MANUAL
ID ISC.LR2000
Standard-Reader
from Firmware-Version
RFC 1.17.00
FPGA 2.00.04
ACC 2.02.00
final
public (B)
2011-04-21
H60700-3e-ID-B.doc

Advertisement

Table of Contents
loading

Related Manuals for Feig Electronic OBID i-scan ID ISC.LR2000

Summary of Contents for Feig Electronic OBID i-scan ID ISC.LR2000

  • Page 1 MANUAL ID ISC.LR2000 Standard-Reader from Firmware-Version RFC 1.17.00 FPGA 2.00.04 ACC 2.02.00 final public (B) 2011-04-21 H60700-3e-ID-B.doc...
  • Page 2 FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed with components and testing methods for a level of reliability suitable for use in or in connection with surgical implants or as critical components in any life support systems whose failure to perform can reasonably be expected to cause significant injury to a human.

  • Page 3: Table Of Contents

    4.3. CFG2: Inputs/Outputs I ....................34 4.3.1. Dedicated Input / Output Functions ................36 4.4. CFG3: RF-Interface ......................37 4.5. CFG4: Transponder Parameters ..................40 4.6. CFG5: Anticollision ......................43 4.7. CFG6: Customer Command Option Bytes ..............45 FEIG ELECTRONIC GmbH Page 3 of 184 H60700-3e-ID-B.doc...
  • Page 4 4.28. CFG44 WLAN Security Settings, Part 1 ................82 4.29. CFG45 WLAN Security Settings, Part 2 ................83 4.30. CFG46: People Counter Notification Channel..............84 4.31. CFG49: Notification Channel ..................85 4.32. CFG63: Customer Parameter ..................88 FEIG ELECTRONIC GmbH Page 4 of 184 H60700-3e-ID-B.doc...
  • Page 5 7. Protocols for ISO15693 Host Commands 7.1. [0xB0] Host commands for ISO15693 Mandatory and Optional Commands ..... 115 7.1.1. [0x01] Inventory ......................116 7.1.2. [0x02] Stay Quiet ...................... 119 7.1.3. [0x22] Lock Multiple Blocks ..................120 FEIG ELECTRONIC GmbH Page 5 of 184 H60700-3e-ID-B.doc...
  • Page 6 7.4.1. Texas Instruments (Tag-it HFI Pro / Standard) ............151 7.4.2. Texas Instruments (Tag-it HFI Plus) ............... 153 7.5. Supported ISO15693 Host commands for non ISO15693 Transponders ....155 7.5.1. NXP I-Code EPC Transponders ................155 FEIG ELECTRONIC GmbH Page 6 of 184 H60700-3e-ID-B.doc...
  • Page 7 ISO15693 Host Command (DB-Size of the Transponder = 4 bytes) ........175 ISO15693 Host Command (DB-Size of the Transponder = 8 bytes) ........175 ANNEX F: Labeling of configuration parameter ..............176 FEIG ELECTRONIC GmbH Page 7 of 184 H60700-3e-ID-B.doc...

  • Page 8: Revision History Of Documentation

    Customer Parameter in CFG63 Note for Set Default Configuration Additional modes for Reader Diagnostic 14.09.09 Labeling of configuration parameter AFI4 inserted AFI – Relay assignment EAS Mode People Counter Settings 47, 84 20.04.11 FEIG ELECTRONIC GmbH Page 8 of 184 H60700-3e-ID-B.doc...

  • Page 9: Abbreviations

    Most Significant Byte Number Output Read / Write Access Read Relay Radio Frequency RSSI Received Signal Strength Indicator Real Time Clock Table Transponder Timeslot Unique Identifier (read only Serial Number) Write Only Access Write FEIG ELECTRONIC GmbH Page 9 of 184 H60700-3e-ID-B.doc...

  • Page 10: Introduction

    ISO Host commands used throughout the OBID i-scan product line. The configuration possibilities of the ID ISC.LR2000 reader make it easy to adapt the reader to a range of applications by software and hardware configuration. FEIG ELECTRONIC GmbH Page 10 of 184 H60700-3e-ID-B.doc...
  • Page 11 ACC Firmware can also be updated allowing the reader to adapted to different applications. FEIG Electronic provides a library which allows the user to develop their own applications to run on the ACC. FEIG ELECTRONIC GmbH Page 11 of 184 H60700-3e-ID-B.doc...

  • Page 12: Data Transmission Between Obid I-Scan ® Id Isc.lr-Reader And Host

    Host (Terminal / PC / ..) Reader parameter- / control command  parameter received and stored / control command processed  status / error status data  FEIG ELECTRONIC GmbH Page 12 of 184 H60700-3e-ID-B.doc...

  • Page 13: Iso15693 Host Commands

    Transponder data in Reader field  write data to Transponder with UID  Transponder with correct UID in antenna field ?  OK status status = no Transponder in Reader field  FEIG ELECTRONIC GmbH Page 13 of 184 H60700-3e-ID-B.doc...
  • Page 14 = no Trans- Transponder read ponder data in Reader field   write data Transponder in antenna field ?  OK status status = no Trans- ponder in Reader field  FEIG ELECTRONIC GmbH Page 14 of 184 H60700-3e-ID-B.doc...
  • Page 15 / status = Transponder read no Transponder data in Reader field  write data  selected Transponder in antenna field ?  OK status status = no Transponder in Reader field  FEIG ELECTRONIC GmbH Page 15 of 184 H60700-3e-ID-B.doc...

  • Page 16: Buffered Read Mode

    Only read operations are available with the Buffered Read Mode.  The Buffered Read Mode is only available if Scan Mode is disabled  The Buffered Read Mode can be used with the 2.6. Reader Multiplex Mode. FEIG ELECTRONIC GmbH Page 16 of 184 H60700-3e-ID-B.doc...

  • Page 17: Notification Mode

    Keepalive messages are never acknowledged by the host. The Keepalive message should not be mistake with the keepalive option (s. CFG41/CFG43) of a LAN/WLAN con- nection initiated by a host. FEIG ELECTRONIC GmbH Page 17 of 184 H60700-3e-ID-B.doc...

  • Page 18: Scan Mode

    2 Transponder in detection range UID and data block should be read: UID1 data1 UID2 data2 Com-Prefix (optional) SCAN-LOCK-TIME UID: Serial-Number (fix) time to the next new Transponder reading data: data blocks (free programmable) Separation character (optional) End character (optional) FEIG ELECTRONIC GmbH Page 18 of 184 H60700-3e-ID-B.doc...
  • Page 19 Only read operations are available with the Scan Mode.  Scan Mode is only available if Buffered Read Mode is disabled  The Scan Mode can be used with the 2.6. Reader Multiplex Mode. FEIG ELECTRONIC GmbH Page 19 of 184 H60700-3e-ID-B.doc...

  • Page 20: Reader Multiplex Mode (Syncronisation)

    Please refer the manual “Mounting Instructions ID ISC.LR(M)2000” (M51001-xde-ID-B.pdf / M51101-0de-ID-B.pdf) for details. Note: Multiplex Mode will only be available in Buffered Read Mode, Notification Mode and Scan Mode. FEIG ELECTRONIC GmbH Page 20 of 184 H60700-3e-ID-B.doc...

  • Page 21: Interface

    The keepalive parame- ters can be modified in the configuration pages for LAN and WLAN. This keepalive option should not be mistake with the Keepalive message for notification mode. FEIG ELECTRONIC GmbH Page 21 of 184 H60700-3e-ID-B.doc...

  • Page 22: Serial Data Format And Protocol Frames

    Protocol frame: Advanced Protocol-Length Reader  Host (6...n-2) CONTROL- COM-ADR (DATA)  (0x02) ALENGTH ALENGTH BYTE  CRC16 CRC16 Host  Reader (7...n-2) CONTROL- COM-ADR STATUS (DATA)  (0x02) ALENGTH ALENGTH BYTE  CRC16 CRC16 FEIG ELECTRONIC GmbH Page 22 of 184 H60700-3e-ID-B.doc...
  • Page 23 Cyclic redundancy check of the protocol bytes from 1 to n-2, as specified by CCITT- CRC16 Polynom: + 1 (0x8408) Start Value: 0xFFFF Direction: Backward see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 23 of 184 H60700-3e-ID-B.doc...

