GV-CS1320 Camera Access Controller
User's Manual
Before attempting to connect or operate this product, please
read these instructions carefully and save this manual for future use.
CS1320V211-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-CS1320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-CS1320

Summary of Contents for GeoVision GV-CS1320

  • Page 1 GV-CS1320 Camera Access Controller User’s Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. CS1320V211-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Naming And Definition

    Naming and Definition GV-System GeoVision Analog and Digital Video Recording Software. The GV- System also refers to Multicam System, GV-NVR System, GV- (GV-DVR/NVR) Hybrid DVR System and GV-DVR System at the same time. GV-VMS GeoVision Video Management System for IP cameras.

  • Page 4: Optional Device

    Optional Device Optional devices can expand the capabilities and versatilities of your GV-CS1320. Consult your sales representative for more information. GV-Reader 1352 GV-Reader 1352 V2 is a card reader that uses a 13.56 MHz frequency. It has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
  • Page 5 Power Adapter Contact your sales representative for the countries and areas supported. GV-I/O Box 4 A small but capable device, the GV-I/O Box 4 Ports V1.2 provides 4 Ports V1.2 inputs and 4 relay outputs. It supports both DC and AC output voltages, and provides a USB port for PC connection.

  • Page 6: Installation Considerations

    When placed at a building gate, GV-CS1320 should be about 1.4-1.5 meters above the ground. • When placed at a parking lot gate, GV-CS1320 should be about 1.2 meters above the ground to match the height of vehicles. Face Detection Limitations •...
  • Page 7 Lighting Conditions • Avoid placing GV-CS1320 where the light source is directly behind the subject. • Prevent light from directly falling onto the GV-CS1320’s camera lens.

  • Page 8: Chapter 1 Introduction

    Introduction Chapter 1 Introduction GV-CS1320 is an access controller with a built-in 2 MP camera and 13.56 MHz reader. GV-CS1320 recognizes identification cards and grants access to up to 100,000 users accordingly. With the integration of the wide angle camera, the Card and Face Mode enables GV-CS1320 to perform face detection together with card verification before access can be granted.
  • Page 9 There are 3 types of notifications allowing the operator to communicate with the visitor and grand access. 1. GV-ASNotify Program: Visitors requesting entry permits can use the touch pad to be granted access. When GV- CS1320 is connected to GV-ASManager over the network, GV-ASNotify will generate a notification message whenever the touch pad is activated.
  • Page 10 Figure 1-3 3. VoIP Calls: When the touch pad is activated, GV-CS1320 will place a call to the operator through the Internet using VoIP. The operator can then communicate with the visitor and enter the access code to open the door.
  • Page 11 The all-in-one solution eliminates the need of installing and maintaining a separate camera in addition to the card reader and a door entry system.

  • Page 12: Key Features

    Reader • Built-in 13.56 MHz Reader (Mifare DESFire, Mifare Plus and Mifare Classic) • Support for GV-Proximity Cards with GID (GeoVision identifier) to enhance security • Access by card plus face detection • RS-485 and network interfaces for connecting up to 2 readers Access Control •...
  • Page 13 • 1 relay outputs (30V DC, 0.5A) • Support for GV-I/O Box 4 Ports for sensor, alarm application and door bell activation...

  • Page 14: Packing List

    Introduction 1.2 Packing List • • GV-CS1320 Mounting Plate • • Standard Screw x 2 Plastic Screw Anchor x 2 • • Security Screw Torx Wrench • Silica Gel Bag • Software DVD • Micro SD Card 2 GB •...

  • Page 15: System Requirements

    1.3 System Requirements To access the functions and settings of GV-CS1320 on the Web interface, ensure your PC has good network connection and use one of the following web browsers: • Internet Explorer 9 x or later • Microsoft Edge •...

  • Page 16: Physical Description

    1.4 Physical Description Figure 1-5 No. Name Function Lens Receives image. Microphone Receives sound from GV-CS1320. Card Reader Reads ID cards or ID tags. IR LEDs Automatically illuminates for night time use. Speaker Talks to the surveillance area from the local computer.

