GV-CS1320 Camera Access Controller
User's Manual
Before attempting to connect or operate this product, please
read these instructions carefully and save this manual for future use.
CS1320V302-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-CS1320 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-CS1320

Summary of Contents for GeoVision GV-CS1320

  • Page 1 GV-CS1320 Camera Access Controller User’s Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. CS1320V302-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    1.6.1 Connecting RS485 Readers ..............12 1.6.2 Connecting Network Readers ..............13 1.6.3 Connecting Input Devices to GV-CS1320 ..........13 1.6.4 Connecting an Output Device to GV-CS1320 ..........14 1.6.5 Connecting GV-CS1320 to PC..............15 1.6.6 Connecting the Power ................17 1.7 LED Status and Beeper..................18 Chapter 2 Getting Started ...........19...
  • Page 4 3.2.3 Snapshot of a Live Video ................30 3.2.4 Video Recording..................30 3.2.5 Digital PTZ ....................30 3.2.6 Wide Angle Lens Dewarping ..............31 3.2.7 Picture-in-Picture and Picture-and-Picture View ........32 3.2.8 Alarm Notification ..................34 3.2.9 Video and Audio Configuration ..............35 3.2.10 Remote Configuration ................36 3.2.11 Camera Name Display ................36 3.2.12 Image Enhancement ................36 Chapter 4 Administrator Mode ...........37...
  • Page 5 5.4.2 Running Watermark Proof................75 5.4.3 The Watermark Proof Window ..............76 Chapter 6 GV-DVR / NVR / VMS Configurations ....77 6.1 Setting up GV-CS1320 on GV-DVR / NVR ............78 6.1.1 Customizing the Basic Settings..............80 6.2 Setting up GV-CS1320 on GV-VMS...............82 Chapter 7 Mobile Phone Connection .........84 Chapter 8 Connecting to GV-I/O Box 4 Ports....85...

  • Page 6: Naming And Definition

    GV-FWC data, paired to Face IDs, to controllers either through TCP/IP or Wiegand connection. GV-CS1320 is compatible with GV-GF1921 / 1922. The reader supports three operation modes for access control: Fingerprint Only, GV-GF Fingerprint Readers Fingerprint + Card and Card Only. Readers with optical and capacitance sensors are available.
  • Page 7 A small but capable device, the GV-I/O Box 4 Ports V1.2 provides 4 GV-I/O Box 4 Ports inputs and 4 relay outputs. It supports both DC and AC output V1.2 voltages, and provides a USB port for PC connection. GV-RK1352 is a 13.56 MHz card reader with keypad.

  • Page 8: Installation Considerations

    When placed at a building gate, GV-CS1320 should be about 1.4-1.5 meters above the ground. • When placed at a parking lot gate, GV-CS1320 should be about 1.2 meters above the ground to match the height of vehicles. Face Detection Limitations •...
  • Page 9 Lighting Conditions • Avoid placing GV-CS1320 where the light source is directly behind the subject. • Prevent light from directly falling onto the GV-CS1320’s camera lens.

  • Page 10: Chapter 1 Introduction

    Introduction Chapter 1 Introduction GV-CS1320 is an access controller with a built-in 2 MP camera and 13.56 MHz reader. GV-CS1320 recognizes identification cards and grants access to up to 100,000 users accordingly. With the integration of the wide angle camera, the Card and Face Mode enables GV-CS1320 to perform face detection together with card verification before access can be granted.
  • Page 11 There are 3 types of notifications allowing the operator to communicate with the visitor and grand access. 1. GV-ASNotify Program: Visitors requesting entry permits can use the touch pad to be granted access. When CS1320 is connected to GV-ASManager over th e network, GV-ASNotify will generate a notification message whenever the touch pad is activated.
  • Page 12 Figure 1-3 3. VoIP Calls: When the touchpad is activated, GV-CS1320 will place a call to the operator through the Internet using VoIP. The operator can then communicate with the visitor and enter the access code to open the door.

  • Page 13: Key Features

    Reader • Built-in 13.56 MHz Reader (Mifare DESFire, Mifare Plus and Mifare Classic) • Support fo r GV-Proximity Cards with GID (GeoVision identifier) to enhance security • Access by card plus face detection • RS-485 and network interfaces for connecting up to 2 readers Access Control •...

