Zenith HydroTap G4 Series User Manual

Hide thumbs

Advertisement

Quick Links

Zenith HydroTap G4
User Guide
Tap Operation .................. Pages 3-10
•
•
Maintenance .................... Pages 24-25
•
Home Menu Icons ........... Page 26
•
Cleaning ........................... Page 27
•
Contact Details ................ Page 28
•
Date of Installation............../.........../..........
802254NZ - HT BC User Guide 10.18 v3.02
HydroTap BC100/75
HydroTap BC160/125
HydroTap BC160/175
HydroTap BC240/175
HydroTap Residential
Affix Model Number
Label Here
802254NZ
®
Page 1 of 28

Advertisement

loading
Need help?

Need help?

Do you have a question about the HydroTap G4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenith HydroTap G4 Series

Summary of Contents for Zenith HydroTap G4 Series

  • Page 1: Table Of Contents

    Zenith HydroTap G4 ® User Guide Tap Operation ....Pages 3-10 • LCD Screen & Menu ..Pages 11-23 • Maintenance ....Pages 24-25 • Home Menu Icons ... Page 26 • Cleaning ......Page 27 • Contact Details ....Page 28 •...
  • Page 2 ** This user manual has been written according to firmware version B02.6.8 Please check the following website for the latest user manual: zenithwater.co.nz BC Residential BC100/75 BC160/125 BC160/175 BC240/175 Page 2 of 28 802254NZ - HT BC User Guide 10.18 v3.02...
  • Page 3 Tap Safety Lock The safety lock feature is provided to prevent boiling water flowing if the hot lever is inadvertently operated. This function can be activated and deactivated from either the Tap or from the touch screen display (Located on the unit in the cupboard). (Classic &...
  • Page 4 Tap functions Classic Tap: Boiling Button Chilled Button The Classic tap uses lever control to dispense Boiling and Chilled Safety Lock water. The safety lock can be controlled from either the tap or from the touch screen display (see page 3). Elite Tap: Boiling Button Chilled Button...
  • Page 5 Tap functions Celsius All-In-One Tap: The Celsius AIO combines the tap functions of the Arc/Cube tap and the Classic Mixer tap. Please see AIO tap and Arc/Cube tap functions for the Celsius AIO. Classic All-In-One Tap: The top levers and safety lock button of the Classic AIO tap are operated in the same way as a Classic HydroTap to dispense...
  • Page 6 Tap functions HydroTap Arc/Cube and Celsius AIO: Tapping the select button will allow the choice of Boiling (RED) with safety, Chilled (BLUE) or Sparkling (WHITE) water mode. The Arc/Cube control may be rotated in a forward or reverse direction to dispense Boiling or Chilled water.

  • Page 7: Tap Operation

    Tap operation To dispense Chilled water: HydroTap Classic and Press or pull lever Classic All-In-One taps Depress the “Blue” lever to dispense Chilled water. Pulling forward the Blue lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (this is user adjustable).
  • Page 8 Tap operation To dispense Boiling water: (WITH SAFETY ON) HydroTap Classic: Depress the Red lever, while simultaneously covering the safety lock button with a second finger. These two actions need to occur simultaneously within 2 seconds for the successful dispensing of boiling water. Elite Tap: Place one finger on the safety lock, then touch the boiling button with a second finger while keeping both fingers in position.
  • Page 9 Tap lights Red Lights Blue Lights Red Boiling Water Light: (All) On all the time: This indicates that the boiling water is ready. Flashing slowly: This indicates that the boiling water is below the desired temperature. Wait for the light to stop flashing before dispensing water.
  • Page 10 Filter Lights Filter light: Classic & Elite Filter Light Filter Light Off: This indicates the filter is operating within its normal specified lifespan. Filter Change light flashing slowly: The light will flash slowly when the filter is due for replacement and the LCD will show “Filter Change”.
  • Page 11 To check the calibration, dispense Boiling water, in normal light conditions with the safety enabled. LCD Screen Zenith HydroTap has a ‘TOUCH’ screen for easy setup and operation adjust- ment. See page 26 for icon details. Other possible messages in status window:...