  • Page 17: Installation

    1.5 Installation 1.5.1 Wire Definition The wire assignment of the GV-CS1320 cable data are illustrated below. Figure 1-6 Wire Definition RJ-45 Ethernet 12V DC Black Yellow Sensor IN1 Brown IN COM Light Red Button IN2 Blue RS-485 + Light Blue...
  • Page 18 Introduction 1.5.2 Installing GV-CS1320 After the location of GV-CS1320 is decided, follow the steps below to install the camera access controller. Note: You will need to prepare a single gang power box for wall mount installation. 1. Attach the single gang power box to the wall.
  • Page 19 4. Secure the supplied security screw on the bottom with the mounting plate. Figure 1-9...

  • Page 20: Replacing The Silica Gel Bag

    1.5.3 Replacing the Silica Gel Bag If you opened the compartment cover at the back of your GV-CS1320 to change a new Micro SD card, you must follow the steps below to replace the original silica gel bag with a new one.

  • Page 21: Connecting Rs485 Readers

    GV-CS1320 can establish RS-485 connection with up to 2 GV-Readers. Connect the RS- 485 wires from the GV-CS1320 to the reader. The 12V DC and GND wires of the GV- CS1320 can be used to power the readers, but you will need to set up a separate power source if the total power consumption (including output devices) exceeds 12V.

  • Page 22: Connecting Network Readers

    Introduction 1.6.2 Connecting Network Readers GV-CS1320 supports network connection with GV-CR420, GV-GF1921 / 1922 and GV- FR2020. Figure 1-13...
  • Page 23 Wire color Definition Yellow Sensor IN1 Light Red Button IN2 Brown IN COM Note: You can connect a GV-I/O Box to your GV-CS1320 to give an extra layer of security. For details, see Chapter 8 Connecting to GV-I/O Box 4 Ports.
  • Page 24 (+) point on the locking device to the Door COM wire on GV-CS1320, connect the two (-) points of the locking device and the external power supply together, and connect the (+) point on the external power supply to the Door NO or Door NC wire on GV-CS1320 based on the state of the locking device.
  • Page 25 1.6.5 Connecting GV-CS1320 to PC Connecting GV-CS1320 to a computer enables you to access its Web interface and connect it to GV-ASManager if the computer is installed with GV-ASManager. The computer running GV-ASManager software can be used to monitor the access information and alarm messages from GV-CS1320.
  • Page 26 Introduction When GV-CS1320 is connected to GV-ASManager, GV-ASNotify will generate a notification message and snapshot whenever the touch pad on GV-CS1320 is activated. You can use GV-ASNotify to watch live view and communicate with the surveillance site with the microphone and speaker functions of GV-ASNotify. For details, see Chapter 15, GV-ASNotify in the GV-ASManager User’s Manual.

  • Page 27: Connecting The Power

    1. Power should only be applied to the unit when all connections are completed and tested. 2. GV-CS1320 produces an output voltage of 12V. You will need to connect an external power supply if the total power consumption exceeds 12V after readers and output...
  • Page 28 Introduction 1.7 LED Status and Beeper Normally, the LED on GV-CS1320 is blue during standby mode and the LED flashes green when a card is granted access. The LED status and beeper under different conditions are listed below Condition Beeper...

  • Page 29: Chapter 2 Getting Started

    3. You can now access the Web interface of GV-CS1320. If GV-CS1320 is installed in a LAN with the DHCP server, use GV-IP Device Utility to look up its dynamic IP address. See 2.1 Checking the Dynamic IP Address.

  • Page 30: Checking The Dynamic Ip Address

    IP devices connected in the same LAN. Click the Name or Mac Address column to sort. Figure 2-1 Find GV-CS1320 with its MAC address, click on its IP address and select Web Page. Figure 2-2...
  • Page 31 The login page appears. Figure 2-3 Type the default ID and password admin and click Apply to login.

  • Page 32: Assigning An Ip Address

    3. In the left menu, select Network and then LAN to begin the network settings. Figure 2-4 4. Select Static IP address. Type the IP Address, Subnet Mask, Router/Gateway, Primary DNS and Secondary DNS. 5. Click Apply. GV-CS1320 is now accessible by entering the assigned IP address on the web browser.
  • Page 33 If Dynamic IP Address or PPPoE is enabled, you need to know which IP address GV-CS1320 will get from the DHCP server or ISP to log in. If your GV-CS1320 in installed in a LAN, use the GV-IP Device Utility to look up its current dynamic address.