  • Page 14: Packing List

    1 relay output (Electric Lock) • Support for GV-I/O Box 4 Ports for sensor, alarm application and doorbell activation 1.2 Pack ing List • • GV-CS1320 Mounting Plate • • Standard Screw x 2 Plastic Screw Anchor x 2 •...

  • Page 15: System Requirements

    1.3 System Requirements To access the functions and settings of GV-CS1320 on the We b interface, ensure your PC has good network connection and use one of the following web browsers: • Internet Exp lorer 9 x or later •...
  • Page 16 Introduction GV-CS1320 Firmware Version Software V3.00 V3.01 V3.02 GV-ASManager V5.1.1 V5.2.0 GV-VMS V17.1 V17.3.0 GV-DVR / NVR V8.7.6.0 V8.8 GV-Control Center V3.5.1 V3.6.0 GV-Failover Server V1.1.0.0 with Patch GV-Redundant Server V1.1.0.0 with Patch GV-Recording Server V1.4.0.0 V1.4.2 GV-Edge Recording V1.4.0.0...

  • Page 17: Physical Description

    Figure 1-5 . Name Function Lens Receives image. Micro phone Receives sound from GV-CS1320. d Reader eads ID cards or ID tags. IR LEDs Automatically illuminates for night time use. Speaker Talks to the surveillance ar ea from the local computer.

  • Page 18: Installation

    Introduction 1.5 Installation 1.5.1 Wire Definition The wire assignment of the GV-CS1320 cable data is illustrated below. Figure 1-6 Wire Definition Wire Definition RJ-45 Ethernet Blue RS-485 + 12V DC Light Blue RS-485 - Black Gray Door NO Yellow Sensor IN1...

  • Page 19: Installing Gv-Cs1320

    1.5.2 Installing GV-CS1320 After the locati on of GV-CS1320 is decided, follow the steps below to install the camera access controller. Note: You will need to prepare a single gang power box for wall mount installation. . Attach the sin gle gang power box to the wall.

  • Page 20: Replacing The Silica Gel Bag

    Introduction 1.5.3 Replacing the Silica Gel Bag If you opened the compartment cover at the back of your GV-CS1320 to change a new Micro SD card, you must follow the steps below to replace the original silica gel bag with a new one.

  • Page 21: Connecting Gv-Cs1320

    GV-CS1320 can establish RS-485 connection with up to 2 GV-Readers. Connect the RS- 485 wires from the GV-CS1320 to the reader. The 12V DC and GN D wires of the GV- CS1320 can be used to power the readers, but you will need to set up a separate power source if the total power consumption (including output devices) exceeds 12V.

  • Page 22: Connecting Network Readers

    Wire color Definition Yellow Sensor IN1 Light Red Button IN2 Brown IN COM Note: You can connect a GV-I/O Box to your GV-CS1320 to give an extra layer of security. For details, see Chapter 8 Connecting to GV-I/O Box 4 Ports.

  • Page 23: Connecting An Output Device To Gv-Cs1320

    (+) point on the locking device to the Door COM wire on GV-CS1320, connect the two (-) points of the locking device and the external power supply together, and connect the (+) point on the external power supply to the Door NO or Door NC wire on GV-CS1320 based on the state of the locking device.

  • Page 24: Connecting Gv-Cs1320 To Pc

    Introduction 1.6.5 Connecting GV-CS1320 to PC Connecting GV-CS1320 to a computer enables you to access its Web interfac e and connect it to GV-ASManager if the computer is installed with GV-ASManager. T he computer running GV-ASManager software can be used to monitor the access information and alarm messages from GV-CS1320.
  • Page 25 15, GV-ASNotify in the GV-ASManager User’s Manual. Figure 1-14 Note: 1. GV-CS1320 is only compatible with GV-ASManager V4.3.5.0 or later. 2. While GV-CS1320 is performing a power reset, duplicate messages may be displayed in the System Event Log on GV-ASManager.

