DZ IND. 1.0 BRUSHLESS DC
DZ IND. 1.5 BRUSHLESS DC
DZ 2.0 ROBUST BRUSHLESS DC
WARNING:
Do not use the product
without fi rst reading the
instruction manual.
Technical Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PPA DZ IND. 1.0
Summary of Contents for PPA DZ IND. 1.0
- Page 1 DZ IND. 1.0 BRUSHLESS DC DZ IND. 1.5 BRUSHLESS DC DZ 2.0 ROBUST BRUSHLESS DC Technical Manual www.ppa.com.br +55 (14) 3407-1000 callcenter@ppa.com.br WARNING: Do not use the product without fi rst reading the instruction manual. MOTOPPAR INDÚSTRIA E COMÉRCIO DE AUTOMATIZADORES LTDA.
-
Page 2: Table Of Contents
INdEX EU DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY IMPORTANT SAFETY INSTRUCTIONS ..................4 Identification Number: PPA CE 001 (Revision: 01) Manufacturer: TECHNICAL CHARACTERISTICS ....................5 Company Name: MOTOPPAR INDÚSTRIA E COMÉRCIO DE AUTOMATIZADORES LTDA. Address: AV. DR LABIENO DA COSTA MACHADO, 3526 TOOLS REQUIRED FOR INSTALLATION .................. -
Page 3: Important Safety Instructions
OPERATOR TYPE Slider Slider Slider • Before installing the equipment, it is important that the specialist installer follow DZ IND. 1.0 DZ IND. 1.5 DZ 2.0 ROBUST all instructions given in this technical manual and in the user manual. MODEL... -
Page 4: Tools Required For Installation
TOOLS REQUIREd FOR INSTALLATION ELECTRICAL INSTALLATION Here are some tools required to install the operator: For electrical installation, the network shall contain the following characteristics: - 230V-50Hz power supply; The passage of the wiring must be made through conduits between: - the electrical distribution box and the total disconnect device - the total disconnect device and the operator supply terminals;... -
Page 5: Care With The Gate Before The Automation
and consequently greater wear. The circular section (Figure B) allows a better displacement of the gate and less friction for the operator. It is mandatory that the ground terminal is connected to the grounding cable network. FIGURE A FIGURE B IMPORTANT Step 3: Check wether the gate leaf does not jam in the opening and closing The electrical installation must have a residual current (RCD) - Page 6 The correct operation of this equipment depends on the instructions in this manual. To secure the equipment, proceed as follows: GATE LEAF Step 1: Make sure the floor is firm enough so that the equipment can be screwed on a level. If it does not comply with the requirement, provide a concrete base, following the guidelines in the right image:...
- Page 7 Step 8: If the gate leaf is warped, provide shims to ensure alignment of the rack. There are cases where the rack should pass the length of the gate leaf. In this case, provide a bracket so the rack teeth will not be skipped when starting the machine. INSERT 2 PARABOLTS BRACKET...
-
Page 8: Installation Analog Limit Switches
INSTALLATION OF THE ANALOG LIMIT SWITCHES Step 2: Fully open the gate and place the other magnet holder on the rack, facing forward with the operator REED. This magnet will act as an opening limit switch. Step 1: With the gate closed, place the magnet holder on the rack, positioned in front with the REED of the operator. -
Page 9: Triflex Connect Brushless Board
The Trifl ex Connect Brushless board allows all parameters to be confi gured through the PROG programmer in three languages (Portuguese, English or Spanish) or trough the mobile app BLUE (In this case, it is necessary to purchase the “BLUE” module from PPA). It can control all PPA operator models with Brushless motors. - Page 10 System Power NOTE: Before connecting the optional accessories (Electromagnetic Lock and / or Garage Light / Signal, pushbuttons and etc.), it is advisable The mains connection must be made at the L and N input of the power to carry out a general test of machine operation. To do this, simply terminal, AC connector, see figure 1.