  • Page 34: Chapter 3 Accessing The Camera Access

    Once installed, GV-CS1320 is accessible on a network. Follow these steps to access your surveillance images: Start the Internet Explorer browser. Type the IP address or domain name of GV-CS1320 in the Location / Address field of your browser. Figure 3-1...
  • Page 35 CS1320, and click Connect to access the full functioning user interface. Figure 3-2 Note: To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one-time installation of GeoVision’s ActiveX component onto your computer.

  • Page 36: Functions Featured On The Main Page

    Accessing the Camera Access Controller 3.2 Functions Featured on the Main Page This section introduces the features of the Live View window on the main page. Figure 3-3...

  • Page 37: The Live View Window

    Stops playing video. 3 Microphone Talks to the surveillance area from the local computer. 4 Speaker Listens to the audio around GV-CS1320. Takes a snapshot of live video. 5 Snapshot --- See 3.2.3 Snapshot of a Live Video. Records live video to the local computer.
  • Page 38 Accessing the Camera Access Controller --- See 3.2.5 Digital PTZ --- See 3.2.6 Wide Angle Lens Dewarping --- See 3.2.7 Picture-in-Picture and Picture-and-Picture View Brings up these functions: Alarm Notify, Video and Audio Configuration, Remote Config, Show Camera Name and Image Enhance. --- See 3.2.8 Alarm Notification 8 Show System Menu --- See 3.2.9 Video and Audio Configuration...

  • Page 39: The Control Panel Of The Live View Window

    Figure 3-5 Tip: The administrator can also use the GV-IP Device Utility and click the GV-CS1320’s IP address to access the live view and adjust camera image settings. Figure 3-6...
  • Page 40 Accessing the Camera Access Controller [Information] Displays the version of GV-CS1320, local time of the local computer, host time of GV-CS1320, and the number of users logging in to GV-CS1320. [Video] Displays the current video codec, resolution and data rates.
  • Page 41 Sharpness: Adjusts the sharpness of the image Gamma: Adjusts the relative proportions of bright and dark areas White balance: GV-CS1320 automatically adjusts the color to be closest to the image you are viewing. You can choose one of the four presets: Auto, Outdoor, Indoor, and Fluorescent.

  • Page 42: Snapshot Of A Live Video

    CS1320 to adjust exposure based on the full live view. Select Regional Metering for GV-CS1320 to adjust exposure of specified zones. Draw directly on the live view and a block marked with “AE (automatic exposure)” appears. You can establish up to 4 zones.

  • Page 43: Digital Ptz

    3.2.5 Digital PTZ The Digital PTZ (DPTZ) function of GV-CS1320 allows you to simulate the PTZ movement on the screen. 1. Right-click on the live view to display a drop-down list. 2. Select Digital PTZ. The PTZ control panel appears.

  • Page 44: Wide Angle Lens Dewarping

    Accessing the Camera Access Controller 3.2.6 Wide Angle Lens Dewarping Use the Wide Angle Lens Dewarping function to reduce the warping of live view. 1. Right-click on the live view to display a drop-down list. 2. Select Wide Angle Setting. The Wide Angle Dewarping Setting window appears. Figure 3-9 3.

  • Page 45: Picture-In-Picture And Picture-And-Picture View

    3.2.7 Picture-in-Picture and Picture-and-Picture View Two types of close-up views are available to provide clear and detailed images of the surveillance area: Picture-in-Picture (PIP) and Picture-and Picture (PAP). After entering the live view window, the image is displayed in PIP mode by default. Picture-in-Picture View With the Picture in Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.

  • Page 46: Picture-And-Picture View

    Accessing the Camera Access Controller Picture-and-Picture View With the Picture and Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 3-11 Right-click the live view and select PAP. Three inset windows appear at the bottom. Draw a navigation box on the image, and this selected area is immediately reflected in one inset window.

  • Page 47: Alarm Notification

    3.2.8 Alarm Notification Note the I/O Alarm notification and motion detection are not supported by GV-CS1320. Figure 3-12...

  • Page 48: Video And Audio Configuration

    Accessing the Camera Access Controller 3.2.9 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communication and set the number of frames to keep for live view buffer. Click the Show System Menu button (No. 9, Figure 3-4), and select Video and Audio Configuration.
  • Page 49 Audio Configure: You can enable the microphone and speaker and adjust the audio volume. Figure 3-14...