  • Page 26: Connecting The Power

    1. Power should only be applied to the unit when all connections are completed and tested. 2. GV-CS1320 produces an output voltage of 12V. You will need to connect an external power supply if the total power consumption exceeds 12V after readers and output...

  • Page 27: Led Status And Beeper

    1.7 LED Status and Beeper Normally, the LED on GV-CS1320 is blue during standby mode and the LED flashes green when a ca rd is granted access. The LED status and beeper under different conditions are listed below Condition Beeper...

  • Page 28: Chapter 2 Getting Started

    IP address. See 2.2 Checking the Dynamic IP Address. If GV-CS1320 is installed in a LAN without the DHCP server, the default IP address 192.168.0.10 will be applied. You also can assign a different static IP.

  • Page 29: Creating Login Credential

    On the GV-IP Device Utility window, click to search for your GV-CS1320. Double-click your GV-CS1320 in the GV-IP Device Utility list. This dialog box appears. Figure 2-1 Click the Create User Account tab to type a new username and password. Note that the new password must meet the password strength requirements.

  • Page 30: Checking The Dynamic Ip Address

    IP devices connected in the same LAN. Click the Name or Mac Address column to sort. Find GV-CS1320 with its MAC address, click on its IP address and select Web Page. Figure 2-2 On the login page, enter your username and password to login. See 2.1 Creating Login Credentials.
  • Page 31 . If Dynamic IP Address or PPPoE is enabled, you need to know which IP address GV-CS1320 will receive from the DHCP server or ISP to log in. If your GV-CS1320 in installed in a LAN, use the GV-IP Device Utility to look up its curren t dynamic address.

  • Page 32: Chapter 3 Accessing The Camera Access Controller

    3.1 Accessing Your Surveillance Images Start the Internet Explorer browser. Type the IP address or domain name of GV-CS1320 in the Location / Address field of your browser. Figure 3-1 Enter your username and password.
  • Page 33 Connect to access the full functioning user interface. Figure 3-2 Note: To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one-time installation of GeoVision’s ActiveX component onto your computer.

  • Page 34: Functions Featured On The Main Page

    3 Microphone Talks to the surveillance area from the local computer. 4 Speaker Listens to the audio around GV-CS1320. Takes a snapshot of live video. 5 Snapshot --- See 3.2.3 Snapshot of a Live Video. Records live video to the local computer.
  • Page 35 Switches to full screen view. Right-click the image to have these options: Snapshot, Digital PTZ, Wide le Lens Dewarping, Wide Angle Setting, PIP and PAP. 7 Full Screen --- See 3.2.5 Digital PTZ --- See 3.2.6 Wide Angle Lens Dewarping --- See 3.2.7 Picture-in-Picture and Pictu re-and-Picture View...

  • Page 36: The Control Panel Of The Live View Window

    Figure 3-4 [Information] Displays the version of GV-CS1320, local time of the local computer, host time of GV-CS1320, and the number of users logging in to GV-CS1320. [Video] Displays the current video codec, resolution and data rates.
  • Page 37 Sharpness: Adjusts the sharpness of the image Gamma: Adjusts the relative proportions of bright and dark areas White balance: GV-CS1320 automatically adjusts the color to be closest to the image you are viewing. You can choose one of the four presets: Auto, Outdoor, Indoor, and...
  • Page 38 CS1320 to adjust exposure based on the full live view. Select Regional Metering for GV-CS1320 to adjust exposure of specified zones. Draw directly on the live view and a block marked with “AE (automatic exposure)” appears. You can establish up to 4 zones.

  • Page 39: Snapshot Of A Live Video

    4. To stop recording, click the Stop button (No. 2, Figure 3-3). 3.2.5 Digital PTZ The Digital PTZ (DPTZ) function of GV-CS1320 allows you to simulate the PTZ movement on the screen. 1. Right-click on the live view to display a drop-down list.

  • Page 40: Wide Angle Lens Dewarping

    Accessing the Camera Access Controller 3.2.6 Wide Angle Lens Dewarping Use the Wide Angle Lens Dewarping function to reduce the warping of live view. 1. Right-click on the live view to display a drop-down list. 2. Select Wide Angle Setting. The Wide Angle Dewarping Setting window appears. Figure 3-7 3.

