Case 2 – Connecting J-Link Probes to application board with IS2083BM
Figure 3-4. J-Link 6-pins connector schematic
Connect the following pins from your board to the 6pins connector:
Table 3-1. Pin details for the IS2083BM/BM83 board
J-Link 6pin Connector
Pin1
Pin2
Pin3
Pin4
Pin5
Pin6
©
2019 Microchip Technology Inc.
BM83
IS2083BM
Pin43, RST_N
RST_N
3V3
3V3_IO
Ground
Ground
Pin46, TDI_CPU
TDI_CPU
Pin47, TCK_CPU
TCK_CPU
NC
NC
User Guide
IS2083
Hardware Connection
Description
Reset IS2083BM
3V3 power
Ground
Data
Clock
Not used
DS50002892A-page 14