  • Page 50: Remote Configuration

    Accessing the Camera Access Controller 3.2.10 Remote Configuration You can upgrade firmware over the network. Click the Show System Menu button (No. 9, Figure 3-4), and select Remote Config. The Remote Config dialog box will appear. Figure 3-15 [Firmware Upgrade] In this tab, you can upgrade the firmware over the network. 3.2.11 Camera Name Display To display the camera access controller’s name on the image, click the Show System Menu button (No.

  • Page 51: Image Enhancement

    3.2.12 Image Enhancement To enhance the image quality of live video, click the Show System Menu button (No. 9, Figure 3-4), and select Image Enhance. This dialog box appears. Figure 3-16 De-Interlace: Converts the interlaced video into non-interlaced video. De-Block: Removes the block-like artifacts from low-quality and highly compressed video.

  • Page 52: Chapter 4 Administrator Mode

    Administrator Mode Chapter 4 Administrator Mode The Administrator can access system configuration of GV-CS1320 through the network. The following configuration categories are available: Video, Access Control, Events and Alerts, Network, Management and SIP. Figure 4-1...
  • Page 53 List of Menu Options Find the topic of interest by referring to the section number prefixed to each option. 4.1.1 Video Settings 4.1 Video 4.1.2 Text Overlay 4.2.1 Basic Setting 4.2 Access Control 4.2.2 Extended Device 4.3.1 Email 4.3 Events and Alerts 4.3.2 RTSP/ONVIF 4.4.1 Status 4.4.2 LAN...
  • Page 54 Administrator Mode 4.1 Video GV-CS1320 supports dual streams, Streaming 1 and Streaming 2, which allow separate codec and resolutions settings for a single video transmission. In a bandwidth-limited network, such as mobile phone surveillance, this dual-stream feature allows you to view live video in lower resolution (Streaming 2), and record in highest resolution (Streaming 1) at the same time.
  • Page 55 4.1.1 Video Settings Figure 4-2a...
  • Page 56 Administrator Mode Figure 4-2b [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended frame rate. [Video Signal Type] Configure the codec type, signal format, resolution and frame rate. Select between H.264 and MJPEG as the codec type.
  • Page 57 Overlay with: Select one or more of the options below to be overlaid on the live view and recorded videos. Camera Name Date System Time [Text Overlay Settings (OSD)] Displays camera name, date, and/or time on the live view and recorded videos when viewing through GeoVision software and third-party software through ONVIF and RTSP.
  • Page 58 [Special View Setting] D/N: Sets the Day/Night mode of GV-CS1320. Auto: Select Auto for the GV-CS1320 to detect the amount of light present and automatically switch to monochrome in a poorly-lit scene. Use the drop-down list to adjust the sensitivity level of light sensor from 1 to 5. The higher the value, the more...
  • Page 59 Black and White: Select this option for the live view to be in monochrome. Color: Select this option for the live view to be in color. [BLC] Enable the backlight compensation to adjust the exposure when the subject is positioned in front of a bright light source.

  • Page 60: Text Overlay

    Administrator Mode 4.1.2 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings.

  • Page 61: Access Control

    4.2 Access Control Under Access Control, there are two sections, Basic Setting and Extended Device, you can choose from to configure the controller settings on the left menu of the Web interface. 4.2.1 Basic Setting The Basic Setting section covers function setting, door parameter configuration, card setting, input and other settings.