  • Page 41: Picture-In-Picture And Picture-And-Picture View

    3.2.7 Picture-in-Picture and Picture-and-Picture View Two types of close-up views are available to provide clear and detailed image s of the surveillance area: Picture-in-Picture (PIP) and Picture-an d Picture (PAP). After entering the live view window, the image is displayed in PIP mode by default. Picture-in-Picture View With the Picture in Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 42 Accessing the Camera Access Controller Picture-and-Picture View With the Picture and Picture (PAP) view, you can create a spli t video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 3-9 Right-click the l ive view and select PAP.

  • Page 43: Alarm Notification

    3.2.8 Alarm Notification After motion detection, you can view up to four captured images. Captured Images Figure 3-10 or this function to work, click the Show System Menu butt on (No. 8, Figure 3-3), and select Alarm Notify. In the pop-up dialog box, configure the followin g settings.

  • Page 44: Video And Audio Configuration

    Accessing the Camera Access Controller 3.2.9 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communicatio n and set the number of frames to keep for live view buffer. Clic k the Show System Menu button (No. 9, Figure 3-3), and select Video and Audio Configuration.

  • Page 45: Remote Configuration

    3.2.10 Remote Configuration You can upgrade firmware over the network. Click the Show System Menu button (No. 9, Figure 3-3), and select Remote Config. For details, see 5.1.1 Using the Web Interface. 3.2.11 Camera Name Display To display the camera access controller’s name on the image, click the Show System Menu button (No.

  • Page 46: Chapter 4 Administrator Mode

    Administrator Mode Chapter 4 Administrator Mode The Administrator can access system configuration of GV-CS1320 through the network. The following configuration categories are available: Video, Access Control, Events and Alerts, Network, Management and SIP. Figure 4-1 List of Menu Options Find the topic of interest by referring to the section number prefixed to each option.

  • Page 47: Video

    4.1 Video and Motion GV-CS1320 supports dual streams, Streaming 1 and Streaming 2, which allow separate codec and resolutions settings for a single video transmission. In a bandwidth-limited network, such as mobile phone surveillance, this dual-stream feature allows you to view live video in lower resolution (Streaming 2), and record in highest resolution (Streaming 1) at the same time.

  • Page 48: Video Settings

    Administrator Mode 4.1.1 Video Settings Figure 4-2a...
  • Page 49 Figure 4-2b [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended frame rate. [Video Signal Type] Configure the codec type, signal format, resolution and frame rate. Select between H.264 and MJPEG as the codec type. The codec options, resolutions and maximum frame rates are listed as below: Streams Codec Options...
  • Page 50 Camera Name, Date and System Time. [Text Overlay Settings (OSD)] Displays camera name, date, and/or time on the live view and recorded videos when viewing through GeoVision software and third-party software through ONVIF and RTSP. Camera Name: Type the camera name.
  • Page 51 [Special View Setting] D/N: Sets the Day/Night mode of GV-CS1320. Auto: Select Auto for the GV-CS1320 to detect the amount of light present and automatically switch to monochrome in a poorly-lit scene. Use the drop-down list to adjust the sensitivity level of light sensor from 1 to 5. The higher the value, the more sensitive GV-CS1320 is to light.

  • Page 52: Text Overlay

    Administrator Mode 4.1.2 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings.