  • Page 24: Crc16 Calculation Algorithm

    /* cnt = number of protocol bytes without CRC */ crc ^= DATA[i]; for (j = 0; j < 8; j++) if (crc & 0x0001) crc = (crc >> 1) ^ CRC_POLYNOM; else crc = (crc >> 1); FEIG ELECTRONIC GmbH Page 24 of 184 H60700-3e-ID-B.doc...

  • Page 25: Configuration Parameters (Cfg)

    Malfunctions may occur if parameters are configured without their described range or if unspecified parameters have been changed!  A firmware update resets the EEPROM to default settings and the Reader goes into the er- ror status “EE-Init-mode”. FEIG ELECTRONIC GmbH Page 25 of 184 H60700-3e-ID-B.doc...
  • Page 26 Changing of this parame- ter only becomes effective this may cause faulty operation of after writing / saving this the Reader. configuration block EEPROM and a Reader reset FEIG ELECTRONIC GmbH Page 26 of 184 H60700-3e-ID-B.doc...

  • Page 27: Cfg0: Passwords

    The Bit in CFG_NO defines if the access to the configuration block is free or if the use should login to the Reader to get access to the configuration block. b0  Access if free b1  Access need a login FEIG ELECTRONIC GmbH Page 27 of 184 H60700-3e-ID-B.doc...
  • Page 28  It is possible to disable the READER-ID with an activation code, if the READER-ID is unknown. The activation code must be ordered by your supplier or FEIG Electronic GmbH. Config Protection By means of Config Protection, the access to the configuration parameters stored within the Reader is protected by a 32-bit password, the "READER-ID".

  • Page 29: Cfg1: Interface

     Via the COM-Adr 255 in the send protocol, the Reader is able to be addressed at any time. It answers then with the configured address. A reasonableness check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = 0x11. FEIG ELECTRONIC GmbH Page 29 of 184 H60700-3e-ID-B.doc...
  • Page 30 Number of Stop Bits 1 Stop Bit - do not use – A reasonableness check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = 0x11. FEIG ELECTRONIC GmbH Page 30 of 184 H60700-3e-ID-B.doc...
  • Page 31 Standard Protocol Frame ( to be used for compatibility with previous LR200) SCAN-INTERFACE: (OperatingMode.ScanMode.Interface) Selection of the communication port for Scan-Mode Bit: Function: IF-NO IF-NO: Interface Number b000: RS232 b001: RS485/RS422 b01x: - do not use – b1xx: - do not use - FEIG ELECTRONIC GmbH Page 31 of 184 H60700-3e-ID-B.doc...
  • Page 32 (HostInterface.Interfaces) Flags for enabling the communication ports Bit: Function: WLAN RS4xx RS232 RS232: b0: disable b1: enable RS4xx: b0: disable b1: enable LAN: b0: disable b1: enable WLAN: b0: disable b1: enable FEIG ELECTRONIC GmbH Page 32 of 184 H60700-3e-ID-B.doc...
  • Page 33 The following table lists the bit combinations for the reader modes: Host-Mode Scan Mode Buffered Read Mode Notification Mode Note:  The Scan, the Buffered Read and the Notification Mode is only supported by LR- Reader (Reader with ACC). FEIG ELECTRONIC GmbH Page 33 of 184 H60700-3e-ID-B.doc...

  • Page 34: Cfg2: Inputs/Outputs I

      REL2 frq REL3 frq REL4 frq Bit combination flashing frequency b 1 1 1 Hz b 1 0 2 Hz b 0 1 4 Hz b 0 0 8 Hz FEIG ELECTRONIC GmbH Page 34 of 184 H60700-3e-ID-B.doc...
  • Page 35 BRM-mode (reading of serial number and data): if the serial number was read OK and the data not, no data set will be transferred, but the assigned RELx and / or the OUT1 will be active. FEIG ELECTRONIC GmbH Page 35 of 184 H60700-3e-ID-B.doc...

  • Page 36: Dedicated Input / Output Functions

    LED1 (green) and LED2 (blue) are blinking alternately if a read error of the EEPROM oc- curred after power-up or a 6.3. [0x63] RF Controller Reset command. A Firmware update sets the EEPROM to initial state and the LED1 and LED2 are also blinking alternately. FEIG ELECTRONIC GmbH Page 36 of 184 H60700-3e-ID-B.doc...

  • Page 37: Cfg3: Rf-Interface

    Transponder access is mini- mized. A reasonableness check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = [0x11]. FEIG ELECTRONIC GmbH Page 37 of 184 H60700-3e-ID-B.doc...
  • Page 38 The I-Code EPC and UID Firmware must be released with the command “Set Firmware Upgrade” first. For this you have to use the demo program ID ISOS- tart and the Upgrade Code must be ordered by Feig Electronic.  The default value depends on the already released transponder driver.
  • Page 39 DC (AirInterface.Antenna.HF.Miscellaneous.Enable_DCPower) defines whether the Reader supplies DC voltage on the RF line to supply Function Units in the RF line with DC power. DC voltage OFF DC voltage ON FEIG ELECTRONIC GmbH Page 39 of 184 H60700-3e-ID-B.doc...

  • Page 40: Cfg4: Transponder Parameters

    RATE CARRIER CODING DATACODING (Transponder.HF.ISO_15693.LinkRate.DataCoding) 1 out of 256 Fast Mode (1 / 4) - do not use - 10% (the modulation depth in the setting in 4.21. CFG20: RF-Parameter) are used FEIG ELECTRONIC GmbH Page 40 of 184 H60700-3e-ID-B.doc...
  • Page 41 BREAK BREAK (Transponder.HF.ISO_15693.Miscellaneous.CommandBreak) break timeslot at “NO Transponder” Break is always 100% modulated EOF This option speeds up the anticollision process, but increases modulation band width Complete timeslot length at “NO Transponder” FEIG ELECTRONIC GmbH Page 41 of 184 H60700-3e-ID-B.doc...
  • Page 42 A value of 0x00 will be automatically set to a block size of 4byte. Blocksize: (Transponder.HF.ISO_15693.Miscellaneous.ReadOption.BlockSizeSelection) Automatic (If transponder is known) Manuel (As specified in DB-Blocksize) Read Mode: (Transponder.HF.ISO_15693.Miscellaneous.ReadOption.ReadMode) b00: Automatic Mode (If transponder is known) Single Read Multiple Read FEIG ELECTRONIC GmbH Page 42 of 184 H60700-3e-ID-B.doc...

  • Page 43: Cfg5: Anticollision

    MAX-TS must contain the value of the desired timeslot. A reasonableness check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = 0x11. FEIG ELECTRONIC GmbH Page 43 of 184 H60700-3e-ID-B.doc...
  • Page 44 Transponders inside of the antenna field. Note: If 1 timeslot is set and the CRC on an I-Code EPC is wrong the serial number will be trans- ferred and the status is set to “[0x02] Data False” FEIG ELECTRONIC GmbH Page 44 of 184 H60700-3e-ID-B.doc...

  • Page 45: Cfg6: Customer Command Option Bytes

    0x00 0x00 0x00 0x00 Note: There are application notes available from FEIG ELECTRONIC GmbH for the descrip- tion of the customer commands. It is also recommended to read the transponder specification from the according transponder manufacturer. FEIG ELECTRONIC GmbH Page 45 of 184...

  • Page 46: Cfg7 Reserved

    4.8. CFG7 Reserved The configuration blocks CFG7 .. 8 are reserved for future use. Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default FEIG ELECTRONIC GmbH Page 46 of 184 H60700-3e-ID-B.doc...

  • Page 47: Cfg8: People Counter

    I/O Settling-TIME. If I/O Settling-TIME is zero the function is disabled. Range: 0x0000 ... 0xFFFF ( * 100ms) = 0s ... 6553,5s. FEIG ELECTRONIC GmbH Page 47 of 184 H60700-3e-ID-B.doc...
  • Page 48 ANT2 ANT1 OUT3_PCNT2 (PeripheralDe- vice.RS485.BusAdr2.DigitalIO.Output.No3.ReadEventActivation.AntennaNo) defines which antenna activates the Output 3 on People Counter 2 if a Transponder has been detected. Bit: Function ANT8 ANT7 ANT6 ANT5 ANT4 ANT3 ANT2 ANT1 FEIG ELECTRONIC GmbH Page 48 of 184 H60700-3e-ID-B.doc...
  • Page 49 ANT2 ANT1 OUT3_PCNT3 (PeripheralDe- vice.RS485.BusAdr3.DigitalIO.Output.No3.ReadEventActivation.AntennaNo) defines which antenna activates the Output 3 on People Counter 3 if a Transponder has been detected. Bit: Function ANT8 ANT7 ANT6 ANT5 ANT4 ANT3 ANT2 ANT1 FEIG ELECTRONIC GmbH Page 49 of 184 H60700-3e-ID-B.doc...