  • Page 62: Function Setting

    [Door/Gate #] [Elevator] Select the function type and the authentication mode for the use of the Doors / Gates / Elevators. Function: Select the function for GV-CS1320 to be installed in a general door / parking place and an elevator for entry or exit access control.
  • Page 63 Info IP: Enter the IP address of the next corresponding controller. Note: GV-CS1320 does not support fire sensor inputs. However, the output of GV-CS1320 will be triggered when the fire sensors on one door of its associated controller is triggered.
  • Page 64 Administrator Mode 4.2.1.2 Door Parameter The content of the Parameter Configuration page change is based on your settings for Door/Gate # in the Function Configuration page (Figure 4-6). Figure 4-7 [Events] Set the parameters for the events. • When Door Control is selected in the Function Configuration page (Figure 4-6), these options become available: Option Description...
  • Page 65 Relay on Time See the same option above. Fire Action Alarm Continuous See the same option above. Time Note: GV-CS1320 does not support fire sensor inputs. The Fire Action and Global Fire Alarm options must work with the Anti-Pass Back (APB).
  • Page 66 Administrator Mode [Alarm] Select Yes or No to enable or disable the alarm function. The default settings for all the alarms are set to NO. • When Door Control is selected in the Function Configuration page (Figure 4-6), these options become available: Option Description Door Held Open...
  • Page 67 Figure 4-8 [Card Identify] Identification type: Set the built-in card reader of GV-CS1320 to read UID (unique identification) or GID (GeoVision identification) on GV-AS ID F Card / Key Fob. To use GeoVision Identification (GID), make sure there are two numbers on your GV-AS ID Cards / Key Fobs as shown below.

  • Page 68: Input Setting

    Administrator Mode 4.2.1.4 Input Setting The Input Setting is used to define the input devices connected to GV-CS1320. Figure 4-10 [Input Function] Set the input contact types to be normally open or normally closed. The default settings for all the inputs are set to NO.

  • Page 69: Other Setting

    4.2.1.5 Other Setting Here you can specify the encryption code, device port and adjust the SD settings in your GV- CS1320. Figure 4-11 3DES Code 1-3: Stands for Triple DES (Data Encryption Standard). Type up to three different keys for data encryption. The default 3DES Code1 is 12345678. Device Port: Keep the default value 4000 or modify it to match that of GV-ASManager’s.
  • Page 70 Administrator Mode 4.2.2 Extended Device You can define the GV-Readers and GV-GF Fingerprint Readers connected to GV-CS1320 through RS-485 or network connection. 4.2.2.1 Extended Reader Figure 4-12 [GV-Reader / CR420 / GF1921 / 1922 Function] Define the readers connected to the controller, and then use the Function drop-down list to select the door option associated with the reader.
  • Page 71 [Card Identification Type] Select either UID (unique identification) or GID (GeoVision identification) for your reader. [GeoFinger Server IP Address] To allow GV-ASManager to receive data from the GV-GF1921 / 1922 defined on this page during remote fingerprint enrollment, type the IP address and port of the GV-ASManager’s GeoFinger Server.

  • Page 72: Events And Alerts

    Administrator Mode 4.3 Events and Alerts The Administrator can set up alert methods to receive e-mail notifications when the door is tampered with. 4.3.1 Email Figure 4-13 [Enable] Select Enable to set up e-mail notifications. Sever URL/IP Address: Type the SMTP Server’s URL address or IP address. Server Port: Type the SMTP Server’s port number or keep the default value 25.
  • Page 73 Alerts interval time in minute: Specify the interval between e-mail alerts. The interval can be between 0 and 60 minutes. The option is useful for frequent event occurrence. Any event triggers during the interval period will be ignored. [Need authentication to login] If the SMTP Server needs authentication, select this option and type a valid Username and Password to log in the SMTP server.
  • Page 74 RTP/UDP Port: Keep the default range from 17300 to 17315, or modify it if necessary. The number of ports for use is limited to 20. Max Connection: Set the maximum number of connections to GV-CS1320. The maximum value is 8.
  • Page 75 Disable Authentication: By default, when accessing live view through the RTSP command, the ID and password of GV-CS1320 are required. Select this option to disable the authentication prompt. [ONVIF] Enable Authentication: The ID and password of GV-CS1320 are required to access GV-CS1320 by a third-party DVR through ONVIF.
  • Page 76 Administrator Mode 4.4 Network The Network section includes some basic but important network configurations that enable the GV-CS1320 to be connected to a TCP/IP network. 4.4.1 Status You can access an overview of GV-CS1320’s network status. Figure 4-15...
  • Page 77 IP address to GV-CS1320. Click the Test DHCP to see the currently assigned IP address or look up the address using GV-IP Device Utility. Static IP address: Assign a static IP or fixed IP to GV-CS1320. Type GV-CS1320’s IP address, Subnet Mask, Router/Gateway, Primary DNS server and Secondary DNS server.
  • Page 78 PPPoE: The network environment is xDSL connection. Type the Username and Password provided by ISP to establish the connection. If you use the xDSL connection with dynamic IP addresses, first use the DDNS function to obtain a domain name linking to GV-CS1320’s changing IP address.

