- Page 1 TIP670 Digital I/O Version 1.0 Revision B User Manual Issue 1.3 December 2002 D75670800 TEWS TECHNOLOGIES GmbH TEWS TECHNOLOGIES LLC Am Bahnhof 7 25469 Halstenbek / Germany 1 E. Liberty Street, Sixth Floor Reno, Nevada 89504 / USA Phone: +49-(0)4101-4058-0...
- Page 2 However TEWS TECHNOLOGIES GmbH reserves the right to change the product described in this document at any time without notice. TEWS TECHNOLOGIES GmbH is not liable for any damage arising out of the application or use of the device described herein.
-
Page 3: Table Of Contents
6.1 Required Software Initialization ....................13 6.2 Initialization of the Watchdog Function..................14 INSTALLATION......................16 7.1 Input Wiring ...........................16 7.2 Output Wiring ..........................17 PIN ASSIGNMENT – I/O CONNECTOR ..............18 8.1 Input Connections.........................18 8.2 Output Connections........................19 TIP670 User Manual Issue 1.3 Page 3 of 19... - Page 4 FIGURE 7-1 : INPUT WIRING OPTIONS .......................16 FIGURE 7-2 : OUTPUT WIRING AS HIGH SIDE SWITCH................17 FIGURE 7-3 : OUTPUT WIRING AS LOW SIDE SWITCH................17 FIGURE 8-1 : INPUT I/O CONNECTION......................18 FIGURE 8-2 : OUTPUT I/O CONNECTION....................19 TIP670 User Manual Issue 1.3 Page 4 of 19...
-
Page 5: Product Description
The TIP670 has 8 (4) digital outputs with galvanic isolation via optocouplers. The outputs are isolated against each other in groups of two. All outputs resist short-circuits and are protected against thermal overload. -
Page 6: Technical Specification
250mA typical @+5V DC (all inputs and outputs active) Temperature Range Operating 0 °C to +70 °C Storage -45°C to +125°C MTBF 920276 h 5 – 95 % non-condensing Humidity Transition Module Optional (TIP001-TM-10) Figure 2-1 : Technical Specification TIP670 User Manual Issue 1.3 Page 6 of 19... -
Page 7: Id Prom Contents
Reserved 0x00 0x11 Driver-ID low byte 0x00 0x13 0x00 Driver-ID high byte 0x15 Number of bytes used 0x0C 0x17 0x93 (for TIP670-10) 0xF2 (for TIP670-20) Figure 3-1 : ID PROM Contents TIP670 User Manual Issue 1.3 Page 7 of 19... -
Page 8: Ip Addressing
4 IP Addressing The TIP670 is accessed in the I/O space through the following set of four direct accessible registers implemented in the Z8536 controller: Address Symbol Description Size (Bit) 0x01 PORTC Port C Data Bits D00-D07 0x03 PORTB Port B Data Bits D00-D07... -
Page 9: Figure 4-2 : Z8536 Cio Indirect Addressable Registers
Port B Special I/O Control 0x2D PBPP Port B Pattern Polarity 0x2E PBPT Port B Pattern Transition 0x2F PBPM Port B Pattern Mask Figure 4-2 : Z8536 CIO Indirect Addressable Registers TIP670 User Manual Issue 1.3 Page 9 of 19... -
Page 10: Figure 4-3 : Cio State Machine
‘1’ longer as necessary. Direct accesses to the data register PORTA, PORTB, and PORTC have no consequence for the status of the state machine. TIP670 User Manual Issue 1.3 Page 10 of 19... -
Page 11: Functional Description
5.1 Digital Inputs 5.1.1 Optical Isolation The TIP670 has 8 (TIP670-10) or 4 (TIP670-20) digital inputs. The standard signal level for these inputs is 24V DC. The switching level of the inputs is between 8 and 13 volts. All input channels are isolated by AC optocoupler and are also isolated against each other. -
Page 12: Output Watchdog
Any software access to the Z8536 will retrigger Timer 3 in the Z8536. If the programmed time expires without a software access all outputs go into the ’off’ state (the maximum programmable time is approx. 30ms). However they will return to their original state, when the TIP670 is accessed again by the software. -
Page 13: Programming
6.1 Required Software Initialization The input lines of the TIP670 are connected to port B of the CIO Z8536. This port has to be configured as input and because of the inverting function of the optocouplers the input polarity has to be set to inverting. -
Page 14: Initialization Of The Watchdog Function
6.2 Initialization of the Watchdog Function On the TIP670 port C and counter timer 3 of the Z8536 are wired in way, that a watchdog function can be programmed into the TIP670. This watchdog is retriggered with every access to the TIP670. If there is no access within a previously programmed time frame, the watchdog will automatically disable the output lines. - Page 15 This selects the Counter/Timer 3 Command and Status Register (C3CSR) for the next operation • Write 0x06 to CIOCSR Writing 0x06 into C3CSR triggers and runs counter timer 3 • Write 0x00 to PORTC Writing 0x00 to PORTC will enable the watchdog function TIP670 User Manual Issue 1.3 Page 15 of 19...
-
Page 16: Installation
Each input has two connections at the IP I/O connector, Input x + and Input x -. However the TIP670 has AC optocoupler at the input side. Therefore the polarity of the input signal may be either way. -
Page 17: Output Wiring
Each output can be individually configured as a high side or a low side switch by corresponding wiring. Figure 7-2 : Output Wiring as High Side Switch Figure 7-3 : Output Wiring as Low Side Switch TIP670 User Manual Issue 1.3 Page 17 of 19... -
Page 18: Pin Assignment - I/O Connector
TIP670-10 only Input 6+ TIP670-10 only Input 6- TIP670-10 only Input 7+ TIP670-10 only Input 7- TIP670-10 only Input 8+ TIP670-10 only Input 8- TIP670-10 only Figure 8-1 : Input I/O connection TIP670 User Manual Issue 1.3 Page 18 of 19... -
Page 19: Output Connections
External Supply Voltage for Output 3-4 +Vs 5-6 External Supply Voltage for Output 5-6 (TIP670-10 only) +Vs 7-8 External Supply Voltage for Output 7-8 (TIP670-10 only) Figure 8-2 : Output I/O connection TIP670 User Manual Issue 1.3 Page 19 of 19...