  • Page 50: Cfg9: Input / Output Ii (Assignment - Output To Antenna Read Event)

    Bit: Function ANT4 ANT3 ANT2 ANT1 Relay4_AE (Relay4 assignment to antenna read event) (DigitalIO.Relay.No4.ReadEventActivation.AntennaNo) defines which antenna activates the Relay4 if a Transponder has been detected. Bit: Function ANT4 ANT3 ANT2 ANT1 FEIG ELECTRONIC GmbH Page 50 of 184 H60700-3e-ID-B.doc...
  • Page 51 (DigitalIO.Miscellaneous.AFIAssignment) activates the AFI 1,2,3,4 assignment to the relay 1,2,3,4 activates Assignment 0x00 AFI1, AFI2, AFI3, AFI4 => Realy1 AFI1 => Realy1 AFI2 => Relay2 0x01 AFI3 => Relay3 AFI4 => Relay4 FEIG ELECTRONIC GmbH Page 51 of 184 H60700-3e-ID-B.doc...

  • Page 52: Cfg10: Trigger

    The Reader start the RF Power and the scan, if the trigger is activated by the external switch. Note If Trigger is enabled and not activated by the external switch, the RF- field will be switched off. FEIG ELECTRONIC GmbH Page 52 of 184 H60700-3e-ID-B.doc...
  • Page 53 X is the input which is used as a trigger (1 ... 65535 * 100 ms = 100 ms ... 6553,5 sec) The TRIGGER-HOLD-TIME defines the period in which the Reader performs inventory com- mands and hold the RF Power active. FEIG ELECTRONIC GmbH Page 53 of 184 H60700-3e-ID-B.doc...

  • Page 54: Cfg11: Read Mode /Scan Mode - Read Data

    A reasonableness check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = [0x11]. FEIG ELECTRONIC GmbH Page 54 of 184 H60700-3e-ID-B.doc...
  • Page 55 DATE (OperatingMode.ScanMode.DataSelector.Date) (OperatingMode.NotificationMode.DataSelector.Date) (OperatingMode.BufferedReadMode.DataSelector.Date) no date is transferred BRM Data record date is transferred BRM Data record Extension If this flag is set TR-DATA-2 is present FEIG ELECTRONIC GmbH Page 55 of 184 H60700-3e-ID-B.doc...
  • Page 56 If this bit is set, the reader stores only one data set also if a tag has been detected of more than one multiplexer antenna. If this bit is not set, the reader stores a data set for each mul- tiplexer antenna. FEIG ELECTRONIC GmbH Page 56 of 184 H60700-3e-ID-B.doc...
  • Page 57 4 bytes. (see Annex : 7.3. Supported ISO15693 Host commands for ISO15693 Transponders.) A plausibility check is performed by writing this parameter to the Reader. If an error occurs the Reader answers with STATUS = [0x11]. FEIG ELECTRONIC GmbH Page 57 of 184 H60700-3e-ID-B.doc...
  • Page 58 Number of data bytes to be transferred, starting with the D-START. Example: data block Byte Data 0x01 0x23 0x45 0x67 0x89 0xAB 0xCD 0xEF D-START = 1 D-LGT = 4 Output Data 0x23 0x45 0x67 0x89 FEIG ELECTRONIC GmbH Page 58 of 184 H60700-3e-ID-B.doc...

  • Page 59: Cfg12: Read Mode - Filter

    Sets the data source for Transponder identification. data block Serial Number TR-ID-DB-ADR (OperatingMode.Miscellaneous.TransponderIdentification.DataBlockNo) Sets the address of the data block for Transponder identification. If ID-SOURCE se- lects the Serial Number as data source, the ID-DB-ADR will be ignored. FEIG ELECTRONIC GmbH Page 59 of 184 H60700-3e-ID-B.doc...
  • Page 60 IN-EV-FLT: Input Event Filter (only for BRM and Notification Mode) Bit: Function Input4 Input3 Input2 Input1 Input1...4 (OperatingMode.NotificationMode.Filter.Enable_Input1Event) (OperatingMode.BufferedReadMode.Filter.Enable_Input1Event) input event will not be notified input event will be notified DB-ADR, DB-N of CFG11 FEIG ELECTRONIC GmbH Page 60 of 184 H60700-3e-ID-B.doc...
  • Page 61 BRM will not be notified timeout event while active BRM will be notified (OperatingMode.NotificationMode.Filter.Enable_TriggerEvent) (OperatingMode.BufferedReadMode.Filter.Enable_TriggerEvent) change of BRM status will not be notified change of BRM status will be notified FEIG ELECTRONIC GmbH Page 61 of 184 H60700-3e-ID-B.doc...

  • Page 62: Cfg13: Scan-Mode

    0x30 b0001 0x31 b0010 0x32 b0011 0x33 b0100 0x34 b0101 0x35 b0110 0x36 b0111 0x37 b1000 0x38 b1001 0x39 b1010 0x41 b1011 0x42 b1100 0x43 b1101 0x44 b1110 0x45 b1111 0x46 FEIG ELECTRONIC GmbH Page 62 of 184 H60700-3e-ID-B.doc...
  • Page 63 „,„ „;‟ CR+LF ASCII CR+LF 0x0D and 0x0A 0x0A 0x0D 0x09 „;‟ 0x3B „,‟ 0x2C „ „ 0x20 USER user defined in SEP-USR none 0x00 Note: Only one option can be selected. FEIG ELECTRONIC GmbH Page 63 of 184 H60700-3e-ID-B.doc...
  • Page 64 HEADER-USR1 + 2 + 3 + 4 Example of scan data: COM- Separation Separation Data- Header END Character Character Character Blocks COM- SEP-CHAR USR1 USR2 USR3 USR4 SEP-CHAR USR1 USR2 USR3 FEIG ELECTRONIC GmbH Page 64 of 184 H60700-3e-ID-B.doc...

  • Page 65: Cfg14: Reserved

    4.15. CFG14: Reserved The configuration block CFG14 is reserved for future use. Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default FEIG ELECTRONIC GmbH Page 65 of 184 H60700-3e-ID-B.doc...

  • Page 66: Cfg15: Antenna Multiplexing I

    The allocation between the input channels and the output channels is fixed if the Dual Mode (2 input channels) is used. The following table shows the allocation between the input channel and the output channel in the Dual Mode. FEIG ELECTRONIC GmbH Page 66 of 184 H60700-3e-ID-B.doc...
  • Page 67 MUX Hardware) to one of the two inputs. Only one output per input can be active at a time. In Single Mode only one channel is enabled, whereas in Dual Mode two channels are enabled. FEIG ELECTRONIC GmbH Page 67 of 184...

  • Page 68: Cfg16: Persistence Reset

    Transponder state. Timer ticks = 5ms Maximum timer value = 5ms x 65534[0xFFFE] = 5,46125 min. The value 65535 [0xFFFF] indicates that no RF reset is performed by the Reader FEIG ELECTRONIC GmbH Page 68 of 184 H60700-3e-ID-B.doc...

  • Page 69: Cfg17: Antenna Multiplexing Ii

    ANT_x the Transponder communication on the active antenna is stopped, and the Reader switches to the next antenna. If „fixed“ is selected under Switch Condition, the switch to the next channel is always made in this time. FEIG ELECTRONIC GmbH Page 69 of 184 H60700-3e-ID-B.doc...

  • Page 70: Cfg18: Reader Synchronisation

    SYNC SWITCH CONDITION: (Operating- Mode.Miscellaneous.HF.ReaderSynchronization.Is_Master) After the anticollision process has finished (no additional response) or at the latest after the TR-RESPONSE-TIMEOUT, the reader sends the sync signal to the next reader. reserved FEIG ELECTRONIC GmbH Page 70 of 184 H60700-3e-ID-B.doc...
  • Page 71 SYNC-TIMEOUT, the reader starts the RF communication automatically after the SYNC- TIMEOUT. In addition, the error message “0x85 Synchronisation Error” appears.  An additional Application note for the synchronisation feature is available. FEIG ELECTRONIC GmbH Page 71 of 184 H60700-3e-ID-B.doc...

