Page 1 Product Manual 26167V1 (Revision J, 5/2014) Original Instructions ® MicroNet TMR Digital Control This manual replaces manual 85584 for the MicroNet TMR. Manual 26167 consists of 2 volumes (26167V1 & 26167V2). Installation and Operation Manual...
Page 2 Revisions—Changes in this publication since the last revision are indicated by a black line alongside the text. Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly undertaken.
Page 3: Table Of Contents
1.2—Specifications and Compatibility ..............2 2. M TMR S ............3 HAPTER ICRO YSTEMS 2.1—MicroNet TMR ....................3 2.2—MicroNet TMR Operation ................14 2.3—Module Replacement ................... 15 2.4—Latent Fault Detection .................. 16 3. C ............ 18 HAPTER HASSIS ONFIGURATIONS 3.1—TMR Main Chassis ..................
Page 4 7. D I/O M ............101 HAPTER ISCRETE ODULES 7.1—Introduction ....................101 7.2—MicroNet TMR Discrete I/O Smart-Plus Module ........102 7.3—24/12 TMR Discrete I/O Module ..............114 7.4—MicroNet Discrete I/O Smart-Plus Module (HDDIO) ........128 7.5—48/24 Discrete Combo Module ..............138 ...
Page 5 Figure 2-13—SYS_INFO Block ................17 Figure 3-1—MicroNet TMR Main Chassis ............18 Figure 3-2—Outline Drawing of MicroNet TMR Main Chassis ......19 Figure 3-3—Mounting Template of MicroNet TMR Main Chassis ......20 Figure 3-4—MicroNet Plus 8-Slot I/O Chassis ............. 21 ...
Page 6 Figure 7-1—DI/DO Field Wire Shielding Example ..........101 Figure 7-2—MicroNet TMR Discrete I/O Smart-Plus Module ......102 Figure 7-3—MicroNet TMR Discrete I/O Smart-Plus Module Block Diagram ..103 Figure 7-4—Example TMR System Configuration ..........104 Figure 7-5—Wiring Diagram for a FT Relay/Discrete Input Module ....105 ...
Page 7 Manual 26167V1 MicroNet TMR Illustrations and Tables Figure 7-21—Latent Fault Detection Verification Graph–100–150 Vdc Circuitry ..................123 Figure 7-22—Jumper and Relay Location Diagram ........... 124 Figure 7-23—FT Relay/Discrete Input Module Labels ........124 Figure 7-24—Example Relay Output Wiring Diagram ........125 ...
Page 8 MicroNet TMR Manual 26167V1 Illustrations and Tables Figure 8-14—Example Fault Tolerant System Configuration ......188 Figure 8-15—MPU Interface Wiring to the TMR Analog Combo FTM (Speed 1, 2, & 3) ....................190 Figure 8-16—Proximity Interface Wiring to the TMR Analog Combo FTM (Speed 4) ....................190...
Page 9 Figure 8-84—Digital Speed Sensor Module Block Diagram ......297 Table 2-1—AI Redundancy Manager Truth Table ..........7 Table 4-1—MicroNet TMR Power Supply Requirements ........42 Table 4-2—Kernel Power Supply Troubleshooting ..........47 Table 4-3—MicroNet Plus Power Supply Requirements ........51 ...
Page 10 Table 8-6—LED Indications of Failure..............217 Table 8-7—LED Indications of Failure..............230 Table 8-8—LED Indications of Failure..............242 The following are trademarks of Woodward, Inc.: LINKnet LINKnet HT MicroNet MicroNet TMR RTCnet Woodward The following are trademarks of their respective companies: Dataforth (Dataforth Corporation) DeviceNet (Open DeviceNet Vendor Association, Inc.)
Page 11: Warnings And Notices
Start-up On- and off-highway Mobile Applications: Unless Woodward's control functions as the supervisory control, customer should install a system totally independent of the prime mover control system that...
Page 12: Electrostatic Discharge Awareness
Do not touch the components or conductors on a printed circuit board with your hands or with conductive devices. To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715 , Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.
Page 13: Regulatory Compliance
Manual 26167V1 MicroNet TMR Regulatory Compliance European Compliance for CE Marking: These listings are limited only to those units bearing the CE Marking. Declared to 2004/108/EC COUNCIL DIRECTIVE of 15 EMC Directive: Dec 2004 on the approximation of the laws of the Member States relating to electromagnetic compatibility and all applicable amendments.
Page 14 MicroNet TMR Manual 26167V1 A fixed wiring installation is required. The power supply mains should be properly fused according to the National Electrical Code. The recommended fuse is a European Type T fuse. Ground leakage current exceeds 3.5 mA. Grounding is required by the input PE terminal.
Page 15 Manual 26167V1 MicroNet TMR EXPLOSION HAZARD—Do not connect or disconnect while circuit is live unless area is known to be non-hazardous. Substitution of components may impair suitability for Class I, Division 2 applications. Do not remove or install power supply while circuit is live unless area is known to be non-hazardous.
Page 16 MicroNet TMR Manual 26167V1 Woodward...
Page 17: Chapter 1. General Information
18 VME slots. All slots are dedicated to the control section. The power supply for the MicroNet TMR main control chassis is a separate chassis which connects to either the lower right or left of the MicroNet TMR main control chassis. The power supply chassis contains redundant power supplies.
Page 18: Specifications And Compatibility
MicroNet TMR Manual 26167V1 The MicroNet TMR control may be expanded to a multi-chassis system using the Plus8 or Plus14 chassis options. For field upgrades, the expansion racks may also be the older Simplex6 or Simplex12 chassis. Each expansion chassis has dedicated power supply, control, and I/O sections located in a single chassis.
Page 19: Chapter 2. Micronet Tmr Systems
In this case, I/O is dedicated to a specific CPU. 2.1.1—MicroNet TMR Main Chassis In the MicroNet TMR Main Chassis, whether the TMR040 or TMR5200 CPUs are used, the I/O modules are associated with a particular Kernel. If that Kernel fails, the associated I/O modules are failed.
Page 20 MicroNet TMR Manual 26167V1 2.1.3 MicroNet TMR5200 Expansion Chassis With the TMR5200 systems, connection to up to 3 Expansion chassis is accomplished through Real Time Networks (RTNs) associated with each Kernel. There are 3 RTN networks. The TMR5200 system supports the MicroNet Plus 8 or 14 chassis and MicroNet Simplex 6 or 12 chassis.
Page 21: Figure 2-1-Double Exchange And Vote Structure
Manual 26167V1 MicroNet TMR 2.1.5—TMR CPU Theory The basis of this control’s fault tolerance architecture is to detect control related faults, annunciate these faults, and allow on-line service/replacement of modules and/or transducers to correct these faults. A CPU fault tolerance logic of 3-2-0 allows the control to function normally with any CPU module failed or removed.
Page 22 MicroNet TMR Manual 26167V1 2.1.6—TMR Inputs and Outputs In a full TMR application, I/O modules are also triplicated. Each Kernel would have the same module and any expansion chassis would be triplicated. Specific TMR I/O Modules and Field Terminal Modules (FTMs) are designed for this sort of application.
Page 23: Figure 2-2-Fault Tolerant Analog Input
Manual 26167V1 MicroNet TMR Figure 2-2—Fault Tolerant Analog Input Table 2-1—AI Redundancy Manager Truth Table Discrete Input Example Each discrete input can withstand up to two failures with no loss of control functionality. If any two of a discrete input’s three “legs” fail, the control uses the third healthy leg’s sensed input signal to control with.
Page 24 MicroNet TMR Manual 26167V1 A discrete input signal is determined to be faulty when the I/O Module or I/O Channel fails or when it is determined to be different then the voted-good value used by the application. If an input is determined to be faulty, the input is removed from the control’s voting logic and an input channel alarm is issued.
Page 25: Figure 2-4-Fault Tolerant Analog Output
Manual 26167V1 MicroNet TMR Figure 2-4—Fault Tolerant Analog Output Actuator Outputs Each actuator output can withstand up to two failures with no loss of output functionality. Any leg of an output channel can drive an output’s full current signal (4–20 mA or 20–160 mA). Each CPU generates an analog output command using a Redundancy manager and known good output channels.
Page 26: Figure 2-5-Fault Tolerant Single Coil Actuator Output
MicroNet TMR Manual 26167V1 Actuator outputs are treated the same way as the other analog outputs, with the exception of a an added precision resistor in the actuator output’s return path. This resistor is used to measure and detect ground loops and coil shortages that are possible when interfacing to an actuator.
Page 27: Figure 2-6-Fault Tolerant Dual Coil Actuator Output
Manual 26167V1 MicroNet TMR Figure 2-6—Fault Tolerant Dual Coil Actuator Output Relay Outputs A six relay configuration is used to form each fault tolerant relay output. When a relay output is closed, the contacts of all six relays are closed. Because of the series-parallel configuration that the relays are in, the failure of any individual relay will not cause the output to be open.
Page 28: Figure 2-7-Fault Tolerant Discrete Output
MicroNet TMR Manual 26167V1 Latent fault detection is provided with this control to detect any relay related failure without effecting the state of the overall relay output. Each individual relay output can be configured to use or not use latent fault detection. A latent fault detection test is performed periodically or on command.
Page 29: Figure 2-8-Input Flow
Manual 26167V1 MicroNet TMR 2.1.7—Simplex Inputs and Outputs The TMR system can also use Simplex I/O modules and FTMs. Typically these are used for non-critical signals although different levels of redundant and even TMR configurations can be supported with the correct application software and the correct selection and distribution of module and signals.
Page 30: Micronet Tmr Operation
2.2—MicroNet TMR Operation 2.2.1 Theory of Operation MicroNet TMR systems are designed for 3-2-0 operation. Thus, to start a system, at least 2 CPUs must be started with the same application. If the CPUs are started individually, the first CPU will wait forever for a second CPU and 2 CPUs will wait up to 10 seconds for the 3 CPU.
Page 31: Module Replacement
Note that power must be removed from the power supply input before a module is removed or inserted. Live insertion and removal of the TMR5200 and Remote RTN modules is allowed in a MicroNet TMR or Plus chassis. These modules should be reset immediately before removing them from the RESET chassis.
