Detail
Detectable paper size can be changed from Inch to Metric, Metric A Size
Paper, or Full Size by the administrator. See page 4-49 in the POD Ad-
ministrator's reference.
When loading 8.5"×11"R in the Multi-sheet bypass tray and specifying
the size in Bypass tray setting, the machine will detect A4R original as
8.5"×11"R. For details of Bypass tray setting, see page 9-15.
Z-Folded mode:
Use Z-Folded mode to scan folded originals without using the size detection
sensor of the ADF.
- Sizes available to be fed: Max. 11.69"×17" ~ 5.04"×5.5" (297 × 431.8 mm
~ 128 × 139.7 mm)
- Detectable original size: 11"×17", 8.5"×14", 8.5"×11", 5.5"×8.5",
5.5"×8.5"R, A3, B4, A4, B5, B5R, B6R
- Original weight: 13 ~ 34 lb (no special stock)
- Curling tolerance: 0.39" (10 mm) or less
- Max. feeder capacity: 100 sheets (20 lb)
- Feeding tolerance: 5 times or less (single-sided) / 3 times or less (double-
sided)
Single Feed mode:
Use Single Feed mode to copy thick originals to be fed one sheet at a time
in the document feeder.
- Sizes available to be fed: Max. 11.69"×17" ~ 5.04"×5.5" (297 × 431.8 mm
~ 128 × 139.7 mm)
- Sizes available to be fed: Max. 297 × 431.8 mm ~ 128 × 139.7 mm
- Detectable original size: 11"×17", 8.5"×14", 8.5"×11", 5.5"×8.5",
5.5"×8.5"R, A3, B4, A4, B5, B5R, B6R
- Original weight: 13 ~ 53 lb (200 g/m
sided)
- Curling tolerance: 0.39" (10 mm) or less
- Max. feeder capacity: 1 sheet at a time
- Feeding tolerance: 5 times or less (single-sided) / 3 times or less (double-
sided)
3-12
Paper and Original Information
2
) (single-sided) / 13 ~ 45 lb (double-
im9220
