the energy
necessary for heating, but also in the costs resulting from heating system installations. BPT710
can control up to 9 switching elements (receivers). The elements are switched subsequently
to prevent current surges in the mains. The coverage in built-up area is approx. 35 m.
Characteristics:
7 weekly programs with 6 temperature
changes per day
backlit display
modes: AUTO/MANU/OFF/HOLIDAY
quick change of the required temperature
possibility of programming day-by-day or in
blocks of Mon-Fri, Sat-Sun, Mon-Sun
information on operating hours
TECHNICAL PARAMETERS
Power supply
Communication type
HF power
Frequency
Hysteresis
Number of temp. changes
Minimum program time
Temperature setting range
Temperature setting
Minimum indication step
Measurement accuracy
Battery life
Protection class
Working temperature
We, ELEKTROBOCK CZ s.r.o., herewith declare that the product BPT710 conforms to the basic require-
ments and other corresponding provisions of the Directive 1999/5/EC.
Issued: 01.04.2012
10
2 x1.5 V AAA alkaline batteries
(not included in the packing)
two-way
< 10 mW
433.92 MHz
0.2°C
6 temp. changes per every day
10 minutes
by 0.5°C
5 to 39°C (anti freeze 3°C)
0.1°C
± 0.5°C
heating season
IP20
0°C to +40°C
DECLARATION OF CONFORMITY
Pb
LEAD FREE
in compliance with RoHS
child lock – key lock
automatic transfer to SUMMER / WINTER
time
„OPEN WINDOW" function (automatic
switch-off of the heating during ventilation)
optional setting of the current temperature
correction
anti-freeze protection (3°C)
WARRANTY CERTIFICATE
(a 2-year warranty is granted for the product)
Product number:
Checked by:
In case of guarantee or post-
guarantee service, send the
thermostat to the manufacturer's
ELEKTROBOCK CZ s.r.o.
Blanenská 1763
Kuřim 664 34
Tel.: +420 541 230 216
MADE IN CZECH REPUBLIC