Page 32: Latent Fault Detection
MicroNet TMR Manual 26167V1 2.4—Latent Fault Detection Because a TMR system can tolerate single faults, it is possible for a fault to go undetected. Undetected faults are termed latent faults. If another fault occurs when a latent fault exists, the second fault could cause a shutdown. It is important to detect a latent fault in a TMR system so that it may be repaired before another fault occurs.
Page 33: Figure 2-13-Sys_Info Block
TEMP_ALM_x: Temperature alarm for Kernel A, B, or C. This output is directly from a fan temperature switch which will trip at 60.0 °C. Only applicable to the MicroNet and MicroNet TMR chassis. A_FAULT: The CPU A Fault Boolean will be set true when CPU A is not in sync.
Page 34: Chapter 3. Chassis Configurations
The fans run whenever power is applied to the system. The eighteen-slot MicroNet TMR control chassis is composed of three blocks with a motherboard inserted in the back of the assembly to make connections between the fans, switches, power supply chassis, and all three kernels.
Page 35: Figure 3-2-Outline Drawing Of Micronet Tmr Main Chassis
(#8-32 M4) should be installed to properly ground the chassis to the mounting plate.  For proper airflow, the installation should allow a 3” (8 cm) air gap above and below the chassis. Figure 3-2—Outline Drawing of MicroNet TMR Main Chassis Woodward...
Page 36: Figure 3-3-Mounting Template Of Micronet Tmr Main Chassis
Figure 3-3 shows the mounting template and fasteners to bulkhead mount the chassis. Rack mounting is not recommended. For proper airflow, the installation should allow a 3” air gap above and below the chassis. Figure 3-3—Mounting Template of MicroNet TMR Main Chassis Woodward...
Page 37: Expansion Micronet Plus 8-Slot I/O
Manual 26167V1 MicroNet TMR 3.2—Expansion MicroNet Plus 8-Slot I/O Figure 3-4—MicroNet Plus 8-Slot I/O Chassis The MicroNet Plus 8-slot chassis offers redundant RTN capability and more I/O slots than the MicroNet 6, as well as improvements in airflow and overall system reliability.
Page 38: Figure 3-5-Micronet Plus 8-Slot Chassis
MicroNet TMR Manual 26167V1 The MicroNet Plus 8-slot chassis is composed of two blocks with a motherboard inserted in the back of the assembly to make connections between the fans, switches, power supplies, and control modules. See Figure 3-5. The modules use the VERSAmodule Eurocard (VME) bus standard for connector specification and data transfer.
Page 39 24 Vdc power fault. Replacement fuses can be ordered as Woodward P/N 1641-1004. The system must be shut down to replace the fuses safely.
Page 40: Figure 3-6-Outline Drawing Of Micronet Plus 8-Slot Chassis
MicroNet TMR Manual 26167V1 Figure 3-6—Outline Drawing of MicroNet Plus 8-Slot Chassis 3.2.2—Installation Figure 3-7 shows the mounting template and fasteners to bulkhead mount the chassis. Rack mounting is not recommended. For proper airflow, the installation should allow a 3” air gap above and below the chassis.
Page 41: Expansion Micronet Plus 14-Slot I/O
Manual 26167V1 MicroNet TMR 3.3—Expansion MicroNet Plus 14-Slot I/O Figure 3-8—MicroNet Plus 14-Slot I/O Chassis The MicroNet Plus 14-slot chassis offers redundant RTN capability and more I/O slots, as well as improvements in airflow and overall system reliability. Features: ...
Page 42: Figure 3-9-Micronet Plus 14-Slot Chassis
MicroNet TMR Manual 26167V1 The MicroNet Plus chassis is composed of three blocks with a motherboard inserted in the back of the assembly to make connections between the fans, switches, power supplies, and control modules. See Figure 3-8. The modules use the VERSAmodule Eurocard (VME) bus standard for connector specification and data transfer.
Page 43 24 Vdc power fault. Replacement fuses can be ordered as Woodward P/N 1641-1004. The system must be shut down to replace the fuses safely.
Page 44: Figure 3-10-Outline Drawing Of Micronet Plus Chassis
MicroNet TMR Manual 26167V1 Figure 3-10—Outline Drawing of MicroNet Plus Chassis Woodward...
Page 45: Expansion Micronet Simplex 6-Slot I/O
Manual 26167V1 MicroNet TMR 3.3.2—Installation Figure 3-11 shows the mounting template and fasteners to bulkhead mount the chassis. Rack mounting is not recommended. For proper airflow, the installation should allow a 3” air gap above and below the chassis. Figure 3-11—Mounting Template of MicroNet Plus 14-Slot I/O Chassis 3.4—Expansion MicroNet Simplex 6-Slot I/O...
Page 46: Figure 3-12-Simplex Micronet Six Slot I/O
MicroNet TMR Manual 26167V1 Figure 3-12—Simplex MicroNet Six Slot I/O 3.4.1—Specification The MicroNet control is designed around a modular six slot chassis (block). Each block consists of a premolded cage with a fan for cooling and a temperature switch for high temperature detection. The chassis are cooled by forced air, and either a module or a module blank must be installed in every slot to maintain correct air flow.
Page 47: Figure 3-13-Outline Drawing Of Micronet Six Slot I/O
Manual 26167V1 MicroNet TMR NOTES:  Add ~2” (~5 cm) to the depth dimension to account for the cable saddles that are not shown on the outline drawing below.  The PE ground connection point is located underneath the left side of the chassis.
Page 48: Expansion Micronet Simplex 12-Slot I/O
MicroNet TMR Manual 26167V1 3.4.2—Installation Figure 3-14 shows the mounting template and fasteners to bulkhead mount the chassis. Rack mounting is not recommended. For proper airflow, the installation should allow a 3” air gap above and below the chassis. Figure 3-14—Mounting Template of MicroNet 6 Slot I/O Chassis 3.5—Expansion MicroNet Simplex 12-Slot I/O...
Page 49: Figure 3-15-Simplex Micronet 12 Slot I/O
Manual 26167V1 MicroNet TMR Figure 3-15—Simplex MicroNet 12 Slot I/O 3.5.2—Specification The MicroNet is designed around a modular six slot chassis (block). Each block consists of a premolded cage with a fan for cooling and a temperature switch for high temperature detection. The chassis are cooled by forced air, and either a module or a module blank must be installed in every slot to maintain correct air flow.
Page 50: Figure 3-16-Outline Drawing Of Micronet 12 Slot I/O
MicroNet TMR Manual 26167V1 NOTES:  Add ~2” (~5 cm) to the depth dimension to account for the cable saddles that are not shown on the outline drawing below.  The PE ground connection point is located underneath the left side of the chassis.
Page 51: Figure 3-17-Mounting Template Of Micronet 12 Slot I/O Chassis
Manual 26167V1 MicroNet TMR 3.5.3—Installation Figure 3-17 shows the mounting template and fasteners to bulkhead mount the chassis. Rack mounting is not recommended. For proper airflow, the installation should allow a 3” air gap above and below the chassis. Figure 3-17—Mounting Template of MicroNet 12 Slot I/O Chassis...
Page 52: Chapter 4. Power Supplies
4.1—TMR Main Power Supplies 4.1.1—Module Description The MicroNet TMR main control power supply chassis uses redundant power supplies. A motherboard located on the back of the power supply chassis allows the two power supplies to form a redundant power system providing six separately regulated 24 Vdc, 6 A outputs to the control.
Page 53: Figure 4-2-Tmr Main Chassis Ps Ribbon Cable Connections
Manual 26167V1 MicroNet TMR Input power connections are made to the main power supply through terminals on the front of the power supplies. A 50-pin ribbon cable (5416-977) is used for connecting the power supply chassis to the control chassis.
Page 54: Figure 4-4-Chassis To Chassis Power Cable (5417-293)
See Figure 4-4. Figure 4-4—Chassis to Chassis Power Cable (5417-293) The MicroNet TMR Main power supplies must have the input power removed before installing or removing. This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D or non-hazardous locations only.
Page 55: Tmr Main Power Supply Specifications
Manual 26167V1 MicroNet TMR Figure 4-5—TMR Power Supply Modules (24 Vdc/120 Vac/dc) 4.2—TMR Main Power Supply Specifications 4.2.1—Main PS TMR (24 Vdc Input) Operating range: 18 to 36 Vdc Nominal voltage rating: 20 to 32 Vdc, as on power supply label...
Page 56: Tmr Main Power Supply Installation
MicroNet TMR Manual 26167V1 4.2.3—Main PS TMR (220 Vac Input) Operating range: 180 to 264 Vac (47 Hz to 63 Hz) Nominal voltage rating: 200 to 240 Vac, as on power supply label Maximum current: 6.5 A Maximum power: 1150 VA...
Page 57 For a system with a single I/O chassis, size the input power source according to the rating of the MicroNet TMR main power supply to which the source is connected. Do not size the supply mains for the sum of the MicroNet TMR main power supply ratings when redundant supplies are used.
Page 58: Tmr Kernel Ps Module
4.4—TMR Kernel PS Module 4.4.1—Module Description The MicroNet TMR control contains three kernel power supply modules. Each kernel section (A, B, and C) will contain one kernel power supply module. The kernel power supply will be located in the first slot of each kernel section. This...
Page 59: Tmr Kernel Ps Module Specifications
Manual 26167V1 MicroNet TMR Figure 4-7—Kernel Power Supply Module 4.5—TMR Kernel PS Module Specifications Input Voltage: 24 Vdc ±10% Output Voltage: 5 Vdc ±5% Output Current: 10 A maximum Woodward...
Page 60: Tmr Kernel Ps Installation
MicroNet TMR Manual 26167V1 4.6—TMR Kernel PS Installation Figure 4-8—MicroNet Kernel Power Supplies NOTE: Add ~ 2” to the depth dimension to account for the cable saddles that are not shown on the outline drawing above. The Kernel Power Supply must be installed in the first module slot from the left for each sub-chassis (kernel).
Page 61: Tmr System Power-Up
If at any time during this procedure the defined or expected result is not achieved, begin system troubleshooting. 1. Verify that the entire MicroNet TMR control system has been installed. 2. Turn on the power for one power supply, and verify that the power supply’s green LED is the only power supply LED that is on.
