Pool Cover Specialists INFINITY 4000 Installation Manual page 2

™
The ECLIPSE Safety Pool Cover
SECTIONS
Cover Tracks .......................................................5
Roll-up Mechanism .........................................6
Cover Fabric .................................................... 10
Classic Aluminum Lid .................................. 17
Home Owner Check List ............................ 19
Tools Required
1. Hammer drill or rotary hammer
2. Masonry drill bit 1/4" x 6" (1/4" x 12" bit)
3. Extension cords
4. #2 and #3 Phillips & standard screw drivers
5. Ratchet with 5/16" - 3/4" sockets
6. Hacksaw
7. String line
8. Utility knife
9. Broom
10. Hammer & rubber mallet
11. Pliers - standard, needle nose & channel lock
12. Files - round, triangular & flat
13. Matches or lighter
14. Carpenter's square
15. 5/16 hex head driver bit with 12" extension
16. Drill (cordless or corded)
17. Set of drill bits (1/4" down to 1/16")
© Latham Pool Products, Inc. 2019. All rights reserved.
18. Crescent wrench
19. 100' and 25' tape measure
20. Chalk line ( use white chalk)
21. Nut drivers - 5/16", 3/8", 7/16", 1/2"
22. Chisel (wood & concrete)
23. Scissors
24. Wire strippers
25. Set of box/open end wrenches - 5/16" - 3/4"
26. 6" level
27. Set of allen wrenches
28. Wire
29. Electrical tape
30. Small sledge hammer
31. Vice grips
32. #2 and #3 Phillips drill bits
33. Pencil or marker
34. 6 - 8 clamps
Optional Power tools
Skill saw with carbide tipped blade
Sawzall, Grinder and Angle drill
2 of 21
