4

Requirements

4.1 Documentation

V2000 Installation Guide (ASL document U-0623-0291)
VIPEDIA-12 User's Manual (ASL document U-0641-1605)
VIPEDIA-12 System Configuration Tool User's Manual (ASL document U-0701-0110) (optional)
EOL10K Installation Guide (ASL document U-0398-0656) (optional)
Firmware and Configuration Load Procedures (ASL document U-0641-2585) (optional)
Site specific system documentation with all V2000 IP addresses

4.2 V2000 Hardware

V2000 mainframe(s)
D500 (or D150) amplifier(s)
LSZDC surveillance card(s) (one required for each amplifier used)
Standby Interface card(s) (optional)
A RS485 data connection to PC (optional, for troubleshooting)
All hardware is to be installed in the rack and ready to use. Use the V2000 Installation Guide for guidance.
1.
There are two power switches on the front of the V2000: MAINS and BATTERY. Ensure these are
!
!
both switched OFF for all units.
2.
These two power switches are NOT isolation switches. For correct power isolation always use the
rack fitted isolation switches, or unplug the Mains and Battery input cables. (Note the V2000 may
take a few minutes for all power to be dissipated after power isolation. Observe front LEDs).

4.2.1 Rack MAINS Power

Switch the MAINS rack power ON, by operating the MAINS isolation switch installed onto the rack.
Do not switch the rack BATTERY power on at this point. If a battery backup system is used, make
!
!
sure the rack BATTERY isolation switch is OFF until a static battery configuration is uploaded into the
V2000. Details are in section 6.1.2 - V2000 Configuration.
For all V2000s in the rack:
The Processor LED will now flash at an interval of about 1 second.
The Comms LED will be off.
The Fault LED will now light.

4.2.2 Rack BATTERY Power

Frames require a battery configuration before the rack BATTERY isolation switch can be switched on.
Use the V2000 BATTERY front power switch after the frame is fully configured and commissioned.
V2000 User's Manual
U-0623-0383.docx – Issue: 05 complete, approved – 17/12/15
Page 10 of 36
