14.8 Controlling Copier from Browser (Remote Panel)
When the machine is connected with a PC over a network, the web browser
activated on the PC enables you to operate the machine. This function is pro-
vided for persons with disabilities who have difficulty in operating the control/
touch panel, and also promotes efficiency in operation using PC keyboard
and mouse.
Remote Panel functions:
- Touch panel screens can be displayed on the web browser and operated
using a mouse.
- Control panel keys can be displayed on the web browser and operated
using a mouse.
- Passwords can be entered using PC keyboard.
The following functions are unavailable:
- Reading the screen performed by subsidiary system
- Turning ON/OFF the machine power (Main power switch/Sub power
switch, Power Save, Weekly Timer)
- Reporting paper misfeed, or displaying counter in real time
!
Detail
The setting procedure for the IP address is provided in POD Administra-
tor's reference. (Utility Screen>6 Administrator Setting>4 Network Set-
ting>2 IP NIC Setting>1 TCP/IP). For details, see page 4-96.
To specify the IP address of the PC to be used for Remote Panel function,
see page 5-15 of POD Administrator's reference.
To control copier from browser
0 Set the Enhance Security mode OFF on the machine.
0 The machine should be connected with a PC over a network with TCP/IP
enabled.
0 Specify the IP address of the machine.
0 Specify the IP address of the PC to be used for Remote Panel function,
using Web Utilities setting on a PC.
0 One of the following browsers is required on the PC. No other hardware
or application software is necessary.
Microsoft Internet Explorer 6.02 or higher
Netscape Navigator 7.1 or higher
FireFox 1.0 or higher
0 JavaScript must be active.
0 The popup menu such as paper misfeed prompt will not be updated au-
tomatically. After a long period of inactivity, click [Reload] at the upper
corner of the screen to display the current status.