  • Page 72: Cfg19: Reserved

    4.20. CFG19: Reserved The configuration block CFG19 is reserved for future use. Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default FEIG ELECTRONIC GmbH Page 72 of 184 H60700-3e-ID-B.doc...

  • Page 73: Cfg20: Rf-Parameter

    Weak Collision I-Code UID /EPC: (AirInterface.Miscellaneous.HF.ICodeUID_ICodeEPC.ErrorHandling.Weak- Collision) a weak collision has valid data a weak collision has corrupted data and the data will be ignored FEIG ELECTRONIC GmbH Page 73 of 184 H60700-3e-ID-B.doc...
  • Page 74  System-Manual ID ISC.LR2000 OBID i-scan REC_CHN: (AirInterface.Miscellaneous.HF.ReceiverChannel) Defines which receiver channel / Transponder response sideband is used.. Bit: Function automatic b01: lower sideband b10: upper sideband b11: Upper and lower sideband FEIG ELECTRONIC GmbH Page 74 of 184 H60700-3e-ID-B.doc...

  • Page 75: Cfg22 + Cfg23: Selection Mask (Only I-Code Uid And Epc Transponder)

    152 (=0x98) SELECTION MASK: (Transponder.HF.ICodeUID_ICodeEPC.SelectionMask.Mask) Defines the mask for the selection (MSB first). The selection mask is checked against the memory content on a bit by bit basis. FEIG ELECTRONIC GmbH Page 75 of 184 H60700-3e-ID-B.doc...
  • Page 76 Number of Selection Bits 10 11 12 13 14 15 16 17 18 19 20 ... Selection Bits Selection Mask 0x01 0x02 Only Transponders whose serial numbers begin with "0000 0001 00" return an answer. FEIG ELECTRONIC GmbH Page 76 of 184 H60700-3e-ID-B.doc...

  • Page 77: Cfg24

    4.23. CFG24 .. 29: Reserved The configuration blocks CFG24 .. 29 are reserved for future use. Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default FEIG ELECTRONIC GmbH Page 77 of 184 H60700-3e-ID-B.doc...

  • Page 78: Cfg40: Lan Settings, Part 1

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 78 of 184 H60700-3e-ID-B.doc...

  • Page 79: Cfg41: Lan Settings, Part 2

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 79 of 184 H60700-3e-ID-B.doc...

  • Page 80: Cfg42: Wlan Settings, Part 1

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 80 of 184 H60700-3e-ID-B.doc...

  • Page 81: Cfg43: Wlan Settings, Part 2

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 81 of 184 H60700-3e-ID-B.doc...

  • Page 82: Cfg44 Wlan Security Settings, Part 1

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 82 of 184 H60700-3e-ID-B.doc...

  • Page 83: Cfg45 Wlan Security Settings, Part 2

     5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 83 of 184 H60700-3e-ID-B.doc...

  • Page 84: Cfg46: People Counter Notification Channel

    Defines the port number for wired LAN connection to the destination host. Changing of this pa- rameter only becomes effective after writing / saving this configuration block to EEPROM and a [0x64] System Reset of the LAN-adapter. FEIG ELECTRONIC GmbH Page 84 of 184 H60700-3e-ID-B.doc...

  • Page 85: Cfg49: Notification Channel

    8. Protocols for Buffered Read Mode and Notification Mode. ACK: Acknowledge Notification (Operating- Mode.NotificationMode.Transmission.Enable_Acknowledge) Notification must not be acknowledged Notification must be acknowledged with protocol [0x32] Clear Data Buffer FEIG ELECTRONIC GmbH Page 85 of 184 H60700-3e-ID-B.doc...
  • Page 86 Defines the cycle time for keep alive notification. max. time period KEEP-ALIVE-TIME 0...65535 * 1s DEST-IP-ADDRESS: (Operating- Mode.NotificationMode.Transmission.Destination.IPv4.IPAddress) Defines the destination IP address. DEST-IP-PORT-NUMBER: (Operating- Mode.NotificationMode.Transmission.Destination.PortNumber) Defines the destination port number. HOLD-Time: (Operating- Mode.NotificationMode.Transmission.Destination.ConnectionHoldTime) Defines the connection hold time. FEIG ELECTRONIC GmbH Page 86 of 184 H60700-3e-ID-B.doc...
  • Page 87  5.4. [0x83] Set Default Configuration command has no effect on this setting.  Using the hardware configuration reset (see mounting instruction) the settings in CFG40-49 will be reset to the default. FEIG ELECTRONIC GmbH Page 87 of 184 H60700-3e-ID-B.doc...

  • Page 88: Cfg63: Customer Parameter

    Any kind of customer hex data can be stored in this EEPROM or RAM memory area. Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default Byte Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00 Default FEIG ELECTRONIC GmbH Page 88 of 184 H60700-3e-ID-B.doc...

  • Page 89: Protocols For Reader Configuration

    14 bytes configuration block read from address CFGn in CFG-ADR. Note: A read configuration from EEPROM with reserved configuration blocks will cause an 0x15 error code. see ANNEX D: Index of Status Bytes see Chapter 4. Configuration Parameters (CFG) FEIG ELECTRONIC GmbH Page 89 of 184 H60700-3e-ID-B.doc...

  • Page 90: 0X81] Write Configuration

    A write configuration to EEPROM with reserved configuration blocks will cause an 0x16 error code.  To store RAM configuration over power down use 5.3. [0x82] Save Configuration see ANNEX D: Index of Status Bytes see chapter 4. Configuration Parameters (CFG) FEIG ELECTRONIC GmbH Page 90 of 184 H60700-3e-ID-B.doc...

  • Page 91: 0X82] Save Configuration

     Note:  A save configuration to EEPROM with reserved configuration blocks will result in error code 0x16 . see ANNEX D: Index of Status Bytes see chapter 4. Configuration Parameters (CFG) FEIG ELECTRONIC GmbH Page 91 of 184 H60700-3e-ID-B.doc...

  • Page 92: 0X83] Set Default Configuration

     CFG0 and CFG 40-49 will never be set to default.  A configuration reset of CFG1 and CFG40-49 is also possible by using the DIP-switches of the reader. See mounting instruction. FEIG ELECTRONIC GmbH Page 92 of 184 H60700-3e-ID-B.doc...

  • Page 93: 0X87] Set System Time And Date

    The Get System Time and Date command reads the internal system timer of the ACC. Host  Reader 4...5 COM-ADR [0x88] CRC16 Host  Reader 5..9 9...12 13...14 COM-ADR [0x88] STATUS DATE TIMER CRC16 see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 93 of 184 H60700-3e-ID-B.doc...

  • Page 94: Protocols For Reader Control

    In order to avoid unauthorized data access, the Reader is equipped with the following protection me- chanism:  Config-Protection: Access locking for the configuration parameters stored in the EEPROM of the Reader. FEIG ELECTRONIC GmbH Page 94 of 184 H60700-3e-ID-B.doc...

  • Page 95: 0X52] Baud Rate Detection

    Host  Reader 0x00 [0x55] CRC16 Host  Reader 0x00 [0x55] 0x00 CRC16 Note:  This command is only available if the correct COM-ADR of the Reader is used. (Do not use 0xFF) FEIG ELECTRONIC GmbH Page 95 of 184 H60700-3e-ID-B.doc...

  • Page 96: 0X63] Rf Controller Reset

    The RF Controller will be reset after the ACC runs a start up process. A reset of the ACC can last up to 15 seconds. see ANNEX D: Index of Status Bytes see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 96 of 184 H60700-3e-ID-B.doc...