Page 62 4.8.1.2—TMR Main Power Supply Checks The following is a troubleshooting guide for checking areas which may present difficulties. If these checks are made prior to contacting Woodward for technical assistance, system problems can be more quickly and accurately assessed. ...
Page 63: Micronet Plus 8/14 Chassis Power Supplies
Manual 26167V1 MicroNet TMR Possible Cause Result Corrective Action 5 V is not functioning The kernel will not Remove all modules from that kernel and function. remove the Kernel Power Supply. Re- install the Kernel Power Supply. If the LED does not turn off, replace the module.
Page 64: Figure 4-9-Power Supply Module
MicroNet TMR Manual 26167V1 The MicroNet Plus main power supplies must have the input power removed before installing or removing. This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D or non-hazardous locations only.
Page 65 Manual 26167V1 MicroNet TMR 4.9.2—Power Supply Module Specifications  All Temperature ratings specify the System Ambient Temperature as measured at the front of the MicroNet chassis.  The Power Supply operating temperature range is –10 to +65 °C with de-rated 5 Vdc output current above 55 °C. See Power Supply specifications.
Page 66 If not otherwise indicated on a cabinet system nameplate, either use the MicroNet power supply input ratings for sizing the system’s source or consult Woodward for determining the minimum source requirements. Table 4-3 provides fuse and wire size specifications for each power supply.
Page 67: Table 4-3—Micronet Plus Power Supply Requirements
Manual 26167V1 MicroNet TMR MAXIMUM MAXIMUM FUSE/ INPUT VOLTAGE C.B. RATING WIRE SIZE ** RANGE (Time Delay) (AWG/mm²) 18–36 Vdc 50 A 8 / 10 * 100–150 Vdc 10 A 14 / 2.5 88–132 Vac 47–63 Hz 20 A 12 / 4 180–264 Vac 47–63 Hz...
Page 68 Simplex Power Supply Checks The following is a troubleshooting guide for checking areas which may present difficulties. If these checks are made prior to contacting Woodward for technical assistance, system problems can be more quickly and accurately assessed. ...
Page 69: Micronet Simplex 6/12 Chassis Power Supplies
PA2 (power supply #2). If redundant power supplies are not needed, blanking plates (3799-301) must be installed in the slots not being used. For MicroNet TMR installation instructions, see Chapter 14 and Section 3.3 of this chapter. The 6/12 slot expansion chassis should not be used for new applications.
Page 70: Figure 4-10-Power Supply Modules
MicroNet TMR Manual 26167V1 Expansion Chassis PS Expansion Chassis PS (24 Vdc Input) (120 Vac/dc Input) Figure 4-10—Power Supply Modules Woodward...
Page 71: Micronet Simplex Power Supply Specifications
Manual 26167V1 MicroNet TMR 4.11—MicroNet Simplex Power Supply Specifications Main PS Expansion (24 Vdc Input) Operating range: 18 to 36 Vdc Nominal voltage rating: 20 to 32 Vdc, as on power supply label Maximum current: 29.5 A Maximum power: 531 W...
Page 72: Micronet Simplex Power Supply Installation
MicroNet TMR Manual 26167V1 4.12—MicroNet Simplex Power Supply Installation Figure 4-11—MicroNet Simplex Power Supply 4.12.1—Input Power Wiring MicroNet controls require a fixed wiring installation for ac applications. Ground leakage exceeds 3.5 mA AC. Maximum ground leakage for ac installations is 7.2 mA at 60 Hz.
Page 73: Table 4-4—Micronet Simplex Power Supply Requirements
If not otherwise indicated on a cabinet system nameplate, either use the MicroNet power supply input ratings for sizing the system’s source or consult Woodward for determining the minimum source requirements. Table 4-4 provides fuse and wire size specifications for each power supply.
Page 74: Micronet Simplex Power Supply Troubleshooting
MicroNet TMR Manual 26167V1 When a cabinet is not supplied with the system, input power connections are made through terminals on the front of each main power supply. These terminals accept wires from 0.5 to 10 mm² (20–8 AWG). For a good connection, the inserted wires should have the insulation stripped back 8–9 mm (0.33 in).
Page 75 4.13.2—Expansion Power Supply Checks The following is a troubleshooting guide for checking areas which may present difficulties. If these checks are made prior to contacting Woodward for technical assistance, system problems can be more quickly and accurately assessed. ...
Page 76: Cpus
MicroNet TMR Manual 26167V1 Chapter 5. CPUs 5.1—TMR5200 CPU Module 5.1.1—Module Description Figure 5-1—TMR5200 CPU Module The MicroNet TMR5200 CPU module contains a MPC5200 processor, 128 Mbyte DDR RAM, 64 MB of flash memory, a Real Time clock, and various communication peripherals.
Page 77: Figure 5-2-Cpu Module Block Diagram
Manual 26167V1 MicroNet TMR For CPU module installation and replacement instructions, see the instructions for installing the VME module in Chapter 14, and the instructions for replacement in Chapter 15. Live insertion and removal of this module is allowed in a MicroNet TMR or Plus chassis.
Page 78 Network Configuration. Ethernet ports (ENET1, ENET2) can be configured for the customer network as desired. The RTN ports (RTN1, RTN2) are reserved for communicating with Woodward Real Time Network devices such as expansion racks. See the on-site Network Administrator to define an appropriate I/P address configuration for ENET1 and ENET2.
Page 79 Manual 26167V1 MicroNet TMR Network Configuration Utility (AppManager) Woodward's AppManager software can be used to load Control software (GAP), monitor diagnostic faults, and configure Network settings. The AppManager utility can be downloaded from www.woodward.com/software. A PC connection must be made to Ethernet #1 (ENET1) using a RJ45 Ethernet cable.
Page 80 MicroNet TMR Manual 26167V1 5.1.4—Module Reset Front Panel Reset Switch. The CPU module has a pushbutton reset switch on the front panel to reset the module. If a GAP application was successfully running at the time of reset, the same application will be auto-started and re-initialized.
Page 81: Figure 5-3-Cpu Communications Port (Db9F)
Manual 26167V1 MicroNet TMR Up to two Remote RTN modules may be installed into each MicroNet Plus 8/14 expansion chassis (only one RTN for 6/12 slot expansion chassis). When initialized by the main chassis CPU, the Remote RTN modules will acquire either a SYSCON or STANDBY status.
Page 82: Figure 5-4-Cpu Service Port (Mini-Din6F)
MicroNet TMR Manual 26167V1 Shielded cable is required when connecting to the Service Port. Using shielded cable will help ensure the robustness of the serial communications. Pin 1 – RS-232 Receive Pin 2 – RS-232 Transmit Pin 3 – Signal Ground Pin 4 –...
Page 83: Cpu_040 Module
Manual 26167V1 MicroNet TMR *A table of Message ID values as displayed in AppManager: Description of ID ID Number Created by the Coder (Evaluate specific Application) 1-99 “sysinit” – Problem in system initialization 184,185,186 VerifyCpuMem -- Problem in verify CPU memory...
Page 84: Figure 5-6-Cpu Module
CPU_040 CPUs. Use the CPU_5200 CPUs for all new designs. Every MicroNet TMR control contains three CPU modules, one located in the second slot of each kernel, just to the right of the kernel power supply.
Page 85: Figure 5-7-Cpu Module Block Diagram
Baud rate is selectable from 300 baud to 38.4 Kbaud. Before this port can be used, Woodward kit P/N 8298-096 must be installed. To install this kit, the CPU must have screw posts.
Page 86: Figure 5-8-68040 Cpu Communications Port
MicroNet TMR Manual 26167V1 Figure 5-8—68040 CPU Communications Port 5.2.3—FTM Reference No FTM is used with this CPU. However, additional installation and application information can be found in Chapter 12. 5.2.4—Troubleshooting and Tuning The MicroNet Operating System runs both off-line and on-line diagnostics.
Page 87: Table 5-1—Off-Line Tests
This test enables the interrupt timer and checks that the interrupts are being generated. 7. Local Bus Timeout Test This test writes to a location on the Woodward I/O bus with no memory (module) installed, and checks that a bus error occurs. 8. VME Bus Timeout Test This test writes to a location on the VME bus with no module installed, and verifies that a bus error occurs.
Page 88: Table 5-2—Flash Codes
MicroNet TMR Manual 26167V1 If during diagnostics, a particular test fails, testing stops and a message identifying the cause of the failure will be displayed. Also, the FAILED LED on the CPU module will periodically repeat bursts of flashes; the number of flashes in each burst indicates the test that failed as shown in Table 5-2.
Page 89: Table 5-4—Test Failure Messages
Manual 26167V1 MicroNet TMR A failure of any one of the on-line tests results in the I/O lock being asserted and display of a message as shown in Table 5-4. The message will be displayed on the Service Panel at the time the error occurs, and it also will go into the Fault Mode Buffer so that it can be displayed in the Fault Mode.
Page 90: Table 5-6—Numbered System Errors
MicroNet TMR Manual 26167V1 NUMBER SYS. FILE MEANING OPER. CREATE Cannot create task with priority less than one. CREATE Stack size requested is smaller than the minimum size. NEWPID The priority is greater than the maximum allowed. NEWPID The rate group Proctab entry is not free.
Page 91: Table 5-7—System Alarms
Manual 26167V1 MicroNet TMR FLASHES IN BURST ERROR DETECTED The Applications do not match, CPU_C different. The Applications do not match, CPU_B different. The Applications do not match, CPU_A different. The Applications do not match, ALL different. The Ladder Logic Applications do not match. The EE (tunable) values do not match, CPU_A different. The EE (tunable) values do not match, CPU_B different. 5,10 The EE (tunable) values do not match, CPU_C different.. 5,11 The EE (tunable) values do not match, all CPUs different. 5,14 Pickup CPU failed, re‐sync process 5,15 Pickup CPU failed, Application does not match running CPUs 5,16 Pickup CPU failed, EE (tunable) values do not match 5,17 Pickup CPU failed, EE (tunable) values do not match 5,19 Pickup CPU failed ,Ladder Logic Applications do not match 5,20 Pickup CPU failed attempt to re‐sync with running CPUs 5,21 Pickup CPU failed attempt to re‐sync with running CPUs 5,22 Pickup CPU failed attempt to re‐sync with running CPUs 5,23 Pickup CPU failed attempt to re‐sync with running CPUs 5,24 Pickup CPU failed attempt to re‐sync with running CPUs 5,25 Pickup CPU failed attempt to re‐sync with running CPUs...