  • Page 79: Advanced Tcp/Ip

    4.4.3 Advanced TCP/IP This section introduces the advanced TCP/IP settings, including the DDNS Server, HTTPS port, streaming port, UPnP and QoS. Figure 4-17...
  • Page 80 2. Service Provider: Select the DDNS service provider you have registered with. 3. Host Name: Type the host name used to link to GV-CS1320. For users of GeoVision DDNS Server, it is unnecessary to fill the field because the system will detect the host name automatically.
  • Page 81 DSCP value will tell the router what service level to be applied, e.g. the bandwidth amount. This value ranges from 0 to 63 in decimal format. The default value is 0, meaning QoS is disabled. Note: If you do not intend to connect GV-CS1320 to the network, disable this function to prevent automatic reboot.
  • Page 82 Administrator Mode 4.4.4 IP Filtering The Administrator can set IP filtering to restrict access to GV-CS1320. Figure 4-18 To enable the IP Filter function: 1. Enable IP Filtering: Enable the IP Filtering function. 2. Filtered IP: Type the IP address from which you want to restrict the access.

  • Page 83: Snmp Setting

    2. To enable access to Read/Write Name, type a community string. This will serve as a password to allow read and write access to GV-CS1320 from the SNMP software. 3. To enable Read Only Name, type a community string to allow read-only access to the camera from the SNMP software.
  • Page 84 7. Type the Authentication Password and Current Password (Encrypted). You will need to type these passwords in the SNMP software to be able to access GV-CS1320. 8. To enable access to Read Only Name, type a community string to allows read-only access to GV-CS1320, and set up the Authentication Type, Authentication Password and the Current Password (Encrypted).

  • Page 85: Date And Time Settings

    4.5 Management The Management section includes the settings of data and time and user account. You can also view the firmware version and execute certain system operations. 4.5.1 Date and Time Settings The date and time settings are used for date and time stamps on the image. Figure 4-20...
  • Page 86 [Date & Time on GV-IPCAM] Displays the current date and time on GV-CS1320 [Time Zone] Sets the time zone for local settings. Select Enable Daylight Saving Tim to automatically adjust GV-CS1320 for daylight saving time. Select the Start and Stop time to enable the daylight saving function.

  • Page 87: User Account

    4.5.2 User Account You can change the Administrator’s login name and password. • The default Administrator login name and password are admin. • To remain logged in after reboot, select Disable auto logout after reboot. Figure 4-21...

  • Page 88: Log Information

    Administrator Mode 4.5.3 Log Information The log information contains dump data that is used by service personnel for analyzing problems. Figure 4-22...
  • Page 89 4.5.4 Tools You can use additional tools to execute certain system operations and view the firmware version. Figure 4-23...
  • Page 90 Reboot Time: Use the drop-down lists to specify the time for automatic reboot. [Firmware Update] Displays the firmware version of GV-CS1320. [System Settings] Clicking the first Load Default button will restore GV-CS1320 to factory default settings. Clicking the second Load Default button will restore GV-CS1320 to factory default settings (Except network).
  • Page 91 4.5.5 Language You can select the language for the Web interface. Figure 4-24 Use the Language drop-down list to select a language for the Web interface. By default, the language on the Web interface will be the same with the one used for the operating system.
  • Page 92 Protocol (VoIP) calls. You can connect to a SIP server and configure VoIP service on the setting page. The GV-CS1320 can then place a call to the operator with an IP phone or a computer with VoIP software. With VoIP, the operator can communication with the visitor and enter the access code to open the door.
  • Page 93 [SIP Server Setting] Select Enable to apply the following setting: User Name: Type the phone number of GV-CS1320 registered on SIP Server. Password: Type the password of GV-CS1320 registered on SIP Server. SIP Server Address: Type the IP Address of SIP Server.
  • Page 94 Administrator Mode [SIP Incoming Call Setting] Select Decline to reject phone calls from SIP server to GV-CS1320. It indicates that the operator cannot talk to the visitor. [SIP Outgoing Call Setting] Select Enable Alternate to allow GV-CS1320 to make phone calls to at most three phone numbers registered on SIP server.