  • Page 97: 0X66] Get Reader Info

     STATUS 10-11 12,13 14,15 16,17  HW-TYPE CRC16 Mode = 0x03 (FPGA Firmware) 5...6  COM-ADR [0x66] SW-REV D-REV STATUS 9...10  FPGA-TYPE CRC16 see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 97 of 184 H60700-3e-ID-B.doc...
  • Page 98 Byte Bit: CFG_NO Byte Bit: CFG_NO Mode = 0x60 (I/O Info) Defines the number of inputs, outputs and relays. COM-ADR [0x66] STATUS NR_OF_ NR_OF_  INPUTS OUTPUTS 8...9 NR_OF_  CRC16 RELAYS FEIG ELECTRONIC GmbH Page 98 of 184 H60700-3e-ID-B.doc...
  • Page 99 Revision status of the development Firmware. D-REV is set to „0‟ in customized Firmware re- visions. HW-TYPE: Displays options which are supported by the Reader Hardware SW-TYPE: Type of Reader Firmware 0x2A ID ISCLR2000 (42) FEIG ELECTRONIC GmbH Page 99 of 184 H60700-3e-ID-B.doc...
  • Page 100 EU frequency not supported b1: EU frequency supported FCC: b0: FCC frequency not supported b1: FCC frequency supported UHF: b0: UHF not supported b1: UHF supported b0: HF not supported b1: HF supported FEIG ELECTRONIC GmbH Page 100 of 184 H60700-3e-ID-B.doc...
  • Page 101 TX-BUF is the maximum transmit buffer size of the Reader. The Host has to take in to ac- count that a response protocol of the Reader can have this length. DEV_ID: Individual device identifier of the Reader. CUSTOM_L Indicates which customer Firmware is licensed on the Reader. FEIG ELECTRONIC GmbH Page 101 of 184 H60700-3e-ID-B.doc...
  • Page 102 OBID i-scan FW_L: Indicates which Firmware version is licensed on the Reader. TR_DRV_L: Indicates which Transponder drivers are licensed on the Reader. FNC_L Indicates which optional functions are licensed on the Reader. FEIG ELECTRONIC GmbH Page 102 of 184 H60700-3e-ID-B.doc...

  • Page 103: 0X69] Rf Reset

     After a RF Reset, a Transponder which is located within the field has to be re-selected.  The response of this command will be sent after the RF Reset was completed. see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 103 of 184 H60700-3e-ID-B.doc...

  • Page 104: 0X6A] Rf Output On/Off

    Set RF output active or RF Power OFF Description RF OFF RF ON Set DC voltage for the antenna output to supply function units. Description DC ON DC OFF see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 104 of 184 H60700-3e-ID-B.doc...

  • Page 105: 0X6D] Get Noise Level

    11...12 COM-ADR [0x6D] NOISE-LEVEL CRC16 STATUS NOISE-LEVEL: Byte 5...6 7...8 9...10 NOISE-LEVEL min. NL avg. NL max. NL Value min.NL, avg.NL and max.NL in mV. see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 105 of 184 H60700-3e-ID-B.doc...

  • Page 106: 0X6E] Reader Diagnostic

    (Firmware status) DATA: Response for Reader Diagnostic Modes MODE = 0x01: FLAGS A FLAGS B FLAGS A: Bit: Function: TEMP- TEMP- > < SYNC RF-HW CONTROL ALARM WARN FLAGS B: Bit: Function: FEIG ELECTRONIC GmbH Page 106 of 184 H60700-3e-ID-B.doc...
  • Page 107 Reader Reader power up power up Note: Status != OK (b1) will be set if the multiplexer sends an error status or if there is no response from the multiplexer. FEIG ELECTRONIC GmbH Page 107 of 184 H60700-3e-ID-B.doc...
  • Page 108 Error during the communication with EEPROM Dev 2 RF-Decoder: Error during the communication with RF-Decoder Note: Should be used if status 0x10 “ EEPROM-Failure ” appears. See: ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 108 of 184 H60700-3e-ID-B.doc...
  • Page 109 W r o n g r m w a Explanation: The FPGA Firmware doesn‟t fit to the RFC Firmware. Note: Should be used if status 0x18 “Wrong Firmware” appears. See: ANNEX D: of Status Bytes FEIG ELECTRONIC GmbH Page 109 of 184 H60700-3e-ID-B.doc...

  • Page 110: 0X72] Set Output

    Defines the number of output records. OUT-NR: Defines the Type and the number of the output Bit: Function: OUT- OUT-Number type OUT-type: Digital Output Relay see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 110 of 184 H60700-3e-ID-B.doc...
  • Page 111 In order to reset a continuously active time, OUT-TIME = 1 has to be sent to the Reader, which effects a change to the idle status after 100 ms.  The continuous activation is being set back after a reset or a power failure. FEIG ELECTRONIC GmbH Page 111 of 184 H60700-3e-ID-B.doc...

  • Page 112: Set Output Examples

    REL2 is activated for 1000ms REL3 and REL4 are unchanged OUT-N OUT-NR OUT-S OUT-TIME  0x0003 0x01 0x07 0x0005  OUT-NR OUT-S OUT-TIME 0x81 0x02 0x0002   OUT-NR OUT-S OUT-TIME 0x82 0x01 0x000A FEIG ELECTRONIC GmbH Page 112 of 184 H60700-3e-ID-B.doc...

  • Page 113: 0X74] Get Input

     A Reader-Login with wrong READER-ID cause a "Logout".  A "Logout" can be effected via the command 6.3. [0x63] RF Controller Reset. see ANNEX D: Index of Status Bytes see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 113 of 184 H60700-3e-ID-B.doc...

  • Page 114: Protocols For Iso15693 Host Commands

    7.1.11. [0x2A] Lock DSFI   7.1.12. [0x2B] Get System Information 7.1.13. [0x2C] Get Multiple Block Security Status 7.1. [0xB0] Host commands for ISO15693 Mandatory  and Optional Commands 7.2. [0xBF] ISO15693 Transparent Command  FEIG ELECTRONIC GmbH Page 114 of 184 H60700-3e-ID-B.doc...

  • Page 115: 0Xb0] Host Commands For Iso15693 Mandatory And Optional Commands

    RESPONSE-DATA: Command specific response Notes:  Data is only transferred if STATUS = 0x00, 0x83, 0x94, 0x95.  This commands aren‟t available if Scan-Mode, Buffered Read Mode or Notification Mode is active. FEIG ELECTRONIC GmbH Page 115 of 184 H60700-3e-ID-B.doc...

  • Page 116: 0X01] Inventory

    Repeated DATA-SETS times RESPONSE-DATA ( I-CODE EPC) 7...14 (18) DATA-SETS TR-TYPE Repeated DATA-SETS times RESPONSE-DATA ( I-Code UID) 7...25 DATA-SETS TR-TYPE (14 byte data bytes + 5 byte UID) Repeated DATA-SETS times FEIG ELECTRONIC GmbH Page 116 of 184 H60700-3e-ID-B.doc...
  • Page 117 For I-Code EPC Transponders: 8 or 12 Bytes of the I-Code EPC are transmitted, dependent on the I-Code EPC Transponder type. TagID: 4 byte serial number. FRF Data: 12 byte Fast Read Field. IDD: Identifier Data of the Transponder. FEIG ELECTRONIC GmbH Page 117 of 184 H60700-3e-ID-B.doc...
  • Page 118  STATUS Byte 0x94 (More Data) is displayed dependent on the Tag type: Tr-Type ISO15693 I-Code EPC 96 I-Code UID Number of Transponder > 50 > 38 > 25 triggering status 0x94 FEIG ELECTRONIC GmbH Page 118 of 184 H60700-3e-ID-B.doc...

  • Page 119: 0X02] Stay Quiet

    This command sets one Transponder to Quiet State. REQUEST-DATA 6-13 0x02 MODE MODE: Bit: Function ADR: b001 addressed UID: Read only UID of the Transponder. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 119 of 184 H60700-3e-ID-B.doc...

  • Page 120: 0X22] Lock Multiple Blocks

    Number of data blocks to be locked, starting at DB-ADR. The maximum number of DB-N is ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. DB-ADR-E: Block number where the error occurred. FEIG ELECTRONIC GmbH Page 120 of 184 H60700-3e-ID-B.doc...

  • Page 121: 0X23] Read Multiple Blocks

    (TX-BUF - 10 )/(DB-Size+1) e.g. Block size 4 (DB-N = (512 – 10) / (4+1) = 100). ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. FEIG ELECTRONIC GmbH Page 121 of 184 H60700-3e-ID-B.doc...
  • Page 122  If a Transponder does not support Read Multiple Blocks commands several Read Single Block commands are used for this Transponder.  Only one Transponder can be read in the non-addressed mode. FEIG ELECTRONIC GmbH Page 122 of 184 H60700-3e-ID-B.doc...

