GV-FR Panel V1

GV-FR Panel V2

GV-FR Panel V2-QR

Thank you for purchasing GV-FR Panel. This guide is designed to assist the new user in getting immediate

results from the panel. For advanced information on how to use GV-FR Panel, please refer to GV-FR Panel

User's Manual.

Quick Start Guide

GV-FR Panel

FRPANELV20-QG-A

Table of Contents

Need help?

Do you have a question about the GV-FR Panel V1 and is the answer not in the manual?

Questions and answers

Summary of Contents for GeoVision GV-FR Panel V1

Page 1 Quick Start Guide GV-FR Panel GV-FR Panel V1 GV-FR Panel V2 GV-FR Panel V2-QR Thank you for purchasing GV-FR Panel. This guide is designed to assist the new user in getting immediate results from the panel. For advanced information on how to use GV-FR Panel, please refer to GV-FR Panel User’s Manual.
Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
Page 3: Table Of Contents
Contents Recognition and Authentication Considerations ....... 1 Chapter 1 Introduction ............... 3 1.1 Packing List ................3 1.1.1 GV-FR Panel V1 ......................3 1.1.2 GV-FR Panel V2 ......................4 1.2 Overview .................. 5 1.2.1 GV-FR Panel V1 ......................5 1.2.2 GV-FR Panel V2 ......................7 Chapter 2 Installation .................
Page 4: Recognition And Authentication Considerations
Face Recognition Distance: • GV-FR Panel delivers optimal face recognition results when the faces of the targets are within 1 m (3.3 ft) of GV-FR Panel V1, and 2 m (6.6 ft) of GV-FR Panel V2. Lighting Conditions: • GV-FR Panel is designed for indoor use only. Avoid exposing it to direct sunlight as it may affect its face recognition performance.
Page 5 GV-FR Panel V1: Detection Area for Card Place tags / fobs closely against the text “NFC” QR code reader GV-FR Panel V2: GV-FR Panel V2-QR:...
Page 6: Chapter 1 Introduction
Welcome to the GV-FR Panel Quick Start Guide. In the following sections, you will learn the basic installations and configurations of GV-FR Panel. For details, see the GV-FR Panel User’s Manual. 1.1 Packing List 1.1.1 GV-FR Panel V1 1. GV-FR Panel V1 2. Wall Mount Bracket Kit For GV-Mount800 For GV-Mount801 3. Wiegand cable 4.
Page 7: Gv-Fr Panel V2
1.1.2 GV-FR Panel V2 GV-FR Panel V2 or GV-FR Panel V2-QR GV-FR Panel V2 (includes the data GV-FR Panel V2-QR (includes the cable attached to the rear panel) data cable attached to the rear panel) Wall Mount Bracket Kit Power Adapter DC 12V 3A Screw Kit (a) Short Screw (5 mm / 0.20 in) x 1 (b) Socket Screw (10 mm / 0.39 in) x 2...
Page 8: Overview
Reads QR codes used for access control. (The QR code LED QR Code Reader turns on when detecting motion around.) Contains all the ports of the GV-FR Panel V1. (See No. 6 – Rear Panel 10.) Reset Button Restarts the GV-FR Panel V1.
Page 9 RJ-45 Port Connects to the network via the supplied RJ-45 cable. Relay Output Contains the following 3 relay pins: NO, COM, and NC. Connects to power via the supplied 2-pin power cable and an 2-Pin Power connector optional power adapter. Microphone Receives audio.
Page 10: Gv-Fr Panel V2
1.2.2 GV-FR Panel V2 No. Name Function • Green LED: Turns on when recognizing registered faces. LED Light • Red LED: Turns on when detecting unknown faces. Built-in Cameras Captures real-time live images at the front of the panel. Displays the live images captured by the built-in cameras and Touchscreen Panel accesses its local settings.
Page 11 Connects to 3 -party controllers. (See Chapter 7 Third-Party Controller Integration in the User’s Manual.) Contains the following 5 pins: 232-RX (Not functional.) 232-TX (Not functional.) Wiegand Output Wiegand Output Data 0 Wiegand Output Data 1 Note: The Wiegand Output pins (Data 0 and Data 1) and the GND pin must be connected when integrating with a third-party controller.
Page 12: Chapter 2 Installation
2.1.1 GV-FR Panel V1 To connect GV-FR Panel V1, follow the steps below. Connect the GV-FR Panel V1 to the network using the supplied RJ-45 cable with a user-supplied Ethernet cable. Connect the GV-FR Panel V1 to power using the supplied 2-pin power cable and an...
Page 13 Note: When unplugging a connected cable (No. 3 / 4 / 5 / 6 / 7, 1.2 Packing List) from GV-FR Panel V1 for any reason, grip firmly onto the terminal block and pull out slowly. Do not pull the cable by the cord.
Page 14: Gv-Fr Panel V2
2.1.2 GV-FR Panel V2 To connect GV-FR Panel V2, follow the steps below. Power 1. To connect GV-FR Panel V2 to power, connect from the power input of the data cable to power using the supplied power adapter. 2. To connect GV-FR Panel V2 to the network, connect from the RJ-45 port of the data cable to the network using a user-supplied Ethernet cable.
