- Page 1 Digital Satellite Receiver User instructions “RSD - 7255” RECEPTOR DE SATELITE DIGITAL "RSD-7255" RSD 7255 Menu © Copyright, Televés, S.A.
- Page 2 “RSD - 7255” RECEPTOR DE SATELITE DIGITAL RSD 7255 Menu Fig. -1- 0/12V AUDIO R LNB IN CAUTION MODEL NO: RSD - 7255 RISK OF ELECTRIC SHOCK TV OUT 100 / 240~, 50/60Hz, 35W DO NOT OPEN! LNB OUT TV/VCR VIDEO AUDIO L RS 232...
-
Page 3: Table Of Contents
User instructions “RSD - 7255” INDEX ................Page Before Start . -
Page 4: Before Start
Preface A Digital Satellite Receiver is a conve- features. This also explains special To install the RSD-7255 or before using nient product that allows you to view a features available only in this RSD- it after installation, be sure to read this... -
Page 5: Pannels And Connections Description
Remote Control Unit (RCU) Function Turns power ON/OFF of the RSD-7255 (Green lamp lights up when ON, Red lamp lights up when OFF). TV/RADIO Switches between TV & Radio mode or switches between "TV List" & "Radio List" in the program list menu. -
Page 6: Installation
When adding new 2- Connect the RSD-7255 to your TV 4- Tune to the required broadcast equipment, be sure to refer to the and if applicable to other peripheral channels. -
Page 7: Getting Started
(( S )) Language 1/5 Turn on the RSD-7255 by pressing the ( ) key. The LED on the front panel of the RSD-7255 will change from red to green, indicating that it is on. 1. ASTRA Select TV/Radio mode. -
Page 8: How To Adjust The Volume
User instructions “RSD - 7255” Volume The volume can be adjusted using either the remote control or the corresponding buttons on the front part of the satellite receiver To increase the volume, press the ( ) key, and to decrease volume, press the ( ) key. -
Page 9: How To Use "Favorite Tv/Radio Channel" List
Press the EXIT key to escape from the channel list. Electronic Program Guide (EPG) The RSD-7255 receives and stores the current TV and Radio channel information. This channel information includes detailed information on the next scheduled program. The EPG is an easy-to-use function to see this information on screen. -
Page 10: Last Channel Auto-Saving And Recall
Last Channel Auto-Saving and Recall If there is an interruption of AC power caused by pulling out the main plug of the RSD-7255 or brown-outs (power interruptions), once AC power is reapplied the previous TV channel and last selected Audio mode, appears without having to press the key. -
Page 11: Teletext Function
User instructions “RSD - 7255” TELETEXT Function Only TELETEXT supported TV users can use this function. Press the TXT key of the RCU. If the channel have TELETEXT service, "Teletext ON" will be displayed. Press TXT key one more time, "Teletext OFF" will come up, the TELETEXT service will be stopped. -
Page 12: Main Menu
User instructions “RSD - 7255” Main Menu When watching TV, press MENU key on the RCU or on the front panel of the RSD-7255. The main menu will appear on the screen. Channel Manager TV Channel Radio Channel Program Guide Select an item on the menu and press the OK (LIST) key to execute. -
Page 13: Timer
User instructions “RSD - 7255” TV/RADIO Channels - Delete: When a channel selected to be deleted, the colour of "No" column will be changed to be yellow. Selected channel will be deleted on the channel list. Press EXIT key then the dialog box will come up. -
Page 14: User Installation Menu
User instructions “RSD - 7255” User Installation Menu Antenna Setup You can assign satellites, LNBs and switches to 16 antennas in this "Antenna Setup" menu. Select any one antenna among 16 antennas using key. Assign satellite, LNB and switch to the selected antenna: - Satellite: Select any one satellite among 20 satellites preprogram- Antenna med. - Page 15 User instructions “RSD - 7255” Antenna Setup For reference: - In the case of using switch, please keep in mind the combination of antenna and each switch ports. - It is not allowed to use 22KHZ tone switch and DiSEqC switch at the same time because the attributes of both switches are utilizing the same 22KHZ tone.
