7. Technical data

140-340
Z1
DN100
Htot
Z2
Tanks
Inhabitants 1-3 inhabitants
Max. daily inflow 0,45 m
Length L 2,080 mm
Width B 1,565 mm
Height H 1,690 / 2,010* mm
tot
Inflow Z1 430 / 750* mm
Inflow Z2 1260 mm
Outflow A1 470 / 800* mm
Outflow A2 1255 mm
* with Maxi tank dome
7. Technical data
625
DN 100
A
L
2,700 l 3,750 l
4-5 inhabitants
3
/d 0,75 m
2,280 mm
1,755 mm
1,870 / 2,200* mm
430 / 750* mm
1450 mm
470 / 800* mm
1445 mm
www.graf.info
A1
A2
4,800 l
6-7 inhabitants
3 3
/d 1,05 m /d
2,280 mm
1,985 mm
2,100 / 2,430* mm
515 / 835* mm
1595 mm
470 / 800* mm
1590 mm
22 / 33
L
6,500 l
8-9 inhabitants
3
1,35 m /d
2,390 mm
2,190 mm
2,380 / 2,710* mm
535 / 855* mm
1855 mm
470 / 800* mm
1850 mm
B
06-2018
