Page 1: Table Of Contents
2.3.3.2 Configuring the DDNS Domain Name on Web Interface .........11 3. Establishing Communication......................12 3.1 Configuring for Communication on GV-FWC ..............12 3.2 Sending Face IDs from Camera ..................14 3.3 Receiving Access Card Data by Controller............... 15 ... -
Page 2: Introduction
1. Introduction Paired with GV-Face Recognition Camera, the GV-FWC is able to generate Wiegand signals for access control management based on face recognition. It can be configured through TCP/IP and provides 3 inputs and 2 relay outputs. 1.1 System Requirements ... -
Page 3: Overview
1.4 Overview The GV-FWC provides two relay outputs Wire Definition Brown Input 1 Purple Input 2 White Input 3 Gray Note that the red, yellow and orange wires are currently nonfunctional. GV-FWC Date: 7/30/2019... - Page 4 Currently nonfunctional. RS-485 The GV-FWC provides 2 Wiegand ports for connecting to GV-AS Controller, -party Wiegand controllers and/or Wiegand readers. Wiegand The GV-FWC can be powered through the DC 12 V. DC 12 V Reset Press to reboot the device.
-
Page 5: Basic Setup
2. Basic Setup GV-FWC is able to send access card data, paired to Face IDs of GV-Face Recognition Camera, to GV-AS Controller, regulated by GV-ASManager, upon recognition, as illustrated below. Make sure the GV-FWC, GV-AS Controller and GV-Face Recognition Camera are set up under the same LAN. -
Page 6: Connecting Extended Reader
Note: 1. GV-FWC connection to GV-AS Controller via TCP/IP is only supported by GV-AS210 / 2110 / 2120 / 410 / 4110 / 4111 / 810 / 8110 / 8111 V2.20 or later. 2. Face images are also sent to the GV-ASManager upon recognition only when the GV-FWC is connected to GV-AS Controller via TCP/IP. -
Page 7: Powering On
IP address. Follow the steps below. Note: 1. The PC used to access the Web interface must be under the same LAN as the GV-FWC. 2. If the network connected doesn’t have DHCP server or is disabled, GV-FWC can be accessed by its default IP address 192.168.0.100, see 2.3.1 Assigning a Static IP... -
Page 8: Assigning A Static Ip Address
2.3.1 Assigning a Static IP Address To assign a static IP address to GV-FWC, follow the steps below. Open your Web browser, and type the default static IP address https://192.168.0.100. In both Login and Password fields, type default value admin. Click OK and this page appears. -
Page 9: Configuring A Ddns Domain Name
2.3.2 Configuring a DDNS Domain Name DDNS (Dynamic Domain Name System) provides another way of accessing GV-FWC when using a dynamic IP from a DHCP server. DDNS assigns a domain name to GV-FWC so that it can always be accessed using the domain name. - Page 10 5. Click Send. When the registration is complete, this page appears. The Hostname shown is the domain name, consisting of the registered username and “gvdip.com”, e.g. somerset01.gvdip.com. Note: The registered username becomes invalid after not being used for three months. GV-FWC Date: 7/30/2019...
-
Page 11: Configuring The Ddns Domain Name On Web Interface
After acquiring a domain name from the DDNS Server, follow the steps below to configure the domain name on GV-FWC’s Web interface. Refer to 2.3. Accessing GV-FWC to access the Network Configuration page. Select Enable and Send to DDNS under DHCP Client and Domain Name Service, respectively. -
Page 12: Establishing Communication
Sending Face IDs from Camera. 3.1 Configuring for Communication on GV-FWC For the GV-FWC to receive Face IDs and send the paired access card data to GV-AS Controller, follow the steps below: In the left menu, click Wiegand Setting. The Controller Connecting Setting page appears. - Page 13 Click Submit to save the settings. Note: 1. GV-FWC connection to GV-AS Controller via TCP/IP is only supported by GV-AS210 / 2110 / 2120 / 410 / 4110 / 4111 / 810 / 8110 / 8111 V2.20 or later. 2. For AS Controller IP (Face + Card with Wiegand A/B), enable Wiegand Port Monitor to record all card swipes done to the GV-Reader connected.
-
Page 14: Sending Face Ids From Camera
For the GV-Face Recognition Camera to send Face IDs to GV-FWC upon recognition, follow the steps below. Note: For any Face ID to be sent to GV-FWC upon recognition, it must be paired with a Wiegand access card, as configured in its face database, see GV-Face Manager User’s Guide. -
Page 15: Receiving Access Card Data By Controller
Connection Status. Once the necessary settings among the GV-FWC, GV-Face Recognition Camera and GV-AS Controller are configured, Face IDs of GV-Face Recognition Camera are regarded as Wiegand access cards by the GV-AS Controller to manage access control as set by GV-ASManager. -
Page 16: The Web Interface
4. The Web Interface The following covers all of the settings available on the GV-FWC Web interface, aside from Network and Wiegand Setting (see 2.3 Accessing GV-FWC and 3. Establishing Communication, respectively), which include: Other Setting, Input Setting, Output Setting, In/Out Monitor, Firmware Update, Account Setting, Wiegand Port Monitor and System Log Viewer. -
Page 17: Input Setting
4.2 Input Setting In the left menu, click Input Setting. This page appears. [Input Setting] Enable: Select to enable this Input function to be used by GV-FWC. Name: Name the input. The name is restricted to 16 alphanumeric characters or 5 ... -
Page 18: Output Setting
4.3 Output Setting In the left menu, click Output Setting. This page appears. Enable: Select to enable this Output function to be used by GV-FWC. Name: Name the output. The name is restricted to 16 alphanumeric characters or 5 ... -
Page 19: In/Out Monitor
Off (no output). Click the ALL ON button to force both outputs to be triggered. Click the ALL OFF button to turn off both outputs. Select the individual outputs to turn it ON to force the output to be triggered or turn it OFF. GV-FWC Date: 7/30/2019... -
Page 20: Updating Firmware
When the update is complete, a dialog box appears and asks you to reboot the system. Click OK. GV-FWC starts the Reboot operation. IMPORTANT: It is required to reboot GV-FWC after updating the firmware. Without rebooting, the firmware update is not complete. -
Page 21: Changing Login Id And Password
The Wiegand Port Monitor records and displays past Wiegand signals the GV-FWC has sent to GV-AS Controller. This function is only applicable when the GV-FWC is connected to the GV-AS Controller via Wiegand or when a GV-Reader is connected to one of the Wiegand ports of GV-FWC. -
Page 22: Viewing System Log Information
4.8 Viewing System Log Information The system log information contains the current system status and dump data that can be used by service personnel for analyzing any problems encountered. GV-FWC Date: 7/30/2019...