  • Page 123: 0X24] Write Multiple Blocks

    Number of bytes of one data block. This value depends on the specification of the Trans- ponder manufacturer, see chapter 7.3. Supported ISO15693 Host commands for ISO15693 Transponders. DB-SIZE must be 1 for the I-CODE EPC UID Transponder. FEIG ELECTRONIC GmbH Page 123 of 184 H60700-3e-ID-B.doc...
  • Page 124  A write command on I-Code UID and EPC Transponders can only be performed in the non- addressed mode whereas the block-size (DB-SIZE) must be 1 Byte.  If an I-Code UID and EPC Transponder is already locked, the reader answers with status = [0x03]. FEIG ELECTRONIC GmbH Page 124 of 184 H60700-3e-ID-B.doc...

  • Page 125: 0X25] Select

    Read-only UID of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 125 of 184 H60700-3e-ID-B.doc...

  • Page 126: 0X26] Reset To Ready

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 126 of 184 H60700-3e-ID-B.doc...

  • Page 127: 0X27] Write Afi

    Application Family Identifier of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 127 of 184 H60700-3e-ID-B.doc...

  • Page 128: 0X28] Lock Afi

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 128 of 184 H60700-3e-ID-B.doc...

  • Page 129: 0X29] Write Dsfid

    Data Storage Format Identifier of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 129 of 184 H60700-3e-ID-B.doc...

  • Page 130: 0X2A] Lock Dsfid

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note:  This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 130 of 184 H60700-3e-ID-B.doc...

  • Page 131: 0X2B] Get System Information

    The LSB (32bits) from the Read only Serial Number of the Transponder. AFI: Application Family Identifier. If not supported by the Transponder, this value will return 0x00. Manufacturer Code: Manufacturer specific code (see: ANNEX A: Codes of Transponder Types) FEIG ELECTRONIC GmbH Page 131 of 184 H60700-3e-ID-B.doc...
  • Page 132 IC reference (version) of the Transponder. If not supported by the Transponder, this value will return 0x00. Chip Version: Chip version of the Transponder Note: This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 132 of 184 H60700-3e-ID-B.doc...

  • Page 133: 0X2C] Get Multiple Block Security Status

    The maximum number of DB-N is 255. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. SEC-STATUS: Block security status . Note: This command is only available for ISO15693 Transponders FEIG ELECTRONIC GmbH Page 133 of 184 H60700-3e-ID-B.doc...

  • Page 134: 0Xbf] Iso15693 Transparent Command

    302s. If there is no response within 20ms the command sends back Status “no Transponder” 0x01 b011 = write request with Option “1” The Reader tries to sample the response after CMD-RES-DELAY. If there see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 134 of 184 H60700-3e-ID-B.doc...
  • Page 135 Reader should code the data in the RF forward link and decode the data in the RF return link. TxCRCEn: A CRC is calculated over the transmitted data and the CRC byte(s) are appended to the data stream No CRC is inserted/transmitted FEIG ELECTRONIC GmbH Page 135 of 184 H60700-3e-ID-B.doc...
  • Page 136  The response data always contains the in RSP-LENGTH defined number of data bytes. Note:  This command is only available for ISO15693 Transponders.  This command is not available if the Scan Mode or Buffered Read Mode is switched on. FEIG ELECTRONIC GmbH Page 136 of 184 H60700-3e-ID-B.doc...

  • Page 137: Supported Iso15693 Host Commands

    “CFG4 Transponder Parameters” is set to “b10: Multiple Read“. The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “CFG4 Transponder Parameters” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 137 of 184 H60700-3e-ID-B.doc...

  • Page 138: Em Microelectronics (Em4135)

    Get Multiple Block Security 0x2C Status The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 138 of 184 H60700-3e-ID-B.doc...

  • Page 139: Fujitsu (Mb89R116)

    “00: automatically set” in “CFG4 Transponder Parameters”. Up to two blocks of data can be written for one request.  10% Modulation ASK SUB-CARRIER and Datacoding 1 of 4 must be configured in the read- FEIG ELECTRONIC GmbH Page 139 of 184 H60700-3e-ID-B.doc...

  • Page 140: Fujitsu (Mb89R118)

    “00: automatically set” in “CFG4 Transponder Parameters”. Up to two blocks of data can be written for one request.  10% Modulation and ASK SUB-CARRIER and Datacoding 1 of 4 must be configured in the reader. FEIG ELECTRONIC GmbH Page 140 of 184 H60700-3e-ID-B.doc...

  • Page 141: Fujitsu (Mb89R119)

    “00: automatically set” in “CFG4 Transponder Parameters”. Up to two blocks of data can be written for one request.  ASK SUB-CARRIER and Datacoding 1 of 4 must be configured in the reader. FEIG ELECTRONIC GmbH Page 141 of 184 H60700-3e-ID-B.doc...

  • Page 142: Infineon (My-D Page Mode) 0X60

    “ CFG4 Transponder Parameters ” is set to “b00: automatically set” The user has to take the Custom Specific Commands Read [0x10], Write [0x30] and the Write Byte [0x90]. The commands will be not used automatically by the Reader. FEIG ELECTRONIC GmbH Page 142 of 184 H60700-3e-ID-B.doc...

  • Page 143: Infineon (Iso Address Mode) 0Xe0

      0x2C Status  The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “b00: automatically set” FEIG ELECTRONIC GmbH Page 143 of 184 H60700-3e-ID-B.doc...

  • Page 144: Infineon (My-D Light)

    “ CFG4 Transponder Parameters ” is set to “b00: automatically set”. Reading of one block in non addressed mode is only possible, if parameter “Read Mode” in “CFG4 Transponder Parameters” is set to “b01: Single Read“. FEIG ELECTRONIC GmbH Page 144 of 184 H60700-3e-ID-B.doc...

  • Page 145: Nxp (I-Code Sli)

       Status  The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 145 of 184 H60700-3e-ID-B.doc...

  • Page 146: Nxp (I-Code Sli-S)

    “ CFG4 Transponder Parameters ” is set to “00: automatically set”. Reading of one block in non addressed mode is only possible, if parameter “Read Mode” in “CFG4 Transponder Parameters” is set to “b01: Single Read“. FEIG ELECTRONIC GmbH Page 146 of 184 H60700-3e-ID-B.doc...

  • Page 147: Nxp (I-Code Sli-L)

    “ CFG4 Transponder Parameters ” is set to “00: automatically set”. Reading of one block in non addressed mode is only possible, if parameter “Read Mode” in “CFG4 Transponder Parameters” is set to “b01: Single Read“. FEIG ELECTRONIC GmbH Page 147 of 184 H60700-3e-ID-B.doc...

  • Page 148: Stmicroelectronics (Lri512)

    Get Multiple Block Security Status  The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 148 of 184 H60700-3e-ID-B.doc...

  • Page 149: Stmicroelectronics (Lri64)

    Get Multiple Block Security Status  The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 149 of 184 H60700-3e-ID-B.doc...

  • Page 150: Stmicroelectronics (Lri2K, Lris2K)

        Status The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 150 of 184 H60700-3e-ID-B.doc...

  • Page 151: Texas Instruments (Tag-It Hfi Pro / Standard)

    WR-OPTION = 1 ** 0x25 Select 0x26 Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information 0x2C Get Multiple Block Security Status FEIG ELECTRONIC GmbH Page 151 of 184 H60700-3e-ID-B.doc...
  • Page 152 The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION para- meter in “ CFG4 Transponder Parameters ” is set to “00: automatically set”. When using the “non-addressed” mode the WR-OPTION must be set manually to “WR- OPTION = 1”. FEIG ELECTRONIC GmbH Page 152 of 184 H60700-3e-ID-B.doc...

  • Page 153: Texas Instruments (Tag-It Hfi Plus)

    0xAC Inventory Get Multiple Block  Security Status 0xA2 Write 2 Blocks     WR-OPTION = 1 ** 0xA3 Lock 2 Blocks     WR-OPTION = 1 ** FEIG ELECTRONIC GmbH Page 153 of 184 H60700-3e-ID-B.doc...
  • Page 154 This will only become an effect if the block address starts with an even- numbered address.  In the case of writing / locking an odd number of blocks the “Write_2_Blocks”/“Lock_2_Blocks” command will be combined with the “write single Block”/ “Lock single Block” command. FEIG ELECTRONIC GmbH Page 154 of 184 H60700-3e-ID-B.doc...