  • Page 53: Access Control

    4.2 Access Control Under Access Control, there are two sections, Basic Setting and Extended Device, you can choose from to configure the controller settings on the left menu of the Web interface. 4.2.1 Basic Setting The Basic Setting section covers function setting, door parameter configuration, card setting, input and other settings.
  • Page 54 [Door/Gate #] [Elevator] Select the function type and the authentication mode for the use of the Doors / Gates / Elevators. Function: Select the function for GV-CS1320 to be installed in a general door / parking place and an elevator for entry or exit access control.
  • Page 55 Info IP: Enter the IP address of the next corresponding controller. Note: GV-CS1320 does not support fire sensor inputs. However, the output of GV-CS1320 will be triggered when the fire sensors on one door of its associated controller is triggered.
  • Page 56 Administrator Mode 4.2.1.2 Door Parameter The content of the Parameter Configuration page change is based on your settings for Door/Gate # in the Function Configuration page (Figure 4-6). Figure 4-7...
  • Page 57 Relay on Time See the same option above. Fire Action Alarm Continuous See the same option above. Time Note: GV-CS1320 does not support fire sensor inputs. The Fire Action and Global Fire Alarm options must work with the Anti-Pass Back (APB).
  • Page 58 Administrator Mode [Alarm] Select Yes or No to enable or disable the alarm function. The default settings for all the alarms are set to NO. • When Door Control is selected in the Function Configuration page (Figure 4-6), these options become available: Option Description Door Held Open...
  • Page 59 [Card Identify] ◼ Identification type: Set the built-in card reader of GV-CS1320 to read UID (unique identification) or GID (GeoVision identification) on GV-AS ID F Card / Key Fob. To use GeoVision Identification (GID), make sure there are two numbers on your GV- AS ID Cards / Key Fobs as shown below.
  • Page 60 [Input Function] Set the input contact types to be normally open or normally closed. The default settings for all the inputs are set to NO. 4.2.1.5 Other Setting Here you can specify the encryption code and device port of GV-CS1320 which are used when connecting to GV-ASManager. Figure 4-11 ◼...

  • Page 61: Extended Device

    4.2.2 Extended Device You can define the GV-Readers and GV-GF Fingerprint Readers connected to GV-CS1320 through RS-485 or network connection. 4.2.2.1 Extended Reader Figure 4-12 [GV-Reader / CR420 / GF1921 / 1922 Function] Define the readers connected to the controller, and then use the Function drop-down list to select the door option associated with the reader.
  • Page 62 Administrator Mode [GeoFinger Server IP Address] To allow GV-ASManager to receive data from the GV-GF1921 / 1922 defined on this page during remote fingerprint enrollment, type the IP address and port of GV-ASManager server. By default the port number is 2167 Note: 1.

  • Page 63: Events And Alerts

    4.3 Events and Alerts 4.3.1 RTSP/ONVIF The RTSP enables video and audio streaming to your mobile phone. And, you can configure the ONVIF settings for a third-party DVR and access controllers to connect to GV-CS1320. Figure 4-13 [RTSP] Activate Link: Enable the RTSP protocol.

  • Page 64: Network

    Administrator Mode 4.4 Network The Network section includes some basic but important network configurations that enable the GV-CS1320 to be connected to a TCP/IP network. 4.4.1 Status You can access an overview of GV-CS1320’s network status. Figure 4-14 4.4.2 LAN According to your network environment, select among DHCP, static IP and PPPoE.

  • Page 65: Lan

    IP address to GV-CS1320. Click the Test DHCP to see the currently assigned IP address or look up the address using GV-IP Device Utility. Static IP address: Assign a static IP or fixed IP to GV-CS1320. Type GV-CS1320’s IP address, Subnet Mask, Router/Gateway, Primary DNS server and Secondary DNS server.

  • Page 66: Advanced Tcp/Ip

    Administrator Mode 4.4.3 Advanced TCP/IP This section introduces the advanced TCP/IP settings, including the DDNS Server, HTTPS port, streaming port, UPnP and QoS. Figure 4-16...
  • Page 67 2. Service Provider: Select the DDNS service provider you have registered with. 3. Host Name: Type the host name used to link to GV-CS1320. For users of GeoVision DDNS Server, it is unnecessary to fill the field because the system will detect the host name automatically.
  • Page 68 DSCP value will tell the router what service level to be applied, e.g. the bandwidth amount. This value ranges from 0 to 63 in decimal format. The default value is 0, meaning QoS is disabled. Note: If you do not intend to connect GV-CS1320 to the network, disable this function to prevent automatic reboot.

  • Page 69: Ip Filtering

    4.4.4 IP Filtering The Administrator can set IP filtering to restrict access to GV-CS1320. Figure 4-17 To enable the IP Filter function: 1. Enable IP Filtering: Enable the IP Filtering function. 2. Filtered IP: Type the IP address from which you want to restrict the access.