Page 92: Table 5-8—System Alarms
MicroNet TMR Manual 26167V1 CPU_040 Alarms The possible system alarms are listed in Table 5-8. The numbered system alarms are listed in Table 5-9. The ALARMS in Tables 5-8 and 5-9 do not automatically display; they are stored by the system and to see them, you must use the OPSYS_FAULTS Mode of the Service Panel.
Page 93: Chapter 6. Communication
Manual 26167V1 MicroNet TMR Chapter 6. Communication 6.1—Remote RTN Module 6.1.1—Module Description Figure 6-1—Remote RTN Module The MicroNet Remote Real Time Network (RTN) module is designed to be located in an expansion rack. The module’s primary function is to gather data from local I/O modules and communicate this data to the main rack CPUs while providing redundant failover control of the rack in which it is located.
Page 94: Figure 6-2-Remote Rtn Module Block Diagram
MicroNet TMR Manual 26167V1 MicroNet Real-Time Network Module (RTN) 64MB FLASH VMEbus RESET SWITCH MANUAL RESET ADDRESS ADDRESS VA(31:1) File System, On-Board CAB(15:0) MASTER RUN / RESET LED BUFFERS RUN / RESET XCVR Reserved Boot Sectors 64MByte 64MByte VMEBUS DDR SDRAM...
Page 95: Figure 6-3-Micronet Tmr5200 System (Copper, 3-Rack)
MicroNet Simplex racks (6 or 12 slot versions) are supported. If desired, fiber optic Ethernet switches can be used to locate each chassis in a different location. It is required to use Woodward approved Ethernet hardware for robust operation. Example 4-rack systems using copper and fiber Ethernet cables.
Page 96: Figure 6-4-Micronet Tmr5200 System (Fiber, 2 Locations)
MicroNet TMR Manual 26167V1 MicroNet TMR, Fiber Optic Expansion - MicroNet Plus Expansion racks with redundant RTN modules RS2-4TX/1FX-SM (100' max) Real Time Network DA/STAT FAULT DA/STAT Switch 4TX/1FX RTN-A Fiber-A (10' max) (2 Km) RTN-B Fiber-B (2 Km) RS2-4TX/1FX-SM...
Page 97 Manual 26167V1 MicroNet TMR It is recommended to verify proper switch settings before installing the module in the system and when troubleshooting RTN related issues. The Network Type setting on all CPU and Remote RTN modules in the system must match for proper system operation.
Page 98 MicroNet TMR Manual 26167V1 6.1.5—Module Reset Front Panel Reset Switch. The Remote RTN module incorporates a pushbutton reset switch on the front panel to reset the module. This module will NOT automatically re-initialize to a running state after reset. The main-chassis CPU application can re-init this module upon request.
Page 99 (14 slot or 8 slot versions) or MicroNet Simplex expansion racks (6 or 12 slot versions) are supported in up to 3 different remote locations using fiber optic Ethernet switches. It is required to use Woodward approved hardware for robust operation. Configuration Notes: - A combination of approved copper and fiber optic Ethernet switches are allowed.
Page 100: Figure 6-5-Rtn Service Port (Mini-Din6F)
MicroNet TMR Manual 26167V1 6.1.9—RS-232 Service Port An isolated RS-232 service port is located on the front of the Remote RTN module. This port is for VxWorks operating system use only and cannot be configured for application software use. The communication settings are fixed at 38.4 Kbaud, 8 data bits, no parity, 1 stop-bit, and no flow control.
Page 101: Main Transceiver (Xcvr) Module
Manual 26167V1 MicroNet TMR 6.2—Main Transceiver (XCVR) Module 6.2.1—Module Description The Main XCVR module is only used with CPU 68040 systems. It allows extension of the VME back plane to the expansion I/O Chassis. The Main XCVR module sends and receives control, data, and address information to and from its associated Remote Transceiver module (see next section of this chapter) in an I/O chassis through a copper transceiver cable.
Page 102: Figure 6-7-Main Xcvr Module
MicroNet TMR Manual 26167V1 6.2.2—Module Specification Parallel Interface: High-speed, differential line drivers operating at VME transmission rate Cable Interface: 100 pin metal shell Micro-D connector (2 per module) Figure 6-7—Main XCVR Module 6.2.3—Installation  The Main XCVR module can be installed in any slot in the Main Chassis.
Page 103: Remote Transceiver (Xcvr) Module
Manual 26167V1 MicroNet TMR 6.3—Remote Transceiver (XCVR) Module 6.3.1—Module Description The Remote XCVR module is only used with CPU 68040 systems. The Remote XCVR module receives and sends control, data, and address information via cable to and from its associated Main XCVR module. This module must be used in each Remote I/O Chassis that is connected to the Main Chassis via copper cables.
Page 104: Figure 6-9-Remote Xcvr Module Jumpers
MicroNet TMR Manual 26167V1 Table 6-1 shows the jumpers on the Remote XCVR module used to configure the chassis ID. Figure 6-9—Remote XCVR Module Jumpers JPR1 JPR2 JPR3 JPR4 CHASSIS 1 CHASSIS 2 CHASSIS 3 CHASSIS 4 CHASSIS 5 CHASSIS 6...
Page 105: Figure 6-10-Remote Xcvr Module
Manual 26167V1 MicroNet TMR Figure 6-10—Remote XCVR Module 6.3.2—Module Specification Parallel Interface: High-speed, differential line drivers operating at VME transmission rate Cable Interface: 100 pin metal shell Micro-D connector (2 per module) 6.3.3—Installation  The Remote XCVR module has no switches or LEDs.
Page 106: Transceiver Accessories
MicroNet TMR Manual 26167V1 6.3.4—Troubleshooting 1. If the Remote XCVR module is not functioning or not functioning properly, verify the cable connections. 2. If the module is still not functioning properly after verifying the cable connections, replace the cables connecting to module.
Page 107: Figure 6-13-Expansion I/O Chassis
Manual 26167V1 MicroNet TMR 6.4.2—Module Specification Parallel Interface: High-speed, differential line drivers operating at VME transmission rate Cable Interface: 100 pin metal shell Micro-D connector (2 per module) 6.4.3—Transceiver Accessories Installation (Outline) The Main and Remote Transceiver modules must be connected exactly as shown in the following diagrams (Figures 6-16 and 6-17).
Page 108: Ethernet Module
VME backplane. When inserted into a powered chassis, the module will interrupt VME bus backplane communications and cause other Woodward modules and expansion racks to shut down. On power-up, the Ethernet board runs a series of self-tests that check the board hardware.
Page 109: Figure 6-15-Ethernet Module
Manual 26167V1 MicroNet TMR Due to addressing conflicts with the Pentium CPU and TMR5200, this module can be used only with the Motorola 68040 CPU family. Figure 6-15—Ethernet Module LED Annunciations The following LEDs annunciate board failure as well as different functions related to Ethernet communications.
Page 110 The Ethernet module can be configured for an alternate VME address to support the use of two modules in a MicroNet system. For dual module operation, both the Woodward GAP and the module DIP switch must be configured properly. The DIP switch (S2) is located directly behind the RJ45 Ethernet connector.
Page 111 Manual 26167V1 MicroNet TMR RJ45 Ethernet Pinout Connector Signal Mnemonic RJ45 female Shielded RJ45 female receptacle Shield Chassis GND 6.5.4—FTM Reference Ethernet Interface FTM To ensure signal integrity and robust operation of Ethernet devices, an Ethernet Interface FTM (Field Termination Module) is required when interfacing Ethernet devices to the CPU.
Page 112: Sio Module
MicroNet TMR Manual 26167V1 6.6—SIO Module 6.6.1—Module Description Figure 6-16—SIO Module The SIO (Serial In/Out) Module interfaces four serial communication ports to the VME bus. Figure 6-17 is a block diagram of the SIO module. The module manages four serial ports. Port A(J1) and port B(J2) are RS-232 ports. Port C(J3) and Port D(J4) are for RS-232, RS-422, or RS-485 communication protocols.
Page 113: Figure 6-17-Sio Module Block Diagram
Manual 26167V1 MicroNet TMR Figure 6-17—SIO Module Block Diagram 6.6.2—Module Specification Ports 1 and 2: RS-232 @ 110–38.4 Kbaud Ports 3 and 4: RS-232, RS-422, and RS-485 (software selectable) @ 110–57.6 Kbaud Software Support: Modbus RTU Modbus ASCII Woodward-specific service interface...
Page 114: Figure 6-18-Rs-422 Terminator Locations
MicroNet TMR Manual 26167V1 6.6.3—Installation Termination For RS-422, termination should be located at the receiver when one or more transmitters are connected to a single receiver. When a single transmitter is connected to one or more receivers, termination should be at the receiver farthest from the transmitter.
Page 115: Figure 6-20-Termination And Cable Connection Examples
Manual 26167V1 MicroNet TMR Figure 6-20—Termination and Cable Connection Examples Grounding and Shielding The RS-422 and RS-485 specifications state that a ground wire is needed if there is no other ground path between units. The preferred method to do this is to include a separate wire in the cable that connects the circuit grounds together.
Page 116: Figure 6-21-Preferred Multipoint Wiring Using Shielded Twisted-Pair Cable With A Separate Signal Ground Wire
MicroNet TMR Manual 26167V1 Figure 6-21—Preferred Multipoint Wiring Using Shielded Twisted-Pair Cable with a Separate Signal Ground Wire The SG (signal ground) connection is not required if signal ground is unavailable. Figure 6-22—Alternate Multipoint Wiring Using Shielded Twisted-Pair Cable without a Separate Signal Ground Wire 6.6.4—Troubleshooting...