  • Page 12: Lcd Screen Menu

    LCD Screen Menu Main Sub Menu Sub Menu Options Section Menu • English Lan- guage • Deutsch • Product Info • System Faults • Product serial no. • Filter Log • Lists Info • Recent Fault Log • Energy • Filter Flush •...
  • Page 13 LCD Screen operation - Section A Set Language 1. Press [MENU] for main menu. 2. Press [Language] button. 3. Select the country to change the language 4. Press [<=] button for the previous menu LCD Screen operation - Section B System Information In this section, you can find your product serial number, check system fault messages or view the event logs of your product.
  • Page 14 [Home] to return to the home screen. LCD Screen operation - Section C Install Once your Zenith HydroTap G4 unit has been installed, use the Install menu to configure the system settings for your product. Sub menu: Boiling Chilled 1.
  • Page 15 NOTE: Occasionally the system will vent steam from the tap. This is normal operation as HydroTaps are programmed to re-calibrate at regular intervals. On start up, the Zenith HydroTap starts a self-calibration program. Once complete, the system reverts back to normal operation. If you would like to calibrate the system anytime after initial installation, please follow the steps below.
  • Page 16 LCD Screen operation - Section C 4. - Booster This function should only be considered when a Booster unit is installed. 1. Press the [MENU] button for main Boiling Chilled menu. 2. Press the [Install] button. 3. Press the [Booster] button. 4.
  • Page 17 LCD Screen operation - Section C 7. - Advanced options (Residential Only) Pump anti cavitation mode: This feature sends two electric pulses every 5minutes to the pump. This prevents the build up of air bubbles inside the pump and ensures an even flow of hot water at the tap.
  • Page 18 Service This section is reserved for service technicians only Note : In New Zealand call a licensed electrician, plumber, or Zenith free call on 0800 558 055, for assistance, service, spare parts, or enquiries. LCD Screen operation - Section E...
  • Page 19 Home screen. Set Temperature Zenith HydroTaps are designed to operate within 1ºC to 2ºC of set point for boiling water and between 6ºC to 10ºC for chilled drinking water. All boiling water units are self calibrating to 98ºC, which is the recommended setting.
  • Page 20 LCD Screen operation - Section G Filter Zenith HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
  • Page 21 LCD Screen operation - Section G Energy Modes This mode allows the HydroTap to Go into Energy Saving mode. There are two options available: ‘Sleep’ mode and ‘ON/OFF’ mode. In Sleep Mode the unit will Go to “Sleep” after a 2hr period of inactivity. The Boiling water will gradually drop to either 68°C or room temp, as shown in the table below and the Chilled water will be ON or OFF.
  • Page 22 LCD Screen operation - Section G Note: Any attempt, during OFF mode, to dispense water, will bring the unit out of sleep mode. The unit will return to sleep mode after 2 hours of non use. Please allow sufficient time for the water to reach the set temperature after disabling the sleep mode.
  • Page 23 LCD Screen operation - Section G Safety When the Safety Lock is enabled, the Safety Lock button must be used, in addition to tap controls, in order to dispense Boiling water. To allow Safety Setting change: • Press [MENU], [Settings], [Safety]. •...

  • Page 24: Maintenance

    Filter Maintenance Water Filter The Zenith HydroTap notifies when filter replacement is due. If you notice one of the following, you will need to change the filter: • The Change Filter light will flash white once a second, until reset.
  • Page 25 PULL DOWN Air Inlet Filter The Zenith HydroTap air filter is conveniently located on the outside of the condenser. The filter screen is a sliding fit in the plastic housing on the right hands side of the under sink unit. The screen may be removed for cleaning, by sliding it forward.

  • Page 26: Home Menu Icons

    Home Menu Icons Safety switch is LOCKED. The HydroTap will not dispense any Boiling water. See page 3 for safety switch operation Safety switch is UNLOCKED. Boiling water may be dispensed. See page 8 for tap operation details Sleep mode is active. There are 7 sleep mode options which display this icon on the home screen.

  • Page 27: Cleaning

    Cleaning General cleaning Do not use strong, corrosive, spray or abrasive cleaners. Clean with a soft damp cloth and mild soap. Under sink units must never be located near, or cleaned with water jets. Avoid using airborne pesticides near the undersink unit. Tap cleaning Do not use strong, corrosive, spray or abrasive cleaners.

  • Page 28: Contact Details

    Telephone +(64 9) 838 8612 Free Call 0800 558 055 As Zenith policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