  • Page 70: Snmp Setting

    7. Type the Authentication Password and Current Password (Encrypted). You will need to type these passwords in the SNMP software to be able to access GV-CS1320. 8. To enable access to Read Only Name, type a community string to allows read-only access to GV-CS1320, and set up the Authentication Type, Authentication Password and the Current Password (Encrypted).

  • Page 71: Management

    4.5 Management The Management section includes the settings of data and time and user account. You can also view the firmware version and execute certain system operations. 4.5.1 Date and Time The date and time settings are used for date and time stamps on the image. Figure 4-19...

  • Page 72: Storage Setting

    [Date & Time on GV-IPCAM] Displays the current date and time on GV-CS1320 [Time Zone] Sets the time zone for local settings. Select Enable Daylight Saving Tim to automatically adjust GV-CS1320 for daylight saving time. Select the Start and Stop time to enable the daylight saving function.

  • Page 73: User Account

    4.5.3 User Account You can change the Administrator’s login name and password. To remain logged in after reboot, select Disable auto logout after reboot. Figure 4-21 4.5.4 Log Information The log information contains dump data that is used by service personnel for analyzing problems.

  • Page 74: Tools

    You can use additional tools to execute certain system operations and view the firmware version. Figure 4-22 [Host Settings] Enter a descriptive name for GV-CS1320. [Auto Reboot Setup] Select Enable to activate automatic reboot and specify the time for reboot in the sub fields.

  • Page 75: Language

    [System Settings] Clicking the first Load Default button will restore GV-CS1320 to factory default settings. Clicking the second Load Default button will restore GV-CS1320 to factory default settings (Except network). Note: After clicking the first default function, you will need to configure the camera access controller’s network setting again.

  • Page 76: Sip

    Protocol (VoIP) calls. You can connect to a SIP server and configure VoIP service on the setting page. The GV-CS1320 can then place a call to the operator with an IP phone or a computer with VoIP software. With VoIP, the operator can communication with the visitor and enter the access code to open the door.
  • Page 77 The default port type is UDP. Change the port type if necessary. [SIP Outgoing Call Setting] Select Enable Alternate to allow GV-CS1320 to make phone calls to at most three phone numbers registered on SIP server. If unanswered, GV-CS1320 will automatically forward the call to the next two phone numbers.

  • Page 78: Chapter 5 Advanced Applications

    GeoVision for repair. 4. If firmware upgrade fails, you will need to restore the GV-CS1320 to the default settings. For details, see 5.3 Restoring to Factory Default Settings in the User’s Manual.

  • Page 79: Using The Web Interface

    5.1.1 Using the Web Interface 1. In the Live View window, click the Show System Menu button (No. 8, Figure 3-4) and select Remote Config. This dialog box appears. Figure 5-1 2. Click the Browse button to locate the firmware file (.img) saved at your local computer. 3.

  • Page 80: Using The Ip Device Utility

    IP devices connected under the same LAN. Click the Name or Mac Address column to sort. 3. Double-click a GV-CS1320 in the list to bring up a dialog box, and click the Firmware Upgrade tab. This dialog box appears.

  • Page 81: Backing Up And Restoring Settings

    5.2.1 Backing Up the Settings 1. Run GV-IP Device Utility and locate a GV-CS1320. See Steps 1-2 in 5.1.2 Using the IP Device Utility. 2. Double-click a GV-CS1320 in the list to bring up a dialog box, and click the Export Settings tab.

  • Page 82: Restoring The Settings

    Advanced Applications 5.2.2 Restoring the Settings 1. In Figure 5-3, click the Import Settings tab. This dialog box appears. Figure 5-4 2. Click the Browse button to locate the exported file (.dat). 3. Select Upgrade all devices to apply the settings to all devices of the same model in the same LAN.

  • Page 83: Restoring To Factory Default Settings

    5.3 Restoring to Factory Default Settings You can restore GV-CS1320 to factory default settings using the Web interface or directly on the camera. To restore to default settings using the Web interface: 1. In the left menu, select Management and select Tools.

  • Page 84: Verifying Watermark

    Advanced Applications 5.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of its creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark], 4.1.1 Video Settings.

