HydroTap G4
User Guide
Tap Operation...................(Pages 2-6)
•
•
Maintenance.................... (Page 17-19)
•
Menu Icons.......................(Page 19)
•
Date of Installation............./........./..........
Chilled
Residential
model
Affix Model Number Label
802262 - Chilled HT User Guide - 11.16 - v2.01
®
Here
802262NZ
Page 1 of 20

Advertisement

loading
Need help?

Need help?

Do you have a question about the HydroTap G4 802262NZ and is the answer not in the manual?

Questions and answers

Related Manuals for Zenith HydroTap G4 802262NZ

Summary of Contents for Zenith HydroTap G4 802262NZ

  • Page 1 HydroTap G4 ® User Guide Tap Operation....(Pages 2-6) • LCD Screen & Menu ..(Pages 7-17) • Maintenance....(Page 17-19) • Menu Icons.......(Page 19) • Date of Installation...../../..Chilled Residential model Affix Model Number Label Here 802262NZ 802262 - Chilled HT User Guide - 11.16 - v2.01 Page 1 of 20...

  • Page 2: Tap Operation

    Tap operation To dispense chilled water: Press or pull lever HydroTap Classic: Depressing the “Blue” lever allows the dispensing of chilled water. Pulling forward the Blue lever allows the tap to operate in a “no- touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable).
  • Page 3 Tap functions Elite Tap: The Elite tap uses touch sensitive controls, in lieu of levers, to dispense Chilled water. Touching any of the chilled buttons allows the dispensing of chilled water. Chilled Button Chilled Button 802262NZ - Chilled HT User Guide - 11.16 - v2.01 Page 3 of 20...
  • Page 4 Tap functions ARC & CUBE Tap: On powerup, wait 30secs. for the unit to calibrate. The Arc/ Cube control may be rotated in a forward or reverse direc- tion to dispense Chilled water. The rotary control is spring loaded in the anticlockwise direction and when released, will return to the OFF position.
  • Page 5 Tap Lights Chilled Water Light: (All) On all the time: This indicates that the temperature of the chilled water is within the set temperature range. Flashing slowly: This indicates that the chilled water is not within the set temperature range. When the chilled water is at the set temperature, the light will stop flashing.
  • Page 6 Filter light Filter Light Filter light: Filter Change Light Off: This indicates the filter is operating within its normal specified lifespan. Filter Change light flashing slowly: The light will flash slowly when the filter is due for replacement and the LCD will show “Filter Change”.
  • Page 7 LCD Screen **Status window Set chilled water temp. Filter usage Zenith HydroTap introduces a ‘TOUCH’ screen for easy setup and operation adjustment. See page 19 for icon details. Other possible messages in status window: **Status Information Notes System Fault Product has one or more system...

  • Page 8: Lcd Screen Menu

    LCD Screen Menu Main Menu Sub Menu Sub Menu Options Section • English Language • Deutsch • Product Info • Product serial • System Faults Information • Lists • Event Log • Reset options • Filter Flush • Calibration Installation •...
  • Page 9 LCD Screen operation - Section A Set Language Press [MENU] for main menu. Press [Language] button. Select the country to change the language Press [<=] button for the previous menu LCD Screen operation - Section B System Information In this section, you can find your product serial number , check system fault messages or view the event logs of your product.
  • Page 10 Position CLOSED Position The Zenith HydroTap allows the user to adjust the filter life and to edit the filter usage. (See filter details on Pages 14). Page 10 of 20 802262NZ - Chilled HT User Guide - 11.16 - v2.01...
  • Page 11 LCD Screen operation - Section D Service This section is reserved for service technicians only Note: In Australia, call a licensed electrician, plumber or Zenith office on 1800-638-633, for assistance, service, spare parts or enquiries 802262NZ - Chilled HT User Guide - 11.16 - v2.01...
  • Page 12 HydroTap unit. LCD Screen operation - Section F F Communication (when available) The Zenith HydroTap G4 allows the user to use wifi or Bluetooth to operate the product remotely. Not yet available Page 12 of 20 802262NZ - Chilled HT User Guide - 11.16 - v2.01...
  • Page 13 LCD Screen operation - Section G nstructions Settings 1. Press the [MENU] button for main menu. 2. Press the [Settings] button. 3. Press [Enable Password]. 4. Then enter your 4-digit password. You will need to enter your password to access the settings screens.
  • Page 14 LCD Screen operation - Section G ions Filter Zenith HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
  • Page 15 LCD Screen operation - Section G ions Energy Modes This mode allows the HydroTap to Go into Energy Saving mode. In Sleep Mode the unit will Go to “Sleep” after a 2hr period of inactivity. The Chilled water will be ON or OFF. When the period of inactivity passes, the home screen status window will show “Sleep Mode”.
  • Page 16 LCD Screen operation - Section G In ON / OFF Mode the user may turn the unit ON or OFF at specific times for individual days or alternatively by weekly and/or weekend settings. To activate ON/OFF mode: Press the [MENU] button for main menu.

  • Page 17: Maintenance

    Filter Maintenance Air Inlet Filter The Zenith HydroTap air filter is conveniently located on the outside of the condenser. The filter screen is a sliding fit in the plastic housing on the side of the under sink unit. The screen may be removed for cleaning, by sliding it forward.
  • Page 18 Adjust the filter settings in Section G - filter - Litres and Days used. Warning: If the Zenith HydroTap is switched off for a long period of time (e.g. More than a weekend), run water through the chilled water outlet for at least 5 minutes before consumption.

  • Page 19: Menu Icons

    Filter Maintenance REMOVE FILTER INSERT FILTER 1. INSERT 1. ROTATE 2. PULL DOWN 2. ROTATE Cleaning General cleaning Do not use strong, corrosive, spray or abrasive cleaners. Clean with a soft damp cloth and mild soap. Under sink units must never be located near, or cleaned with water jets. Avoid using air bourne pesticides near the undersink unit.
  • Page 20 Telephone: 0800 558055 Facsimile: 0800 559055 As Zenith policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
