1

Introduction

This guide provides guidance on the configuration, basic operation, and troubleshooting of the V2000
Amplifier Mainframe.
This guide will also provide some basic information on VIPEDIA-12 Router configuration, required for full
V2000 functionality.
The term 'PAVA system' will be used when referring to the system as a whole (VIPEDIA-12 + V2000 + other
related hardware).
The diagram below provides an overview of the configuration and commissioning process.
Safety and Precautions
Requirements
V2000 IP Configuration
V2000 static configuration
Upload static configuration
VIPEDIA-12 Dynamic
Commissioning
V2000 Dynamic Commissioning
Rack Power (BATTERY)
V2000 User's Manual
Summary of Task
Read the safety and precautions instructions and guidelines
1. Gather documentation, software tools, and set up PC
2. V2000 installed
No installation instructions are provided in this document. Refer to V2000
Installation Guide (U-0623-0291)
3. Power up the rack, MAINS power only
4. Configure all VIPEDIA-12 IP addresses
1. Ensure all V2000 Ethernet connections are removed.
2. Power up the first V2000 and configure IP address using the ASL Transfer Tool
3. Configure IP addresses of remaining V2000s in turn
4. Connect all V2000 Ethernet connections to the network.
5. Power up all V2000s (MAINS only)
1. Load the VIPEDIA-12 PAVA static configuration into the System Configuration
Tool
2. Add V2000s to the PAVA system configuration
3. Add battery if battery backup system used
4. Configure the frame settings
5. Configure the amplifiers and define the surveillance methods used
Upload the static configuration to all V2000s and VIPEDIA-12s using the ASL
Transfer Tool
1. Commission VIPEDIA-12 output limiter
2. Commission VIPEDIA-12 output clipper
3. Commission VIPEDIA-12 output surveillance generator
1. Commission V2000 input surveillance
2. Commission V2000 amplifier output surveillance
3. Commission V2000 DC-EOL surveillance
4. Commission V2000 earth leakage surveillance
5. Backup dynamic configuration
1. Power up the rack BATTERY power
2. Switch on V2000 BATTERY supply
U-0623-0383.docx – Issue: 05 complete, approved – 17/12/15
Page 5 of 36
Section Page
2 6
3.2 10
10
10
11
5 12
12
13
13
13
6 15
15
15
15
16
6.1.3 17
6.2.1 18
18
19
6.2.2 22
22
22
22
24
4.2.2 10
10