  • Page 85: The Watermark Proof Window

    5.4.3 The Watermark Proof Window Figure 5-5 The controls in the window: No. Name Description Open File Opens the recorded file. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 86: Chapter 6 Gv-Dvr / Nvr / Vms Configurations

    The above maximum numbers of streams are based on the maximum resolution for the camera access controller and the codec H.264. By default, GV-CS1320 is in dual streams and will take up 2 streams when connected to GV-DVR / NVR / GV-VMS.

  • Page 87: Setting Up Gv-Cs1320 On Gv-Dvr / Nvr

    6.1 Setting up GV-CS1320 on GV-DVR / NVR To set up GV-CS1320 and receive live view on the GV-DVR / NVR, follow these steps: On the main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install. This dialog box appears.
  • Page 88 Figure 6-4 Click Query to acquire the information from GV-CS1320. The video streaming port should match the VSS port on GV-CS1320. The default port number is 10000. Click Apply. GV-CS1320 is added to the connection list. Click the listed camera access controller and select Display position to map the IP camera access controller to a channel on the GV-DVR / NVR.

  • Page 89: Customizing The Basic Settings

    6.1.1 Customizing the Basic Settings After GV-CS1320 is connected and assigned with a display position, you can configure the GV-CS1320’s settings such as frame rate, codec type and resolution. Right-click the desired camera access controller to see the following list of options: Figure 6-6 Remote Camera Setting: Accesses the configuration interface of the connected device.
  • Page 90 Frames to keep in live view buffer: Specifies the number of frames to keep in the live view buffer. Recording Codec Format: Specifies whether to record in standard or GeoVision type of MJPEG H.264 codec. Automatically Adjust DST: If enabled, the time on the GV-IP device Web interface will be synchronized with the time of the GV-DVR / NVR when DST period starts or ends on the GV-DVR / NVR.

  • Page 91: Setting Up Gv-Cs1320 On Gv-Vms

    6.2 Setting up GV-CS1320 on GV-VMS Follow the steps below to manually connect your GV-CS1320 to GV-VMS. 1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install. Figure 6-7 2. Click Add Camera .
  • Page 92 Port: Modify the video streaming port number if necessary. 6. Click Apply to add the GV-CS1320 to the list. 7. To connect the added GV-CS1320, click the box besides the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bit rate being displayed in the correspondent columns.

  • Page 93: Chapter 7 Mobile Phone Connection

    Chapter 7 Mobile Phone Connection Using iPhone, iPod Touch, iPad or Android Smartphones, you can now remotely watch live view with GV-CS1320. Find GV-Access App from our website for latest information.

  • Page 94: Chapter 8 Connecting To Gv-I/O Box 4 Ports

    Chapter 8 Connecting to GV-I/O Box 4 Ports GV-I/O Box 4 Ports provides extra protection for GV-CS1320. The wiring of a locking device to be secured inside the door can prevent outside intruders from shorting the wires together and opening the door.

  • Page 95: Physical Connection

    2. GV-I/O Box 8 Ports and GV-I/O Box 16 Ports are not supported. 3. When GV-I/O Box 4 Ports is properly installed in the application, the door sensor (yellow) and door button (light red) wires of GV-CS1320 will no longer be effective.

  • Page 96: Setting Up Gv-Cs1320

    8.2 Setting up GV-CS1320 After establishing connections among GV-CS1320, GV-I/O Box, door button and sensors, you need to set up GV-CS1320 to identify all these connected input devices. 1. Log on the Web interface of GV-CS1320. 2. Under Access Control, select Extended IOBOX Configuration to access the Input and Output settings of GV-I/O Box.
  • Page 97 Note: For the alarm sound to be sent by GV-CS1320, the corresponding settings must be specified on GV-ASManager first. [Output Ports Function] Electric Lock: The lock output is triggered when the correct card is presented to open the locking device.

  • Page 98: Appendix

    Appendix Appendix A. RTSP Protocol Support The camera reader can support RTSP protocol for both video and audio streaming. If you are using Quick Time player, use the following RTSP command: rtsp://<IP of the camera reader>:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp If you are using VLC player, use the following RTSP command: rtsp://<ID>:<Password>@<IP of the camera reader>:8554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:8554/CH001.sdp...