  • Page 155: Supported Iso15693 Host Commands For Non Iso15693 Transponders

    Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information Get Multiple Block Security 0x2C Status 0xA0 Read Config Block 0xA1 Write Config Block FEIG ELECTRONIC GmbH Page 155 of 184 H60700-3e-ID-B.doc...

  • Page 156: Nxp I-Code Uid Transponders

    Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information Get Multiple Block Security 0x2C Status 0xA0 Read Config Block 0xA1 Write Config Block FEIG ELECTRONIC GmbH Page 156 of 184 H60700-3e-ID-B.doc...

  • Page 157: Nxp I-Code 1 Transponders

    Get System Information Get Multiple Block Security 0x2C Status   0xA0 Read Config Block   0xA1 Write Config Block Note: Read Multiple Blocks cannot be used with the option including Security Status. FEIG ELECTRONIC GmbH Page 157 of 184 H60700-3e-ID-B.doc...

  • Page 158: Protocols For Buffered Read Mode And Notification Mode

    Host is able to do other jobs e.g. to communicate with other Readers Additional information about the capacity of the data buffer can be determined with the 8.5. [0x31] Read Data Buffer Info command. FEIG ELECTRONIC GmbH Page 158 of 184 H60700-3e-ID-B.doc...

  • Page 159: The Notification Mode Procedure

    As an additional option Keepalive messages can be sent periodically to a host. Keepalive notifications are never acknowledged. The information sent by a Keepalive notification is identical with the com- mand 6.9. [0x6E] Reader Diagnostic with mode = 0x01. FEIG ELECTRONIC GmbH Page 159 of 184 H60700-3e-ID-B.doc...

  • Page 160: Transponder Access In The Buffered Read Mode And Notification Mode

    The anticollision procedure can be configured in the configuration block 4.6. CFG5: Anticollision. After power up or a 6.3. [0x63] RF Controller Reset command the buffered read mode starts with transponder reading. FEIG ELECTRONIC GmbH Page 160 of 184 H60700-3e-ID-B.doc...

  • Page 161: 0X22] Read Buffer

    ExFlag = Extension flag, if b1= TR-DATA2 will be send TR-DATA2: Selects the data types for read operation. Bit: Function no Input will be stored Inputs will be stored see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 161 of 184 H60700-3e-ID-B.doc...
  • Page 162 Transponder is read will by set in the bit field. Bit: Function ANT8 ANT7 ANT6 ANT5 ANT4 ANT3 ANT2 ANT1 ANT1...8 this antenna has not read transponder data this antenna has read transponder data FEIG ELECTRONIC GmbH Page 162 of 184 H60700-3e-ID-B.doc...
  • Page 163  Every time if the trigger starts and stops a data set will be stored. All data will be set to 0x00, only the Input values “IN” and “STATUS” and “Date” and “Time” will be set. FEIG ELECTRONIC GmbH Page 163 of 184...

  • Page 164: 0X31] Read Data Buffer Info

    Number of Transponder data sets reserved in the data buffer. Notes:  Additional information about the data table status is transferred if STATUS = 0x00, 0x84, 0x85, 0x93. see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 164 of 184 H60700-3e-ID-B.doc...

  • Page 165: 0X32] Clear Data Buffer

    The command Initialize Buffer clears the data buffer to an initial state. It does not matter if the data sets in the data buffer were read or not. Host  Reader 4...5 COM-ADR [0x33] CRC16 Host  Reader 5...6 COM-ADR [0x33] STATUS CRC16 see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 165 of 184 H60700-3e-ID-B.doc...

  • Page 166: 0X34] Force Notify Trigger

    This command forces a notification, if the buffered read mode and the notification mode are enabled 4.2. CFG1: Interface configuration block. Host  Reader 5...6 COM-ADR [0x34] MODE CRC16 Host  Reader 5...6 COM-ADR [0x34] STATUS CRC16 MODE: Reserved for future use. Send always 0x00. FEIG ELECTRONIC GmbH Page 166 of 184 H60700-3e-ID-B.doc...

  • Page 167: Annex

    ANNEX A: Codes of Transponder Types Value Transponder type 0x01 I-Code 1 0x03 ISO15693 Tags 0x06 NXP I-Code EPC 0x07 NXP I-Code UID The Information will be send by performing the 7.1.1. [0x01] Inventory command. FEIG ELECTRONIC GmbH Page 167 of 184 H60700-3e-ID-B.doc...

  • Page 168: Annex B: Time Behavior Of The Asynchronous Interface

    1 Block (16 Bytes) all ( 8 ) Blocks 6.6. [0x69] RF Reset 7.1. [0xB0] Host com- mands for ISO15693 Man- datory and Optional Com- mands as configured in 4.2. CFG1: Interface TR-RESPONSE-TIME FEIG ELECTRONIC GmbH Page 168 of 184 H60700-3e-ID-B.doc...

  • Page 169: Annex C: Time Behavior Of Iso15693 Host Commands

    The extent of the data that needs to be read or written  Types of Transponders supported by the Reader,  Position of the Transponder at the time of the requirement,  Probable local electromagnetic interferences present. FEIG ELECTRONIC GmbH Page 169 of 184 H60700-3e-ID-B.doc...

  • Page 170: Time Behaviour For [0X01] Inventory And Iso15693 Transponders

    The timing is measured inclusive of the communication time at 38,4Kbaud. A modified baud rate will slightly increase the timing but the Inventory timing is mostly determine by the anticollision so you may neglect the communication time. Execution time Communication time FEIG ELECTRONIC GmbH Page 170 of 184 H60700-3e-ID-B.doc...

  • Page 171: Annex D: Index Of Status Bytes

    The address is beyond the configured address space of the Transponder. 0x05 Wrong Transponder-type: This command is not applicable at the Transponder:  Attempt to write on or read from a Transponder.  A special command is not applicable to the Transponder. FEIG ELECTRONIC GmbH Page 171 of 184 H60700-3e-ID-B.doc...
  • Page 172 1. Read the Device-ID using the command [0x66] Firmware version (Mode 0x80) 2. Send the Device-ID and the serial number of the reader to Feig Electronic 3. Write the upgrade code into the reader using the command [0x5F] Set Firmware Update...
  • Page 173 The specified block was not successfully programmed 0x14 The specified block was not successfully locked 0xA0 - 0xDF Custom command error codes all others reserved for future use see 4.12. CFG11: Read Mode FEIG ELECTRONIC GmbH Page 173 of 184 H60700-3e-ID-B.doc...

  • Page 174: Annex E: Codes Of Reader Types

    ID ISC.MR101-U ID CPR.M02 ID CPR.02 ID CPR40.30-Ux ID CPR40.0x-Ax / -Cx ID CPR.M03 (586/#) ID CPR.03 (584/#) ID CPR30 ID CPR.52 ID CPR.04-U ID ISC.LRU1000 ID ISC.LRU2000 ID ISC.LRU3000 ID MAX50 FEIG ELECTRONIC GmbH Page 174 of 184 H60700-3e-ID-B.doc...

  • Page 175: Annex F: Examples For Read Data

    The setting "LSB first" and "MSB first" gives the direction of the received data bytes ISO15693 Host Command (DB-Size of the Transponder = 4 bytes) ISO15693 Host Command (DB-Size of the Transponder = 8 bytes) FEIG ELECTRONIC GmbH Page 175 of 184 H60700-3e-ID-B.doc...