Page 117: Chapter 7. Discrete I/O Modules
7.1—Introduction There are seven types of discrete I/O modules currently available with the MicroNet system. These include the MicroNet TMR Discrete I/O Smart-Plus module (24 discrete inputs, 12 discrete outputs), 24/12 TMR Discrete Combo module (24 discrete inputs, 12 discrete outputs), MicroNet Discrete I/O Smart-...
Page 118: Micronet Tmr Discrete I/O Smart-Plus Module
Manual 26167V1 7.2—MicroNet TMR Discrete I/O Smart-Plus Module Each MicroNet TMR Discrete I/O Smart-Plus module contains circuitry for twenty-four (24) discrete inputs and twelve (12) TMR discrete outputs, and provides latent fault detection for each relay output. Each discrete input may be 24 Vdc.
Page 119: Figure 7-3-Micronet Tmr Discrete I/O Smart-Plus Module Block Diagram
Manual 26167V1 MicroNet TMR Figure 7-3—MicroNet TMR Discrete I/O Smart-Plus Module Block Diagram 7.2.2—Specifications Discrete Inputs Number of channels: Update time: 5 ms Input type: Optically isolated discrete input 24 V Input thresholds: <8 Vdc = “OFF”, at .7 mA >16 Vdc = “ON”, at 1.2 mA...
Page 120: Figure 7-4-Example Tmr System Configuration
Associated Components Figure 7-4—Example TMR System Configuration In a TMR system, each MicroNet TMR Discrete I/O Smart-Plus module is connected through two high density 62 conductor discrete cables to four FT Relay/Discrete Input modules. All of the I/O on MicroNet TMR Discrete I/O Smart-Plus module is accessible on the relay modules.
Page 121: Figure 7-5-Wiring Diagram For A Ft Relay/Discrete Input Module
Manual 26167V1 MicroNet TMR 7.2.4.1—Field Wiring Figure 7-5—Wiring Diagram for a FT Relay/Discrete Input Module Woodward...
Page 122: Figure 7-6-Optional Internal 24 Vdc Contact Wetting Configuration
Manual 26167V1 7.2.4.2—Discrete Inputs The MicroNet TMR Discrete I/O Smart-Plus module accepts 24 discrete inputs. Each of the control’s four FT Relay/Discrete Input modules accepts six contact inputs. Contact wetting voltage can be supplied by the control or from an external source.
Page 123: Figure 7-7-Tmr Discrete Output
Manual 26167V1 MicroNet TMR 7.2.4.3—Configuration Notes Refer to Figure 7-6 for contact input wiring.  All contact inputs accept dry contacts.  The internal 24 Vdc power source or an external 18-36 Vdc (UL and LVD) power source can be used for circuit wetting.
Page 124 MicroNet TMR Manual 26167V1 Readback circuitry allows the state of each relay contact to be detected. Any failures are annunciated, and further testing is disabled without affecting the state of the relay output contact or control operation. Latent fault detection is not appropriate for all applications or circuits. The control’s latent fault detection logic can only work with circuits using voltages...
Page 125: Figure 7-8-Latent Fault Detection Verification Graph-18-32 Vdc Circuitry
Manual 26167V1 MicroNet TMR Using the graph below, the intersection point between the 200 ohm load resistance line and the 110 Vac line was found. From this intersection point it was determined that the voltage developed across the load due to leakage current when the relay is open, is approximately 7.5 Vac.
Page 126: Figure 7-9-Jumper And Relay Location Diagram
MicroNet TMR Manual 26167V1 Each relay output has two banks of jumpers. One jumper-bank (a set of nine jumpers) is used to match the latent fault detection circuit with the circuit voltage to which it is being interfaced. The second jumper bank (a set of four jumpers) is used to select which set of relay contacts (N.O.
Page 127: Figure 7-11-Example Relay Output Wiring Diagram
Manual 26167V1 MicroNet TMR Configuration Notes  Refer to Figure 7-11 for relay output wiring.  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required in cases where the interfaced circuit demands relay contacts with a higher power rating.
Page 128: Table 7-1—Led Indications Of Failure
Manual 26167V1 7.2.4.6—Fault Detection (Module Hardware) Each MicroNet TMR Discrete I/O Smart-Plus module has a red Fault LED that is turned on when the system is reset. During initialization of a MicroNet TMR Discrete I/O Smart-Plus module, which occurs after every CPU reset, the CPU turns the Fault LED on.
Page 129 Check the software configuration to ensure that the input is configured properly. After verifying all of the above, remove the MicroNet TMR Discrete I/O Smart- Plus module and exchange the J1 and J2 cables. See instructions for replacing the module in Chapter 15, Installation and Service. If the problem moves to a different channel, replace the cable.
Page 130: 24/12 Tmr Discrete I/O Module
MicroNet TMR Manual 26167V1 7.3—24/12 TMR Discrete I/O Module Each 24/12 TMR Discrete I/O module (TMR High Density Discrete module) contains circuitry for twenty-four (24) discrete inputs and twelve (12) TMR discrete outputs, and provides latent fault detection for each relay output. Each discrete input may be 24 V, or 125 Vdc.
Page 131: Figure 7-13-24/12 Tmr Discrete I/O Module Block Diagram
Manual 26167V1 MicroNet TMR Figure 7-13—24/12 TMR Discrete I/O Module Block Diagram 7.3.2—Specifications Discrete Inputs Number of channels: Update time: 5 ms Input type: Optically isolated discrete input 24 V Input thresholds: <8 Vdc = “OFF”, at .7 mA >16 Vdc = “ON”, at 1.2 mA 125 V Input thresholds: <...
Page 132: Figure 7-14-Example Tmr System Configuration
MicroNet TMR Manual 26167V1 Contact ratings: 5.0 A @ 240 Vac, 50/60 Hz (resistive) (meets UL ratings only) 3.0 A @ 240 Vac, 50/60 Hz (inductive)·(meets UL ratings only) 10.0 A @ 120 Vac, 50/60 Hz (resistive) (meets UL ratings only) 6.0 A @ 120 Vac, 50/60 Hz (inductive) (meets UL ratings only)
Page 133: Figure 7-15-Wiring Diagram For A Ft Relay/Discrete Input Module
Manual 26167V1 MicroNet TMR 7.3.4.1—Field Wiring Figure 7-15—Wiring Diagram for a FT Relay/Discrete Input Module Woodward...
Page 134: Figure 7-16-Optional Internal 24 Vdc Contact Wetting Configuration
MicroNet TMR Manual 26167V1 7.3.4.2—Discrete Inputs The 24/12 TMR Discrete I/O Discrete module accepts 24 discrete inputs. Each of the control’s four FT Relay/Discrete Input modules accepts six contact inputs. Contact wetting voltage can be supplied by the control or from an external source.
Page 135: Figure 7-17-Optional External 24/125 Vdc Contact Wetting Configuration
Manual 26167V1 MicroNet TMR Figure 7-17—Optional External 24/125 Vdc Contact Wetting Configuration 7.3.4.3—Configuration Notes If there is 125 Vdc on the FT Relay/Discrete Input module terminal blocks, there will be 125 Vdc on the relay module sub D connectors and on the cable when it is connected to the relay module. For this...
Page 136: Figure 7-18-Tmr Discrete Output
MicroNet TMR Manual 26167V1 Figure 7-18—TMR Discrete Output 7.3.4.4—Latent Fault Detection It is important to detect latent faults in a fault tolerant system, because although a single fault may go undetected, if another fault occurs it could cause a shutdown.
Page 137 Manual 26167V1 MicroNet TMR Verifying That Latent Fault Detection Can Be Used With a Relay Output Verify that the circuit the relay output is used with has a voltage level of 18- 32 Vdc, 100–150 Vdc, or 88-132 Vac. Use graph which corresponds to the circuit’s voltage level to determine if the voltage developed across the load (due to the leakage current) is lower than the load’s drop-out voltage level.
Page 138: Figure 7-19-Latent Fault Detection Verification Graph-18-32 Vdc Circuitry
MicroNet TMR Manual 26167V1 Figure 7-19—Latent Fault Detection Verification Graph–18-32 Vdc Circuitry Figure 7-20—Latent Fault Detection Verification Graph–18-132 Vac Circuitry Woodward...
Page 139: Figure 7-21-Latent Fault Detection Verification Graph-100-150 Vdc Circuitry
Manual 26167V1 MicroNet TMR Figure 7-21—Latent Fault Detection Verification Graph–100–150 Vdc Circuitry 7.3.4.5—Relay Jumper Configurations Relay coil power should be supplied by the control, because this supply is fault tolerant. Jumper banks (four jumpers in one package) are provided on each relay module to allow field selection of internal or external relay coil power.
Page 140: Figure 7-22-Jumper And Relay Location Diagram
MicroNet TMR Manual 26167V1 Figure 7-22—Jumper and Relay Location Diagram After all jumper-banks have been correctly positioned, mark the placement of each jumper-bank on the FT Relay/Discrete Input module cover labels. See the figure below. Figure 7-23—FT Relay/Discrete Input Module Labels Configuration Notes HIGH VOLTAGE—If there is 125 Vdc on the FT Relay/Discrete Input...
Page 141: Figure 7-24-Example Relay Output Wiring Diagram
Manual 26167V1 MicroNet TMR  Refer to Figure 7-24 for relay output wiring.  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required in cases where the interfaced circuit demands relay contacts with a higher power rating.
Page 142: Table 7-2—Led Indications Of Failure
MicroNet TMR Manual 26167V1 7.3.4.6—Fault Detection (Module Hardware) Each 24/12 TMR Discrete I/O module has a red Fault LED that is turned on when the system is reset. During initialization of a 24/12 TMR Discrete I/O module, which occurs after every CPU reset, the CPU turns the Fault LED on. The CPU then tests each 24/12 TMR Discrete I/O module using diagnostic routines built into the software.
Page 143 Manual 26167V1 MicroNet TMR  If the other channels on the 24/12 TMR Discrete I/O module are also not working, check the fuse on the 24/12 TMR Discrete I/O module. See instructions for module replacement in Chapter 15, Installation and Service.