- Page 11 2 - When the control board is in standby, with the gate open or closed, the Pushbutton Connection only for closing "CLO" motor is off. The control board then sends a command to the PPA Nobreak to turn off the power control stage and reduce the battery consumption, increasing the The board acknowledges a closing command when the CLO terminal is autonomy.
-
Page 12: Logical Function Of The System For Gates
If instead the gate starts a closing movement, remove the ‘F/R’ jumper to change the direction of the motor. After removing the jumper the gate will stop. Press NON STOP BARRIER (SPECIFIC PPA BARRIER MODEL) the ‘+’ button again or proceed with an external command. The gate should start The pause before repeating the parameter value is three seconds and the flashes opening. - Page 13 “GSS” GATE: HOW TO ADJUST THE GAP BETWEEN GATE AND ITS Programming Functions Table: (DIP 1 and 5) MECHANICAL STOP Function Description If necessary, the space between the stop and the gate can be 3 4 5 6 7 8 adjusted when the operator completes the closing or opening FUNCTION SELECTOR / RECORD OR DELETE TRANSMITTERS “_”...
- Page 14 “SF” CONFIGURING SAFETY DEVICES Obs.: The travel recognition speed is equal to the end of travel speed It reads the current state of the SFO and SFC inputs and stores the (DIP 1 e 8) if it is greater that 20Hz, if it is smaller, the board automatically uses 20 value as a safe condition.
-
Page 15: Erase The Recognized Gate Travel
at the same time and hold them down until the “OSC” LED lights up. Keep them pressed until the LED “OSC” flashes. When the buttons are released, the travel is Press the (-) button to turn off (flashing LED) the open stop function deleted and the factory settings are applied. -
Page 16: Encoder Operation Test
Open limit switch WARNING Depending on the installation, this anti-crushing system The “END” LED flashes when the gate reaches an open limit switch. Closed limit switch is not enough to comply with EN13241, EN12978 and EN12453, and to avoid accidents with people and animals, requiring the use of photocells The “END”... - Page 17 A) Inverted motor A) Check the motor wires connection B) Locked gate or B) Manually unlock the Motor blocked motor operator and check individually the gate movement and the motor operation A) Burned fuse A) Replace the fuse B) Power grid off B) Connect the power gird (power) (power)
-
Page 18: Exploded View Dz Ind 1.0 Brushless Dc
EXPLOdEd VIEW A22107 CONTROL BOARD TRIFLEX CONNECT BRUSHLESS DC 230V 50HZ DZ IND 1.0 BRUSHLESS DC C10048 E40 RETAINING RING C10254 3,9 X 9,5 PHILIPS SCREW C10278 3/8 X 2 ¾" ANCHOR BOLT C10285 E17 RETAINING RING C10771 6203 ZZ BEARING C10778 M5 X 10MM TORX SCREW C10779... -
Page 19: Exploded View Dz Ind 1.5 Brushless Dc
EXPLOdEd VIEW P04067 RACK PIECE - RESIDENTIAL LINE A22107 CONTROL BOARD TRIFLEX CONNECT BRUSHLESS DC 230V 50HZ DZ IND 1.5 BRUSHLESS DC C10048 E40 RETAINING RING C10254 3,9 X 9,5 PHILIPS SCREW C10278 3/8 X 2 ¾" ANCHOR BOLT C10285 E17 RETAINING RING C10771 6203 ZZ BEARING... -
Page 20: Exploded View Dz 2.0 Robust Brushless Dc
P04067 RACK PIECE - RESIDENTIAL LINE EXPLOdEd VIEW A16979 230V 50HZ BRUSHLESS DC STATOR A22107 CONTROL BOARD TRIFLEX CONNECT BRUSHLESS DC 230V 50HZ DZ 2.0 ROBUST BRUSHLESS DC C10048 E40 RETAINING RING C10254 3,9 X 9,5 PHILIPS SCREW C10278 3/8 X 2 ¾" ANCHOR BOLT C10285 E17 RETAINING RING C10771...