  • Page 176: Annex F: Labeling Of Configuration Parameter

    AccessProtection.Lock_CFG19 CFG_ACCESS AccessProtection.Lock_CFG20 CFG_ACCESS AccessProtection.Lock_CFG21 CFG_ACCESS AccessProtection.Lock_CFG22_29 CFG_ACCESS AccessProtection.Lock_CFG30_39 CFG_ACCESS AccessProtection.Lock_CFG40_49 COM-ADR HostInterface.Serial.BusAddress BAUD HostInterface.Serial.Baudrate TRANS-FORM (P) HostInterface.Serial.Parity TRANS-FORM (D) HostInterface.Serial.Databits TRANS-FORM (S) HostInterface.Serial.Stopbits TR-RESPONSE-TIME AirInterface.TimeLimit PROTOCOL-SELECTION HostInterface.Miscellaneous.ProtocolSelection SCAN-INTERFACE OperatingMode.ScanMode.Interface INTERFACE HostInterface.Interfaces FEIG ELECTRONIC GmbH Page 176 of 184 H60700-3e-ID-B.doc...
  • Page 177 ISO 15693 MODE (DATACODING) Transponder.HF.ISO_15693.LinkRate.DataCoding ISO 15693 MODE (NO-TS) Transponder.HF.ISO_15693.Anticollision.NoOfTimeslots ISO 15693 MODE (AFI) Transponder.HF.ISO_15693.SelectionMask.Enable_AFI ISO 15693 AFI1 Transponder.HF.ISO_15693.SelectionMask.AFI1 ISO 15693 OPTION (WR-OPTION) Transponder.HF.ISO_15693.Miscellaneous.WriteOption ISO-CMD-OPTION (BREAK) Transponder.HF.ISO_15693.Miscellaneous.CommandBreak ISO 15693 AFI2 Transponder.HF.ISO_15693.SelectionMask.AFI2 ISO 15693 AFI3 Transponder.HF.ISO_15693.SelectionMask.AFI3 FEIG ELECTRONIC GmbH Page 177 of 184 H60700-3e-ID-B.doc...
  • Page 178 Relay2_AE (Relay2 assignment to DigitalIO.Relay.No2.ReadEventActivation.AntennaNo antenna read event) Relay3_AE (Relay3 assignment to DigitalIO.Relay.No3.ReadEventActivation.AntennaNo antenna read event) Relay4_AE (Relay4 assignment to DigitalIO.Relay.No4.ReadEventActivation.AntennaNo antenna read event) AFI Assignment DigitalIO.Miscellaneous.AFIAssignment TRIGGER_MODE (Unlimited Valid OperatingMode.ScanMode.Trigger. Time) Enable_UnlimitTransponderValidTime FEIG ELECTRONIC GmbH Page 178 of 184 H60700-3e-ID-B.doc...
  • Page 179 HOLD-TIME) Input.No1.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.ScanMode.Trigger.Source. HOLD-TIME) Input.No2.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.NotificationMode.Trigger.Source. HOLD-TIME) Input.No2.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.BufferedReadMode.Trigger.Source. HOLD-TIME) Input.No2.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.ScanMode.Trigger.Source. HOLD-TIME) Input.No3.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.NotificationMode.Trigger.Source. HOLD-TIME) Input.No3.HoldTime TRIGGER-USE (TRIGGER_X- OperatingMode.BufferedReadMode.Trigger.Source. HOLD-TIME) Input.No3.HoldTime FEIG ELECTRONIC GmbH Page 179 of 184 H60700-3e-ID-B.doc...
  • Page 180 OperatingMode.ScanMode.DataSelector.Selector TR-DATA OperatingMode.NotificationMode.DataSelector.Selector TR-DATA OperatingMode.BufferedReadMode.DataSelector.Selector TR-DATA-2 (IN) OperatingMode.ScanMode.DataSelector.InputEvents TR-DATA-2 (IN) OperatingMode.NotificationMode.DataSelector.InputEvents TR-DATA-2 (IN) OperatingMode.BufferedReadMode.DataSelector.InputEvents TR-DATA-3 (COM Prefix) OperatingMode.ScanMode.DataFormat.BusAddressPrefix TR-DATA-3 (ANT-STORE) OperatingMode.ScanMode.DataSelector.Mode. Enable_AntennaPool TR-DATA-3 (ANT-STORE) OperatingMode.NotificationMode.DataSelector. Mode.Enable_AntennaPool TR-DATA-3 (ANT-STORE) OperatingMode.BufferedReadMode.DataSelector. Mode.Enable_AntennaPool DB-ADR OperatingMode.ScanMode.DataSource.FirstDataBlock FEIG ELECTRONIC GmbH Page 180 of 184 H60700-3e-ID-B.doc...
  • Page 181 IN-EV-FLT (Input 2) OperatingMode.NotificationMode.Filter. Enable_Input2Event IN-EV-FLT (Input 2) OperatingMode.BufferedReadMode.Filter. Enable_Input2Event IN-EV-FLT (Input 3) OperatingMode.ScanMode.Filter.Enable_Input3Event IN-EV-FLT (Input 3) OperatingMode.NotificationMode.Filter. Enable_Input3Event IN-EV-FLT (Input 3) OperatingMode.BufferedReadMode.Filter. Enable_Input3Event IN-EV-FLT (Input 4) OperatingMode.ScanMode.Filter. Enable_Input4Event IN-EV-FLT (Input 4) OperatingMode.NotificationMode.Filter. FEIG ELECTRONIC GmbH Page 181 of 184 H60700-3e-ID-B.doc...
  • Page 182 MUX-MODE (MUX Switch Condition) AirInterface.Multiplexer.HF.External.SwitchCondition OUTPUT-CHANNELS AirInterface.Multiplexer.HF.External.NoOfOutputChannels MUX-VALID-TIME-ANT_1 AirInterface.Multiplexer.HF.External.Antenna.No1.ActiveTime MUX-VALID-TIME-ANT_2 AirInterface.Multiplexer.HF.External.Antenna.No2.ActiveTime MUX-VALID-TIME-ANT_3 AirInterface.Multiplexer.HF.External.Antenna.No3.ActiveTime MUX-VALID-TIME-ANT_4 AirInterface.Multiplexer.HF.External.Antenna.No4.ActiveTime MUX-VALID-TIME-ANT_5 AirInterface.Multiplexer.HF.External.Antenna.No5.ActiveTime INPUT-CHANNELS AirInterface.Multiplexer.HF.External.InputChannelMode PER-RESET-TIME Transponder.PersistenceReset.Antenna.No1. PersistenceResetTime MUX-VALID-TIME-ANT_6 AirInterface.Multiplexer.HF.External.Antenna.No6.ActiveTime MUX-VALID-TIME-ANT_7 AirInterface.Multiplexer.HF.External.Antenna.No7.ActiveTime MUX-VALID-TIME-ANT_8 AirInterface.Multiplexer.HF.External.Antenna.No8.ActiveTime SYNC (MODE) OperatingMode.Miscellaneous.HF.ReaderSynchronization. Enable_Synchronization SYNC (MASTER) OperatingMode.Miscellaneous.HF.ReaderSynchronization. Is_Master FEIG ELECTRONIC GmbH Page 182 of 184 H60700-3e-ID-B.doc...
  • Page 183 HostInterface.WLAN.Keepalive.Enable KEEP-CNT HostInterface.WLAN.Keepalive.RetransmissionCount GW-ADDRESS-WLAN HostInterface.WLAN.IPv4.GatewayAddress KEEP-IDLE HostInterface.WLAN.Keepalive.IdleTime KEEP-INTERVAL HostInterface.WLAN.Keepalive.IntervalTime SEC-MODE (WEP) HostInterface.WLAN.Security.WEP.KeyLength SEC-MODE (SSID) HostInterface.WLAN.Security.ServiceSetIdentifier.Enable SEC-MODE (Authentication Type) HostInterface.WLAN.Security.AuthenticationType SSID-LEN HostInterface.WLAN.Security.ServiceSetIdentifier.Length SSID HostInterface.WLAN.Security.ServiceSetIdentifier.SSID WEP_KEY HostInterface.WLAN.Security.WEP.Key MODE (DATA-TRIGGER) OperatingMode.NotificationMode.Transmission. NotifyTrigger MODE (ACK) OperatingMode.NotificationMode.Transmission. FEIG ELECTRONIC GmbH Page 183 of 184 H60700-3e-ID-B.doc...
  • Page 184  System-Manual ID ISC.LR2000 OBID i-scan Enable_Acknowledge TIME-TRIGGERED-TIME OperatingMode.NotificationMode.Transmission. TimeTriggeredTime DATA-SETS-LIMIT OperatingMode.NotificationMode.Transmission. DataSetsLimit KEEP-ALIVE (EN) OperatingMode.NotificationMode.Transmission. KeepAlive.Enable KEEP-ALIVE-TIME OperatingMode.NotificationMode.Transmission. KeepAlive.IntervalTime DEST-IP-ADDRESS OperatingMode.NotificationMode.Transmission. Destination.IPv4.IPAddress DEST-IP-PORT-NUMBER OperatingMode.NotificationMode.Transmission. Destination.PortNumber HOLD-Time OperatingMode.NotificationMode.Transmission. Destination.ConnectionHoldTime FEIG ELECTRONIC GmbH Page 184 of 184 H60700-3e-ID-B.doc...