Page 144: Micronet Discrete I/O Smart-Plus Module (Hddio)
MicroNet TMR Manual 26167V1 7.4—MicroNet Discrete I/O Smart-Plus Module (HDDIO) 7.4.1—Module Description The HDDIO module is a MicroNet Plus module that will allow the customer to access information about the module during operation via AppManager. A 48/24 Discrete Combo module contains circuitry for forty-eight optically isolated discrete inputs and twenty-four discrete outputs.
Page 145 Manual 26167V1 MicroNet TMR 7.4.2—Module Specification Discrete Inputs Number of channels: Update time: 5 ms Input type: Optically isolated discrete input (galvanically isolated) 48/24 Discrete FTM Input thresholds: Input voltage: 8 Vdc at 1.5 mA = “OFF” > 16 Vdc at 3 mA = “ON”...
Page 146: Figure 7-26-Configuration 1, One 48/24 Discrete Ftm With Relay Module(S)
MicroNet TMR Manual 26167V1 Power Supply 48/24 Power Supply HDDIO High Density Analog/Discrete Cable High Density Analog/Discrete Cable Low Density Discrete Cable 32Ch Relay Module Low Density Discrete Cable 24Vdc 48/24 Discrete FTM 16Ch Relay Module 16Ch Relay Module Figure 7-26—Configuration 1, One 48/24 Discrete FTM with Relay Module(s)
Page 147: Table 7-3—Discrete Outputs/Relay Module Configuration
Manual 26167V1 MicroNet TMR Configuration Notes:  Refer to Chapter 12 for Discrete Input wiring.  Each MicroNet Discrete I/O Smart-Plus module can only accept one input voltage range, 24 Vdc (LVD and UL).  All contact inputs accept dry contacts.
Page 148: Figure 7-28-Relay Output Interface Wiring To A 16Ch Relay Module
MicroNet TMR Manual 26167V1 Figure 7-28—Relay Output Interface Wiring to a 16Ch Relay Module Figure 7-29—Relay Output Interface Wiring to a 32Ch Relay Module Configuration Notes  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used.
Page 149: Figure 7-30-Configuration 2, Two 24/12 Discrete Ftms
Manual 26167V1 MicroNet TMR Figure 7-30—Configuration 2, Two 24/12 Discrete FTMs Both the 48 discrete inputs and 24 discrete outputs are wired to the 24/12 Discrete FTM. An external 24 Vdc source connection to the FTM is required for discrete input contact sensing and relay coil energizing. For wiring information on the 24/12 Discrete FTM, see Chapter 12.
Page 150: Figure 7-31-Discrete Input Interface Wiring To A 24/12 Discrete Ftm
MicroNet TMR Manual 26167V1 Internal External Channel 1 Field Contacts Channel 2 48/24 Discrete Combo Module Jumper (remove for Optional external External excitation) Excitation +24VDC 24Ret TB10 Cable Ground to Sheild DIN rail Figure 7-31—Discrete Input Interface Wiring to a 24/12 Discrete FTM Configuration Notes: ...
Page 151: Figure 7-32-Relay Output Interface Wiring To A 24/12 Discrete Ftm
Manual 26167V1 MicroNet TMR Figure 7-32—Relay Output Interface Wiring to a 24/12 Discrete FTM Configuration Notes  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required when the interfaced circuit demands relay contacts with a higher power rating.
Page 152: Figure 7-33-Micronet Discrete I/O Smart-Plus Module Block Diagram
MicroNet TMR Manual 26167V1 Number of Fault LED Flashes Failure Watchdog Failure No Application Flash Memory Failure Exception Failure FPGA Failure Non-Volatile Memory Error Kernel Watchdog Error MFT Failure Software Slip Ram Memory Failure Software Failure Table 7-4—LED Indications of Failure...
Page 153 Manual 26167V1 MicroNet TMR Discrete Inputs If a discrete input is not functioning properly, verify the following: Measure the input voltage on the terminal block. It should be in the range of 16–32 Vdc for the low voltage FTM or 100–150 Vdc for the high voltage FTM.
Page 154: 48/24 Discrete Combo Module
MicroNet TMR Manual 26167V1 7.5—48/24 Discrete Combo Module 7.5.1—Module Description A 48/24 Discrete Combo module contains circuitry for forty-eight discrete inputs and twenty-four discrete outputs. These modules have no potentiometers and require no calibration. A module may be replaced with another module of the same part number without any adjustment.
Page 155 Manual 26167V1 MicroNet TMR 7.5.2—Module Specification Discrete Inputs Number of channels: Update time: 5 ms Input type: Optically isolated discrete input (galvanically isolated) 48/24 Discrete FTM Input thresholds: Low voltage: 8 Vdc at 1.5 mA = “OFF” > 16 Vdc at 3 mA = “ON”...
Page 156: Figure 7-35-Configuration 1, One 48/24 Discrete Ftm With Relay Module(S)
MicroNet TMR Manual 26167V1 Power Supply Power Supply 48/24 High Density Analog/Discrete Cable High Density Analog/Discrete Cable Low Density Discrete Cable 32Ch Relay Module Low Density Discrete Cable 24VDC 48/24 Discrete FTM or 125VDC 48/24 Discrete FTM 16Ch Relay Module 16Ch Relay Module Figure 7-35—Configuration 1, One 48/24 Discrete FTM with Relay Module(s)
Page 157: Figure 7-36-Discrete Input Interface Wiring To A 24 Vdc 48/24 Discrete Ftm
Manual 26167V1 MicroNet TMR Figure 7-36—Discrete Input Interface Wiring to a 24 Vdc 48/24 Discrete FTM Figure 7-37—Discrete Input Interface Wiring to a 125 Vdc 48/24 Discrete FTM HIGH VOLTAGE—If the high voltage FTM is being used, and there is 125 Vdc on the FTM terminal blocks, there will be 125 Vdc on the FTM sub D connectors and on the cable when it is connected to the FTM.
Page 158: Figure 7-38-Relay Output Interface Wiring To A 16 Ch Relay Module
MicroNet TMR Manual 26167V1 Discrete Outputs For the 48/24 Discrete Combo FTM configuration, there are three types of relay output boxes that can be used. These consist of the 16 Ch Relay (Phoenix) Module, 16 Ch Relay Module, and the 32 Ch Relay Module (see Chapter 12 for a description of the available modules).
Page 159: Figure 7-39-Relay Output Interface Wiring To A 32 Ch Relay Module
Manual 26167V1 MicroNet TMR Figure 7-39—Relay Output Interface Wiring to a 32 Ch Relay Module Configuration Notes  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required when the interfaced circuit demands relay contacts with a higher power rating.
Page 160: Figure 7-41-Discrete Input Interface Wiring To A 24/12 Discrete Ftm
MicroNet TMR Manual 26167V1 Both the 48 discrete inputs and 24 discrete outputs are wired to the 24/12 Discrete FTM. An external 24 Vdc source connection to the FTM is required for discrete input contact sensing and relay coil energizing. For wiring information on the 24/12 Discrete FTM, see Chapter 12.
Page 161: Figure 7-42-Relay Output Interface Wiring To A 24/12 Discrete Ftm
Manual 26167V1 MicroNet TMR Discrete Outputs The discrete outputs on the 48/24 Discrete I/O module are non-isolated; the isolation takes place in the 24/12 Discrete FTM. See Chapter 12 for field wiring of discrete output relays. Figure 7-42 illustrates an example of a discrete output wiring configuration.
Page 162: Figure 7-43-48/24 Discrete Combo Module Block Diagram
MicroNet TMR Manual 26167V1 Number of LED Flashes Failure Micro-controller internal RAM test failure External RAM high and low byte test failure External RAM low byte failure External RAM high byte failure EEPROM failure Software not running System monitor fault MFT pulses missing Table 7-6—LED Indications of Failure...
Page 163 Manual 26167V1 MicroNet TMR Discrete Inputs If a discrete input is not functioning properly, verify the following: Measure the input voltage on the terminal block. It should be in the range of 16–32 Vdc for the low voltage FTM or 100–150 Vdc for the high voltage FTM.
Page 164: 48 Channel Discrete Input Module
MicroNet TMR Manual 26167V1 7.6—48 Channel Discrete Input Module 7.6.1—Module Description Each 48 Channel Discrete Input (48 Ch DI) Module is connected through two low density discrete cables to two separate FTMs. There are two types of FTMs available for use with the 48 Ch DI Module; the 24 Vdc Discrete Input/Output FTM and the Discrete Input (With LEDs) FTM (see Chapter 12 for additional information on this FTM module).
Page 165: Figure 7-45-48 Ch Di Module With Two Ftms
Manual 26167V1 MicroNet TMR 7.6.2—Module Specification Number of Channels: Input Type: Optically isolated discrete input Input Thresholds: < 8 Vdc = "OFF" > 16 Vdc = "ON" Input Current: 3 mA @ 24 Vdc Contact Power: Module provides isolated 24 Vdc, 0.3 A 7.6.3—Installation...
Page 166: Figure 7-46-Discrete Input Interface Wiring With Internal Power Source To A 24
MicroNet TMR Manual 26167V1 Each 48 Ch DI Module accepts 48 contact inputs. Contact wetting voltage may be supplied by the 48 Ch DI Module internal power supply. The supply can only supply 300 mA and therefore should not be used with the Discrete Input (with LEDs) FTM.
Page 167: Figure 7-48-Discrete Input Module Block Diagram
Manual 26167V1 MicroNet TMR 7.6.4—FTM Reference See Chapter 12 for detailed wiring of FTMs. See Appendix A for part number Cross Reference for modules, FTMs, and cables. 7.6.5—Troubleshooting Fault Detection (Module Hardware) Each 48 Ch DI module has a red Fault LED that is turned on when the system is reset.
Page 168: 32 Channel Discrete Output Module
7.7.2—Module Specification Number of channels: Update time: 5 ms Output Type: Open drain drivers, intended for use with Woodward relay interface modules. Fault Detection Readback: Output channel status, relay status is not available System Faults: Outputs are turned off if communications with the CPU is lost.
Page 169: Figure 7-49-Discrete Output Module
This module receives digital data from the CPU and generates 32 non-isolated relay driver signals. All discrete output modules in the system interface to one or more Woodward Relay Modules, each with 16 or 32 relays. The contacts of these relays then connect to the field wiring.