  • Page 95: Chapter 5 Advanced Applications

    5. Do not turn the power off for 10 minutes after the firmware is updated. 6. If firmware upgrade fails, you will need to restore the GV-CS1320 to the default settings. For details, see 5.3 Restoring to Factory Default Settings in the User’s Manual.

  • Page 96: Using The Web Interface

    Advanced Applications 5.1.1 Using the Web Interface 1. In the Live View window, click the Show System Menu button (No. 8, Figure 3-4) and select Remote Config. This dialog box appears. Figure 5-1 2. Click the Browse button to locate the firmware file (.img) saved at your local computer. 3.

  • Page 97: Using The Ip Device Utility

    5.1.2 Using the IP Device Utility The IP Device Utility provides a direct way to upgrade the firmware for multiple cameras and/or camera access controllers. Note the computer used to upgrade firmware must be under the same network of the camera / the camera access controller. 1.
  • Page 98 Advanced Applications 4. Double-click a camera / a camera access controller in the list. This dialog box appears. Figure 5-3 5. Click the Firmware Upgrade tab. This dialog box appears. Figure 5-4 6. Click the Browse button to locate the firmware file (.img) saved at your local computer. 7.

  • Page 99: Backing Up And Restoring Settings

    5.2 Backing Up and Restoring Settings With the IP Device Utility included on the Software DVD, you can back up the configurations in GV-CS1320, and restore the backup data to the current unit or import it to another unit. 5.2.1 Backing Up the Settings 1.

  • Page 100: Restoring The Settings

    Advanced Applications 5.2.2 Restoring the Settings 1. In Figure 5-3, click the Import Settings tab. This dialog box appears. Figure 5-6 2. Click the Browse button to locate the exported file (.dat). 3. Select Upgrade all devices to apply the settings to all devices of the same model in the same LAN.

  • Page 101: Restoring To Factory Default Settings

    5.3 Restoring to Factory Default Settings You can restore GV-CS1320 to factory default settings using the Web interface or directly on the camera. To restore to default settings using the Web interface: 1. In the left menu, select Management and select Tools.

  • Page 102: Verifying Watermark

    Advanced Applications 5.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of its creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark], 4.1.1 Video Settings.

  • Page 103: The Watermark Proof Window

    5.4.3 The Watermark Proof Window Figure 5-7 The controls in the window: No. Name Description Open File Opens the recorded file. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 104: Chapter 6 Dvr Configurations

    The above maximum numbers of streams are based on the maximum resolution for the camera access controller and the codec H.264. By default, GV-CS1320 is in dual streams and will take up 2 streams when connected to GV-System (GV-DVR/NVR) / GV-VMS.
  • Page 105 GV-DVR / NVR / VMS Connection Figure 6-1...
  • Page 106 DVR Configurations 6.1 Setting up GV-CS1320 on GV-System To set up GV-CS1320 and receive live view on the GV-System, follow these steps: On the main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install. This dialog box appears.
  • Page 107 Click Add Camera. This dialog box appears. Figure 6-3 Type the IP address, username and password of GV-CS1320. Modify the default HTTP port if necessary. Select GeoVision from the Brand drop-down list and select the model from the Device drop-down list. This dialog box appears.
  • Page 108 DVR Configurations Click the listed camera access controller and select Display position to map the IP camera access controller to a channel on the GV-System. Figure 6-5 The Statue column should display “Connected”. Click OK.

  • Page 109: Customizing The Basic Settings

    6.1.1 Customizing the Basic Settings After GV-CS1320 is connected and assigned with a display position, you can configure the GV-CS1320’s settings such as frame rate, codec type and resolution. Right-click the desired camera access controller to see the following list of options: Figure 6-6 Remote Camera Setting: Accesses the configuration interface of the connected device.
  • Page 110 Frames to keep in live view buffer: Specifies the number of frames to keep in the live view buffer. Recording Codec Format: Specifies whether to record in standard or GeoVision type of MJPEG H.264 codec. Automatically Adjust DST: If enabled, the time on the GV-IP device Web interface will be synchronized with the time of the GV-System when DST period starts or ends on the GV-System.
  • Page 111 6.2 Setting up GV-CS1320 on GV-VMS Follow the steps below to manually connect your GV-CS1320 to GV-VMS. 1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install. Figure 6-7 2. Click Add Camera .
  • Page 112 Port: Modify the video streaming port number if necessary. 6. Click Apply to add the GV-CS1320 to the list. 7. To connect the added GV-CS1320, click the box besides the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bit rate being displayed in the correspondent columns.