Page 15: Standard Installation
Insert the 4 plastic screw anchors into the holes drilled and secure the mounting bracket onto the wall with the screws provided. Secure the large sealing rubber and the back cover onto the back of the GV-FR Panel V1 with the screws provided.
Page 16 Secure the small sealing rubber and the mounting plate onto the GV-FR Panel V1 with the screws provided. Mounting Plate Sealing Rubber Secure the GV-FR Panel V1 onto the wall by attaching its mounting plate onto the wall mount bracket. The Mounting Plate secured at the back of GV-FR Panel...
Page 17: Gv-Fr Panel V2
2.2.2 GV-FR Panel V2 2.2.2.1 Wall Installation To install GV-FR Panel V2 on a wall, follow the steps below. 1. Place the mounting bracket on the wall and mark the locations of the three screw positions as illustrated below. 2. At each of the three screw positions marked on the wall, drill a hole using a 6 mm (0.24 in) drill bit.
Page 18 4. Secure two of the provided 10 mm (0.39 in) socket screws to the back of GV-FR Panel V2. The provided Allen wrench can be used if needed. 5. If a wall hole is drilled to conceal the cables, guide the data cable attached to GV-FR Panel V2 through the square hole in the mounting bracket and into the wall;...
Page 19 6. To complete the installation, secure the mounting bracket to GV-FR Panel V2 from the bottom using one of the provided 5 mm (0.20 in) screws.
Page 20 2.2.2.2 Desktop Installation To install GV-FR Panel V2 with Pillar Stand on a horizontal surface (such as a counter or desk), follow the steps below. Select a suitable horizontal surface no thicker than approximately 10 mm (0.39 in). leaving space for the securing nut along the 18 mm (0.71 in) thread. Note: The 10 mm (0.39 in) measurement is an estimate;...
Page 21 Detach the securing nut from the end of the pillar stand. Slide the nut along the length of the cables until it is fully removed. Route the cables through the drilled hole, and then insert the pillar stand (already attached to the back of GV-FR Panel V2) through the hole until the stand sits firmly on the surface.
Page 22 Adjust the tilt angle of GV-FR Panel V2 by loosening the cover on top of the pillar stand. Once you have adjusted the angle, re-tighten the cover to lock the tilt angle in place.
Page 23: Chapter 3 Accessing Gv-Fr Panel
Chapter 3 Accessing GV-FR Panel Upon first-time starting GV-FR Panel, users are prompted to set the login password for its Administrator account. After setting the password, the live view of the GV-FR Panel’s built-in camera appears. GV-FR Panel V1: GV-FR Panel V2:...
Page 24 After faces are registered in and recognized by the GV-FR Panel, a confirmation screen will be displayed and overlaid on the live image. There are several methods to register faces: 1. From the Web interface of GV-FR Panel. See how to find the IP address of GV-FR Panel in 3.1 Looking up the IP Address, and then select Face Management >...
Page 25: Looking Up The Ip Address
To check the IP address of your GV-FR Panel, follow the steps below. 1. On the main screen of GV-FR Panel, tap the GeoVision logo at the upper-left corner of the touchscreen to enter the settings page. You’re prompted to type the password of its Administrator account.
Page 26 3. On a PC, open a Web browser and type the IP address and Web port of the GV-FR Panel as exemplified below, e.g. 192.168.4.236:8080. The login page appears. IMPORTANT: For accessing GV-FR Panel, it is required to add a colon and the port number (default port: 8080) after the IP address, e.g.
Page 27: Chapter 4 Advanced Settings
Chapter 4 Advanced Settings 4.1 Upgrading System Firmware GeoVision periodically updates the latest firmware to the company website. You can update GV-FR Panel’s firmware through GV-IP Device Utility (V8.9.3 or later) from the website. Important Notes Before You Start Before you start updating the firmware, read these important notes: While the firmware is being updated, the power supply must not be interrupted.
Page 28 Using the GV-IP Device Utility GV-IP Device Utility provides a direct way to upgrade the firmware to multiple GV-FR Panels. Note: The computer used to upgrade firmware must be within the same network as the GV-FR Panel. 1. Once downloaded, select GV IP Device Utility, and follow the onscreen instructions to install the program.
Page 29: Restoring To Factory Default
4.2 Restoring to Factory Default If for any reason the device is not responding properly, you can restore it to its factory default settings through the Web interface. 1. Click General Settings > System Settings. 2. Click Load Default.