Page 170: Figure 7-50-32 Ch Do Module With Relay Modules
MicroNet TMR Manual 26167V1 Power Supply Power Supply Low Density Cable Low Density Cable 32Ch Relay Module 16Ch Relay Module 16Ch Relay Module Figure 7-50—32 Ch DO Module with Relay Modules See Chapter 12 for field wiring of discrete output relays.
Page 171: Figure 7-52-Relay Output Interface Wiring To A 32 Ch Relay Module
Manual 26167V1 MicroNet TMR Figure 7-52—Relay Output Interface Wiring to a 32 Ch Relay Module Configuration Notes  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required when the interfaced circuit demands relay contacts with a higher power rating.
Page 172: Figure 7-53-Discrete Output Module (32 Channel) Block Diagram
MicroNet TMR Manual 26167V1 RELAY POWER ENABLE WOODWARD RELAY MODULE CHANNELS 1-32 LATCHES DRIVERS INTER- FACE BUFFERS FAULT Figure 7-53—Discrete Output Module (32 Channel) Block Diagram If a discrete output is not functioning properly, verify the following: Check the wiring for a loose connection on the terminal blocks, or disconnected or misconnected cables.
Page 173: 64 Channel Discrete Output Module
Manual 26167V1 MicroNet TMR 7.8—64 Channel Discrete Output Module 7.8.1—Module Description Figure 7-54—Discrete Output Module The MicroNet control can provide discrete outputs to the prime mover from field wiring. Each of this type Discrete Output (DO) module can individually control 64 outputs according to commands from the CPU module.
Page 174 This module receives digital data from the CPU and generates 64 non-isolated relay driver signals. All discrete output modules in the system interface to one or more Woodward Relay Modules, each with 16 or 32 relays. The contacts of these relays then connect to the field wiring.
Page 175: Figure 7-55-64 Ch Do Module With Relay Modules
Manual 26167V1 MicroNet TMR Power Supply Power Supply Low Density Cable Low Density Cable Low Density Cable 32Ch Relay Module 16Ch Relay Module 16Ch Relay Module (Channels 33-64) (Channels 33-48) (Channels 49-64) Low Density Cable 32Ch Relay Module 16Ch Relay Module...
Page 176: Figure 7-57-Relay Output Interface Wiring To A 32 Ch Relay Module
MicroNet TMR Manual 26167V1 Figure 7-57—Relay Output Interface Wiring to a 32 Ch Relay Module Configuration Notes  Verify that each set of relay contacts meets the power requirements of the circuit with which it is being used. Interposing relays are required when the interfaced circuit demands relay contacts with a higher power rating.
Page 177: Chapter 8. Analog I/O Modules
The single type modules consist of a single type of I/O, such as all 4–20 mA inputs. 8.2—Combination I/O Modules There are five Analog Combination I/O modules available from Woodward. These are described in sections 8.3 through 8.8. 8.3—TMR 24/8 Analog Module 8.3.1—Module Description...
Page 178: Figure 8-1-24/8 Analog Module
MicroNet TMR Manual 26167V1 Figure 8-1—24/8 Analog Module 8.3.2—Module Specification Analog Input Ratings Number of channels: Update time: 5 ms Input range: 0–25 mA; software and hardware selectable The maximum voltage input range may vary between 4.975 and 5.025 Volts from module to module.
Page 179: Figure 8-2-Example Tmr System Configuration
Manual 26167V1 MicroNet TMR 4–20 mA Output Ratings Number of channels: Update time: 5 ms Output Driver: Pulse Width Modulated (PWM) PWM frequency: 6.14 kHz Filter: 3 poles at 500 μs Current output: 4–20 mA Current output range: 0–25 mA...
Page 180: Figure 8-3-Analog Input Wiring For A 24/8 Analog Ftm
MicroNet TMR Manual 26167V1 Analog Inputs For a 4–20 mA input signal, the 24/8 Analog Module uses a 200 ohm resistor across the input located on the 24/8 Analog Module. Each analog input channel may power its own 4–20 mA transducer. See Figure 8-3 for analog input connection.
Page 181: Figure 8-4-Analog Output Wiring For A 24/8 Analog Ftm
Manual 26167V1 MicroNet TMR Analog Outputs There are 8 analog output channels of 4–20 mA with a full scale range of 0–25 mA. All Analog Outputs can drive a maximum load of 600 ohms (load + wire resistance). See Figure 8-4 for analog output connection. Each output monitors the output source current for fault detection.
Page 182 MicroNet TMR Manual 26167V1 Fault Detection (I/O) In addition to detecting the High Density Analog I/O module hardware faults, the application software may detect I/O faults. Analog Input Faults: The application software may be set with a high and low latch setpoint to detect input faults.
Page 183 Manual 26167V1 MicroNet TMR Check the wiring. If the inputs are reading 0 or the engineering units that correspond to 0 mA, look for a loose connection on the terminal blocks, disconnected or misconnected cables, a missing jumper on the terminal block if the input is a loop powered current input, or a blown fuse on the 24 Vdc on the FTM.
Page 184 MicroNet TMR Manual 26167V1 Check the wiring for a loose connection on the terminal blocks or disconnected or misconnected cables. If none of the outputs on a given 24/8 Analog I/O module are functioning, check the 24/8 Analog I/O module fuse.
Page 185: Tmr Analog Combo Module
Manual 26167V1 MicroNet TMR 8.4—TMR Analog Combo Module 8.4.1—Module Description Each High Density Analog Combo module contains circuitry for four speed sensor inputs, eight analog inputs, four analog outputs, and two proportional actuator driver outputs. Each speed sensor input may be from a magnetic pick- up or from a proximity probe, each analog input must be 4–20 mA, and each...
Page 186 MicroNet TMR Manual 26167V1 8.4.2—Module Specifications Digital Speed Sensor Inputs Number of channels: Update time: 5 ms MPU Input Ratings Input frequency: 100 - 25000 Hz Input amplitude: 1-25 Vrms Input impedance: 2000 Ohms Isolation voltage: 500 Vrms Resolution: 12 bits minimum over chosen frequency range Accuracy: 0.03% full scale, minimum...
Page 187: Figure 8-6-Example Fault Tolerant System Configuration
Manual 26167V1 MicroNet TMR Readback accuracy: 0.2%, over 25 mA full scale Readback temp drift: 400 ppm/C, maximum Actuator Driver Output Ratings Number of channels: Update time: 5 millisecond Driver: PWM (proportional only), single or dual coil PWM frequency: 6.14 kHz...
Page 188 I/O response times in GAP to ignore the deviations or provide the cabling for the MicroNet TMR with intervening isolators. Speed Sensor Inputs The MPU and proximity probe inputs are read and the speed is provided to the application program.
Page 189: Figure 8-7-Mpu/Proximity Interface Wiring To The Tmr Analog Combo Ftm
Manual 26167V1 MicroNet TMR Figure 8-7—MPU/Proximity Interface Wiring to the TMR Analog Combo FTM Woodward...
Page 190: Figure 8-8-Current Input Wiring For An Analog Combo Module Ftm
MicroNet TMR Manual 26167V1 Analog Inputs The TMR analog inputs must be current type due to the TMR FTM. See Appendix A for specific part numbers. All modules use the same cable and FTMs. All current inputs may be used with two-wire ungrounded (loop powered) transducers or isolated (self-powered) transducers.
Page 191 Manual 26167V1 MicroNet TMR Only self-powered voltage transducers should be used on voltage input channels. The full scale range must not exceed 5 volts. Refer to Figure 8-9 for 0–5 Vdc voltage transducer input wiring. CABLE MicroNet Module .01uF Ch. 1...
Page 192 (25 Hz) signal consisting of a 5 millisecond pulse modulated onto the DC actuator-drive current to reduce sticking due to friction in linear type actuators. Woodward TM-type actuators typically require dither. Dither amplitude is variable through the application software. See Figure 8-10 for an example of actuator wiring.
Page 193: Figure 8-10-Analog Output And Actuator Wiring For An Analog Combo Ftm
Manual 26167V1 MicroNet TMR Figure 8-10—Analog Output and Actuator Wiring for an Analog Combo FTM Woodward...
Page 194 MicroNet TMR Manual 26167V1 8.4.5—Troubleshooting Fault Detection (Module Hardware) Each Analog Combo module has a red Fault LED that is turned on when the system is reset. During initialization of a module, which occurs after every CPU reset, the CPU turns the Fault LED on. The CPU then tests the module using diagnostic routines built into the software.
Page 195 Manual 26167V1 MicroNet TMR Speed Sensor Inputs MPUs. If a speed sensor input is not functioning properly, verify the following:  Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14, Installation and Replacement Procedures.
Page 196 MicroNet TMR Manual 26167V1 Proximity Probes. If a speed sensor input is not functioning properly, verify the following:  Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14, Installation and Replacement Procedures.
Page 197 Manual 26167V1 MicroNet TMR If one or two of the MPU and Analog I/O modules are reading the correct number, but the other module(s) is (are) incorrect, check the application software configuration of the modules with the non-working channels, and check to ensure that the cables are connected properly.
Page 198 MicroNet TMR Manual 26167V1 Check the wiring. If the inputs are reading 0 or the engineering units that correspond to 0 mA, look for a loose connection on the terminal blocks, disconnected or misconnected cables, a missing jumper on the terminal block if the input is a loop powered current input, or a blown fuse on the 24 Vdc on the FTM.
Page 199 Manual 26167V1 MicroNet TMR The following actions may shut down the prime mover. Disconnect the field wiring and connect a resistor across the output. If the output current is 0 mA, go to step 1. If the output current is correct, but some of the outputs have a fault, go to step 2.
Page 200 MicroNet TMR Manual 26167V1 The following actions may shut down the prime mover. Disconnect the field wiring and connect a resistor across the output; if the output current is 0 mA, go to step 1. If the output current is correct, but some of the outputs have a fault, go to step 2.
