Operating Instructions:
1.
Enter 4 digit passcode (Default passcode 1234)
2.
Press and hold "Cover" or "Uncover" buttons until cover is in desired position
3.
The keypad will automatically lock after the timeout speci ed (default 20 seconds)
Accessing settings menu:
1.
Enter User 1 passcode (Menus are only accessible from User 1 or Service passcodes)
2.
Press the "Press for Service" button
3.
Press Select (5) button to enter menu
4.
Use Up (2), Down (8) and Select (5) to navigate the menu options
5.
Press the "Press for Service" button at any time to leave the menu option
The following Options are available in the settings menu:
SET PASSCODES: Enter user code number (1-4) and then enter passcode
•
(ie. Press 31111 to program user 3 to a passcode of 1111)
USER DEFAULTS:
•
KEY BEEP – Adjust beep tone
PADTIMEOUT – Adjust key lock timeout (10-60 seconds)
WIFI ENABLE – Not available on this model
SERVICE CALL* – Feature not enabled
RF MODULE* – Allows technician to turn on or off the RF module for remote Touch Pad applications
(Feature Controller with RF required for operation)
LINK TEST* - Display a real time signal strength for troubleshooting poor remote Touch Pad reception
RESET RF LINK* - Resets the RF radio to factory settings (re-sync with feature controller is
required for operation after reset)
• WIFI CONNECT: Not available on this model
•
COVER FEATURES: (if feature controller is installed) – displays feature controller information
•
CALIBRATE POOL* - Allows Touch Pad to be calibrated to the specific pool installation sets
open and close time and average currents
•
CURRENT LIMITS* - Allows technician to fine tune average current and over current limits
•
EDIT PFSSCREEN* - Allows technician to reprogram the screen which is shown when the
"Press for Service" button is pressed
•
SYSTEM STATUS* - Displays system information such as cycle counts and firmware version
•
FACTORY SETUP* - Will reset the Touch Pad back to original factory settings
* Only available in service mode
© Latham Pool Products, Inc. 2019. All rights reserved.
Touch Pad Quick Start Service Guide
A2463
1 of 8

Advertisement

loading

Related Manuals for Pool Cover Specialists A2463

Summary of Contents for Pool Cover Specialists A2463

  • Page 1 Touch Pad Quick Start Service Guide A2463 Operating Instructions: Enter 4 digit passcode (Default passcode 1234) Press and hold “Cover” or “Uncover” buttons until cover is in desired position The keypad will automatically lock after the timeout speci ed (default 20 seconds)
  • Page 2 Touch Pad Installation and Service Guide Introduction: Pool Cover Specialists programmable Touch Pad is designed to provide years of reliable operation to Pool Cover Specialists automatic covers safely and conveniently. This instruction guide is meant to help understand the operation and configuration of the Touch Pad and provide a quick overview of the features that are available.
  • Page 3 Number of Cover Operations: The Touch Pad estimates how many cover uncover cycles have been performed on the pool cover and will be displayed upon login. To scroll through the service menu options use the (2) button to scroll up, (8) button to scroll down, (4) button to scroll left, and (6) button to scroll right.
  • Page 4 Cover Features: If a Feature controller is installed this screen will report the firmware version of the feature controller, if the feature controller is currently active or inactive and the number of cycles currently counted by the feature controller. Service Operations: Calibrate Pool: The Touch Pad can be calibrated for the specific pool it is installed on.
  • Page 5 Edit PFS Screen: The Touch Pad comes with a convenient “Press for Service” button that allows the home owner to quickly get information on who can provide them fast service for their automatic pool cover. This screen is fully customizable, to edit this screen do the BACK following: Access the service menu using the service passcode (5991).

  • Page 6: Installation Notes

    Wiring Instructions - 110 VAC 3 Wire Motor Using the Touch Pad Pool Cover Controller A2463-B/A2469-B Standard All Weather Box Installation Notes: * The control switch is mounted in a standard * The power circuit should be sized for 15 depth single gang all weather box.

  • Page 7: Connection Notes

    Mounting and Configuration Instructions for Remote Touch Pad Applications Part# A2523-B Connection Notes: 1. Log in to the Host Touch Pad using the service code “5991”. * Review wiring instruction for proper installation 2. Select “Press for Service”. of Remote Host Touch Pad or L9965 for proper 3.
  • Page 8 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