-
Page 16: Auto Channel Search
For reference: - The number of transponders can be bigger than the preprogrammed because this RSD-7255 utilizes the NIT information transmitted by satellite to add up channels automatically. - If you wish to search for channels directly indicating band "L" frequencies (950 - 2150 MHz) see "TP Setup" . -
Page 17: Tp Setup
- Unlock: This means that the antenna and transponder data are not 0 Unlocked LNB Freq. 1 9750 LNB Freq. 2 10600 Check Signal properly set, therefore, the RSD-7255 is not in the condition to 0/12 Volt None Start 14/18 Volt None search channels. - Page 18 User instructions “RSD - 7255” TP Setup In general this option does not need to be used, as the receiver automatically detects all the programmes contained in the transponder. However, some of the programmes transmitted in test mode do not have the adequate information available.
-
Page 19: Parental Lock
User instructions “RSD - 7255” Parental Lock If you would like to restrict access to some channels, you can set a "Parental Lock" on these channels. And then you can prevent your children from watching channels, which are unsuitable for them. Only the person who knows the password can watch the locked channels. -
Page 20: Data Transfer
User instructions “RSD - 7255” Data Transfer RSD-7255 to RSD-7255 software upgrade and data transfer are possible through RS-232 cable. Connect TV with the master RSD-7255. Select "Data Transfer" of the master RSD-7255 Connect slave RSD-7255 (should be in stand-by mode) with master Please Connect Both Receivers Using RS-232 Communication Cable. -
Page 21: Options Menu
User instructions “RSD - 7255” Options Menu The "Options" menu allows the user to customize to his/her personal preferen- ce and location. OSD Language English Time Offset +1:00 Summer Time LNB Power Screen Format Video Output CVBS TV Type UHF Standard PAL G UHF Channel NO. -
Page 22: Factory Default
Receiver Info. When this menu is selected, a message will be shown on the screen. Warning! All Channel will be DELETED And all TP Data will be INITIALIZED! Receiver Info "Receiver Info" section has a brief introduction of the RSD-7255. -
Page 23: Technical Specifications
User instructions “RSD - 7255” Technical Specifications System capabilities Fully DVB compliant Demodulator Waveform QPSK Symbol rate 1-45Msps Video decoder MPEG-2 Main Profile @ Main Level Data Rates > 15Mbits/s Video formats 4:3, 16:9 Audio decoder MPEG-1 layer I & II (Musicam Audio) Mono, Dual channel, Stereo, Joint stereo Application system resources Processor... -
Page 24: Flow Chart Of Menu
User instructions “RSD - 7255” Flow Chart of Menu TV Channel Channel Manager Radio Channel Program Guide Turn ON Timer Turn OFF Signal Level Antenna, Satellite, LNB, 0/12V Antenna Setup Go to Auto Search 14/18V, 22KHz, DiSEqC Positioning Help Auto Search Search Option Antenna Select Start... -
Page 25: Guarantee
Televes S.A. offers a six-month guarantee, beginning from the date of purchase. Retain the receipt to determine this date. During the guarantee period, Televes S.A. is responsible for the faults produced due to the defects of the equipment or manufacturing. Televes S.A. complies with the guarantee by repairing or substituting the faulty equipment as it believes necessary. - Page 26 Tfno. 948 27 35 10 La Laguna. E-mail televes.fr@televes.com 948 17 41 49 Tfnos. 922 31 13 14 / 31 13 16 jazpeitia@cin.es TELEVES MIDDLE EAST FZE 922 31 13 33 P.O. Box 17199 tenerife@televes.com OVIEDO C.P.33006 JEBEL ALI FREE ZONE DUBAI Avda.
