INSTALLATION AND SERVICING INSTRUCTIONS
SD-245 / 22019
Pressure Transducers and Temperature Sensors are used in conjunction with Sporlan's
S3C, Kelvin II, and PSK families of controls or other controllers to control Electric Expansion
Valves, Electric Discharge Bypass Valves, Electric Evaporator Pressure Regulating Valves,
relays and more.
PRESSURE TRANSDUCERS

PRESSURE TRANSDUCER VOLTAGE

DC VOLTAGE
(white & green leads)
0
0.9
0.5
25
1.6
1.2
50
2.2
1.8
75
2.9
2.5
100
3.6
3.2
125
4.3
3.8
150
4.5
175
200
225
250
275
300
325
350
375
400
425
450
475
500
525
550
575
600
625
650
Pressure Range
Listed on Label
1/4" SAE Flare Installation
Torque: 6-8 ft
lbs.
*
0.5
0.5
0.5
0.8
0.7
0.7
1.2
0.9
0.8
1.5
1.1
1.0
1.8
1.3
1.1
2.2
1.5
1.3
2.5
1.7
1.4
2.8
1.9
1.6
3.2
2.1
1.7
3.5
2.3
1.9
3.8
2.5
2.0
4.2
2.7
2.2
4.5
2.9
2.3
3.1
2.5
3.3
2.6
3.5
2.8
3.7
3.0
3.9
3.1
4.1
3.3
4.3
3.4
4.5
3.6
3.7
3.9
4.0
4.2
4.3
4.5
PRESSURE TRANSDUCER
Pressure
Material,
Range
Label Color
0 - 150
Brass,
psia
Multi-Color
0 - 150
Stainless Steel,
psig
Green
0 - 300
Stainless Steel,
psig
Silver
0 - 500
Stainless Steel,
psig
Yellow
0 - 652
Stainless Steel,
psig
Pink

PRESSURE TRANSDUCER CABLES

Item
Cable Length
1
No.
2 m
953192
5 m
953100
Controller
Old Pigtail
Terminal
Leads
1+ or 2+
Red
1- or 2-
Black
1S or 2S
Green
If the application requires a longer cable, Sporlan recommends
1
extending leads with a maximum of 400 ft (18 awg) wire using
Scotchlok
UR connectors. The signal accuracy should be
TM
verified with any extension and an offset be added to the control
when necessary.
The cable color code differs from the previous model cable, but
2
can still be used in its place.
Pressure Transducer Voltage
650
600
550
500
450
400
350
300
250
200
150
100
50
0
0.5
1
1.5
2
Volts DC (White & Green Leads)
Item
Description
No.
953291 PSPT0150AVSP-B
952572 PSPT0150SVSP-S
952574 PSPT0300SVSP-S
952576 PSPT0500SVSP-S
952579 PSPT0652SVSP-S
Description
PSPT000000CP20
PSPT000000CP50
New Hermetic
Cable
2
Black
Green
White
4.5
2.5
3
3.5
4
