- Page 1 INFINITY 4000 AUTOMATIC SAFETY POOL COVER ™ DECK MOUNT TOP TRACK SYSTEM INSTALLATION GUIDE © Latham Pool Products, Inc. 2019. All rights reserved.
- Page 2 The ECLIPSE ™ Safety Pool Cover SECTIONS Cover Tracks ..............4 Mechanism ..............7 Cover Fabric ............12 Home Owner Check List ........20 Tools Required 1. Hammer drill or rotary hammer 18. Crescent wrench 2. Masonry drill bit 1/4” x 6” (1/4” x 12” bit) 19.
- Page 3 Carriage bolt 1/4-20 x 3/4” 14. 22003 Top Track Splice 15. H0075 Rope Loop Black Plastic IM4010-R3LV-GLD Infinity 4000 110V Bison Low Voltage -RRT 16. 33600 #10 x 1” Red Holob Anchor 17. H0276 Nut Nylock 1/4-20” IM4010-R3-GLD Infinity 4000 110V Bison (Rec Right) 18.
- Page 4 Step By Step Instructions COVER TRACKS Step By Step Instructions Page/Step Installing the Cover Track ...........5/1 © Latham Pool Products, Inc. 2019. All rights reserved. 4 of 21...
- Page 5 Step By Step Instructions Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Position the cover track along both sides of To determine if the cover system was Cut the length of the track on each side of ordered correctly for the pool, the length the pool.
- Page 6 Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Use the provided screws (29), anchors (16) Use a hammer to tap the screw head down Using a #3 Phillips bit, tighten the screw to and snap-locks (30) to secure the track to until the anchor is flush with the top of the secure the snap-lock to the pool deck.
-
Page 7: Table Of Contents
Step By Step Instructions MECHANISM Step By Step Instructions Page/Step Attaching the Roll-up Tube ......8/3 Positioning the Mechanism ......8/5 Extending the Pulley Brackets ......8/6 Anchoring the Mechanism ......8/14 5 Wire Motor Wiring ..........10 3 Wire Motor Wiring ..........11 © Latham Pool Products, Inc. 2019. All rights reserved. 7 of 21... -
Page 8: Attaching The Roll-Up Tube
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Attaching the Roll-up Tube Position the non-motor end of the Position the motor end of the mechanism mechanism roughly in the position that With the non-motor end turned upside roughly in the position that it will be it will be mounted. -
Page 9: Anchoring The Mechanism
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Use a 1/2” wrench to tighten the nylock nuts. Align the mechanism on the motor side first Go to the non-motor end and make sure the by using a piece of rope. -
Page 10: Wire Motor Wiring
Wiring the Electrical Switch There is one motor option available, the new 3 Wire Motor. It is critical that the control switch that controls the motor be mounted in an all-weather box, in a location where 100% of the pool is visible. Use the following wiring diagram. - Page 11 For the 3-wire motor option, use the wiring diagrams below. Technical Wiring Schematic NOTE: The black wire may be replaced with blue depending on what motor is being used. 3 WIRE MOTOR BLACK WHITE GROUND 110-240 VAC HOT (LINE 2) 50/60 Hz NEUTRAL (LINE 1) 15 AMP GFCI...
- Page 12 Step By Step Instructions COVER FABRIC Step by Step Instructions Page/ Step Opening the Cover Box ........13/1 Running Ropes in the Tracks ......13/4 Routing the Ropes ..........13/9 Magnet Installation ........14/14 Attaching the Leading Edge Tube ....16/31 Attaching the Ropes to the Reels ....17/40 Installing the Sensor ........18/47 Closing the Cover ..........18/50 Attaching the Cover and Bonding Wire ..18/51...
-
Page 13: Opening The Cover Box
Step By Step Instructions Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3 Opening the Cover Box Standing behind the housing looking over Uncoil the ropes to remove twists and kinks. the pool, unroll the cover from left to right. Run the ropes through the tracks. -
Page 14: Magnet Installation
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3 On the non-motor end, run the rope around This rope will continue from the first pulley Run the rope from the non-motor end the pulley and out the backside of the pulley to the second pulley. - Page 15 Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3 Mark the track through the center of the Use a 1/4” drill bit to drill the holes in the Remove the guide from the end of the track. holes in the positive stop plate (36).
-
Page 16: Attaching The Leading Edge Tube
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Drill a minimum of three pilot holes evenly Insert screws (28) into each hole to connect Use a 1/2” wrench, to loosen the center bolt spaced around the leading edge and into the leading edge to the wheel assembly. -
Page 17: Attaching The Ropes To The Reels
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Connect the bonding wire that is attached Reinstall the guide on the end of the track. Drill a hole using a 3/16” bit in the flat section of the leading edge just behind the to the front corner of the cover to the Secure the Positive Stop Plate to the top... -
Page 18: Installing The Sensor
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Installing the Sensor As the excess rope is wrapped around the Use cable ties (22) to secure the sensor wire rope reel, make sure it goes on straight Thread the sensor into the mounting hole to the motor end of the mechanism to keep without getting crossed with each other. -
Page 19: Adjusting The Ropes
Step By Step Instructions Numbers in parenthesis refer to parts shown on page 3. Using a utility knife, carefully cut a slit in Insert a screw driver through the slit in the Apply the supplied grease to the magnet. the webbing long enough for the magnet webbing to create the pocket for the magnet. - Page 20 After the cover system is installed, it is critically important to instruct the home owner on how to operate the cover system safely and do routine maintenance. Use the following check list and the Infinity 4000 Owner's Manual and Safety Information guide as your primary instrution source.
- Page 21 Installation Checklist Tracks q All track ends filed. This is extremely important. q Does the track space measurement match how the cover system was ordered? q Cover goes through the track joints smoothly. q All track screws are tight and flush. q Pulleys are flush against the end of the track. q The guides are snug against the end of the track.
