ELEKTROBOCK BPT710 Manual page 3

Fig.1
Fig.3
- Lift off the front cover of the transmitter acc. to Fig. 1.
- Fasten the back cover to the wall (or on the wiring box directly); see Fig. 2.
- Insert 2 x 1.5 V alkaline batteries, type AAA (not included in the packing); heed the
correct polarity!
- Fasten the front cover on the back one; see Fig. 4, 5.
- Necessity of battery exchange is indicated by the "
- Always use the 2 x 1.5 V alkaline batteries, type AAA! (Do not use rechargeable batteries.)
- For correct function of BPT710, activate the receivers according to the instructions
on page 7!
Note: Dispose of old batteries according to regulations for hazardous waste
treatment!
3
BPT710 INSTALLATION
Fig.4
Fig.2
Holes for fastening
screws
Fig.5
" LCD symbol.