  • Page 113: Chapter 7 Mobile Phone Connection

    Chapter 7 Mobile Phone Connection Using iPhone, iPod Touch, iPad or Android Smartphones, you can now remotely watch live view with GV-CS1320. The latest information on GeoVision mobile applications is available at http://www.geovision.com.tw/products.php?c1=14 Click the link and select the GV-Access...

  • Page 114: Chapter 8 Connecting To Gv-I/O Box

    Chapter 8 Connecting to GV-I/O Box 4 Ports GV-I/O Box 4 Ports provides extra protection for GV-CS1320. The wiring of a locking device to be secured inside the door can prevent outside intruders from shorting the wires together and opening the door.

  • Page 115: Physical Connection

    2. GV-I/O Box 8 Ports and GV-I/O Box 16 Ports are not supported. 3. When GV-I/O Box 4 Ports is properly installed in the application, the door sensor (yellow) and door button (light red) wires of GV-CS1320 will no longer be effective.
  • Page 116 8.2 Setting up GV-CS1320 After establishing connections among GV-CS1320, GV-I/O Box, door button and sensors, you need to set up GV-CS1320 to identify all these connected input devices. 1. Log on the Web interface of GV-CS1320. 2. Under Access Control, select Extended IOBOX Configuration to access the Input and Output settings of GV-I/O Box.
  • Page 117 GV-ASManager. If Tamper is selected on GV-ASManager, GV- CS1320 will send forth alarm sound. Note: For the alarm sound to be sent by GV-CS1320, the corresponding settings must be specified on GV-ASManager first. [Output Ports Function] Electric Lock: The lock output is triggered when the correct card is presented to open the locking device.
  • Page 118 Note: 1. GV-I/O Box application is only supported by the Authentication Mode of Door Entry and Exit Control. Parking and Elevator Control related functions are not supported. 2. GV-I/O Box 4 Ports is supported by GV-CS1320 firmware V1.11 or later.

  • Page 119: Specifications

    Specifications Camera Image Sensor 1/2.8" progressive scan super low lux CMOS Picture Elements 1920 (H) x 1080 (V) Minimum Illumination 0.02 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) S/N Ratio 52 dB Optics Lens Megapixel Day / Night function...
  • Page 120 Specifications Frame Rate 15 fps at 1920 x 1080 Brightness, Contrast, Saturation, Sharpness, Gamma, Image Setting White Balance, Image Orientation, Shutter Speed Audio Compression G.711, AAC (Optional) * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).

  • Page 121: Web Interface

    General Operating Temperature -20°C ~ 50 °C (-4 °F ~ 122 °F) Humidity 10% to 90% (no condensation) Power Source 12V DC, 2.5A / PoE (IEEE 802.3at) Maximum Power 25.5 W Consumption Regulatory CE, FCC, RCM, RoHS compliant Dimension 137 x 80 x 34.5 mm (5.4 x 3.15 x 1.36 in) Weight 315 g (0.69 lb) Web Interface...
  • Page 122 Specifications Event Buffer 50,000 events and log data RS-485 Interface 1 RS-485 interface for GV-Readers (max. 2 readers) 1 TCP/IP interface for GV-CR420, GV-GF1921 / 1922 and TCP/IP Interface GV-FR2020 (max. 2 readers) Communication Protocol TCP/IP Digital I/O 2 inputs, dry contact NO/NC Supported ID Formats 1 relay outputs (30V DC, 0.5A) All specifications are subject to change without notice.

  • Page 123: Rtsp Protocol Support

    Appendix A. RTSP Protocol Support The camera reader can support RTSP protocol for both video and audio streaming. If you are using Quick Time player, use the following RTSP command: rtsp://<IP of the camera reader>:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp If you are using VLC player, use the following RTSP command: rtsp://<ID>:<Password>@<IP of the camera reader>:8554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:8554/CH001.sdp Note:...

  • Page 124: The Cgi Command

    Appendix B. The CGI Command You can use the CGI command to obtain a snapshot of the live view without logging in the Web interface or to access the User Account Web interface. For a camera reader with the following details: IP address: 192.168.2.11 Username: admin Password: admin...