Page 201: Tmr Analog Combo Module - 3 Mpu, 1 Prox
Manual 26167V1 MicroNet TMR Figure 8-11—TMR MPU and Analog I/O Module FTM Fuse Locations Figure 8-12—MPU and Analog I/O Module FTM Fuse Locations 8.5—TMR Analog Combo Module – 3 MPU, 1 Prox 8.5.1—Module Description Each 3 MPU, 1 Prox High Density Analog Combo module contains circuitry for...
Page 202: Figure 8-13-Analog Combo Module
MicroNet TMR Manual 26167V1 This module includes no potentiometers and requires no calibration. An Analog Combo module may be replaced with another module of the same part number without any adjustment. Figure 8-13—Analog Combo Module 8.5.2—Module Specifications Digital Speed Sensor Inputs...
Page 203 Manual 26167V1 MicroNet TMR Analog Input Ratings Number of channels: Update time: 5 millisecond Input range: 0–25 mA The maximum input voltage range may vary between 4.975 and 5.025 Volts from module to module. Isolation: 0 VRMS, -60 dB CMRR, 200 Vdc common mode rejection voltage;...
Page 204: Figure 8-14-Example Fault Tolerant System Configuration
MicroNet TMR Manual 26167V1 8.5.3—Installation The modules slide into card guides in the control's chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel. Also at the top and bottom of the module are two handles which, when toggled (pushed outward), move the modules out just far enough for the boards to disengage the motherboard connectors.
Page 205 Manual 26167V1 MicroNet TMR A proximity probe may be used to sense very low speeds. With a proximity probe, speed can be sensed down to 0.5 Hz. When interfacing to open collector type proximity probes, a pull-up resistor is required between the supplied proximity probe voltage and the proximity probe input to the FTM.
Page 206: Figure 8-15-Mpu Interface Wiring To The Tmr Analog Combo Ftm
MicroNet TMR Manual 26167V1 Figure 8-15—MPU Interface Wiring to the TMR Analog Combo FTM (Speed 1, 2, & 3) Figure 8-16—Proximity Interface Wiring to the TMR Analog Combo FTM (Speed 4) Woodward...
Page 207: Figure 8-17-Current Input Wiring For An Analog Combo Module Ftm
Manual 26167V1 MicroNet TMR Analog Inputs The TMR analog inputs must be current type due to the TMR FTM. See Appendix A for specific part numbers. All modules use the same cable and FTMs. All current inputs may be used with two-wire ungrounded (loop powered) transducers or isolated (self-powered) transducers.
Page 208: Figure 8-9-Voltage Input Wiring For An Analog Combo Module Ftm (Simplex)
MicroNet TMR Manual 26167V1 Only self-powered voltage transducers should be used on voltage input channels. The full scale range must not exceed 5 volts. Refer to Figure 8-18 for 0–5 Vdc voltage transducer input wiring. CABLE MicroNet Module .01uF Ch. 1...
Page 209 (25 Hz) signal consisting of a 5 millisecond pulse modulated onto the DC actuator-drive current to reduce sticking due to friction in linear type actuators. Woodward TM-type actuators typically require dither. Dither amplitude is variable through the application software. See Figure 8-19 for an example of actuator wiring.
Page 210: Figure 8-19-Analog Output And Actuator Wiring For An Analog Combo Ftm
MicroNet TMR Manual 26167V1 Figure 8-19—Analog Output and Actuator Wiring for an Analog Combo FTM Woodward...
Page 211 Manual 26167V1 MicroNet TMR 8.5.5—Troubleshooting Fault Detection (Module Hardware) Each Analog Combo module has a red Fault LED that is turned on when the system is reset. During initialization of a module, which occurs after every CPU reset, the CPU turns the Fault LED on. The CPU then tests the module using diagnostic routines built into the software.
Page 212 MicroNet TMR Manual 26167V1 Speed Sensor Inputs MPUs. If a speed sensor input is not functioning properly, verify the following:  Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14, Installation and Replacement Procedures.
Page 213 Manual 26167V1 MicroNet TMR Proximity Probes. If a speed sensor input is not functioning properly, verify the following:  Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14, Installation and Replacement Procedures.
Page 214 MicroNet TMR Manual 26167V1 If one or two of the MPU and Analog I/O modules are reading the correct number, but the other module(s) is (are) incorrect, check the application software configuration of the modules with the non-working channels, and check to ensure that the cables are connected properly.
Page 215 Manual 26167V1 MicroNet TMR Check the wiring. If the inputs are reading 0 or the engineering units that correspond to 0 mA, look for a loose connection on the terminal blocks, disconnected or misconnected cables, a missing jumper on the terminal block if the input is a loop powered current input, or a blown fuse on the 24 Vdc on the FTM.
Page 216 MicroNet TMR Manual 26167V1 The following actions may shut down the prime mover. Disconnect the field wiring and connect a resistor across the output. If the output current is 0 mA, go to step 1. If the output current is correct, but some of the outputs have a fault, go to step 2.
Page 217 Manual 26167V1 MicroNet TMR The following actions may shut down the prime mover. Disconnect the field wiring and connect a resistor across the output; if the output current is 0 mA, go to step 1. If the output current is correct, but some of the outputs have a fault, go to step 2.
Page 218: 24/8 Analog Module
MicroNet TMR Manual 26167V1 Figure 8-20—TMR MPU and Analog I/O Module FTM Fuse Locations Figure 8-21—Simplex MPU and Analog I/O Module FTM Fuse Locations 8.6—24/8 Analog Module 8.6.1—Module Description A 24/8 Analog module contains circuitry for twenty-four analog inputs and eight 4–20 mA outputs.
Page 219: Figure 8-22-24/8 Analog Module
Manual 26167V1 MicroNet TMR All 4–20 mA analog inputs may be used with two-wire ungrounded (loop powered) transducers or isolated (self-powered) transducers. All analog inputs have 200 Vdc of common mode rejection. If interfacing to a non-isolated device, which may have the potential of reaching over 200 Vdc with respect to the control’s common, the use of a loop isolator is recommended to break any return...
Page 220 MicroNet TMR Manual 26167V1 Isolation: 0 Vrms, 60 dB CMRR, 200 Vdc common mode rejection voltage; no galvanic isolation Input imp. (4–20 mA): 200 ohms Anti-aliasing filter: 2 poles at 10 ms Resolution: 16 bits Accuracy: Software calibrated to 0.1%, over 0–25 mA full...
Page 221: Figure 8-23-Simplex System Configuration Example
Manual 26167V1 MicroNet TMR Power Supply Power Supply 24/8 Analog High Density Analog/Discrete Cable High Density Analog/Discrete Cable 24/8 Analog FTM (Inputs Ch. 12-24) (Outputs Ch. 5-8) 24/8 Analog FTM (Inputs Ch. 1-12) (Outputs Ch. 1-4) Figure 8-23—Simplex System Configuration Example Analog Inputs For a 4–20 mA input signal, the 24/8 Analog Module uses a 200 ohm resistor...
Page 222: Figure 8-24-Analog Input Wiring For A 24/8 Analog Ftm
MicroNet TMR Manual 26167V1 Figure 8-24—Analog Input Wiring for a 24/8 Analog FTM Analog Outputs There are 8 analog output channels of 4–20 mA with a full scale range of 0–25 mA. All Analog Outputs can drive a maximum load of 600 ohms (load + wire resistance).
Page 223: Figure 8-25-Analog Output Wiring For A 24/8 Analog Ftm
Manual 26167V1 MicroNet TMR Figure 8-25—Analog Output Wiring for a 24/8 Analog FTM 8.6.4—FTM Reference See Chapter 12 for complete field wiring information for the Analog High Density FTM. See Appendix A for part number Cross Reference for modules, FTMs, and cables.
Page 224 MicroNet TMR Manual 26167V1 Microcontroller Faults: The system monitors a software watchdog, a hardware watchdog, and a software watchdog on the VME bus communications. All outputs are shut down in the event of a microcontroller fault. Troubleshooting Guide If during normal control operation, all of the 24/8 Analog modules have Fault LEDs on, check the chassis’...
Page 225 Manual 26167V1 MicroNet TMR Analog Outputs If an analog output is not functioning properly, verify the following: 1. Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14. 2. Check the load resistance to ensure that it is not greater than 600 ohms.
Page 226: Dataforth 24/8 Analog Module
0 to 5 V input compatible with the 24/8 Analog module. Each channel is individually configurable via a plug-in standard isolated Dataforth SCM7B converter that has been modified to meet Woodward’s bandwidth and input temperature range requirements. Each module can plug into any of the 12 channels on the FTM.
Page 227 Manual 26167V1 MicroNet TMR 8.7.2—Specifications To obtain overall signal input accuracy and bandwidth, the Dataforth FTM (0–5 V) module input accuracy and the Dataforth 24/8 Analog Module must be taken into account. Module K Type RTD 100  Pt Pass Through...
Page 228: Figure 8-27-Simplex Dataforth Configuration Example
MicroNet TMR Manual 26167V1 8.7.3—Installation The modules slide into card guides in the control's chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel. Also at the top and bottom of the module are two handles which, when toggled (pushed outward), move the modules out just far enough for the boards to disengage the motherboard connectors.
Page 229: Figure 8-28-Thermocouple Wiring To Simplex Dataforth Ftm
Manual 26167V1 MicroNet TMR The cold junction compensation (CJC) is performed by using an NTC thermistor, externally mounted on the FTM module, as shown in Figure 8-28. The thermocouple signal will fail high if an open wire is detected. These modules incorporate both Thompson (Bessel) and Butterworth five-pole filter to maximize both time and frequency response.
Page 230: Figure 8-29-Rtd Wiring To Simplex Dataforth Ftm
MicroNet TMR Manual 26167V1 MicroNet™ Module Dataforth® FTM Plug-in Module Term Blk Sense Thermistor - In +24 V V out + In 0.01uf, 500V * Note: The thermistor remains present on the FTM on all circuits, but has no effect on the accuracy of the measurement.
Page 231: Figure 8-31-Self-Powered 4-20 Ma Signal Wiring To Simplex Dataforth Ftm
Manual 26167V1 MicroNet TMR MicroNet™ Module Dataforth® FTM 4/20 mA (Self Powered) Plug-in Term Blk Module - In +24 V - 24 V + 24 V Transmitter 4-20mA V out + In 0.01uf, 500V Shield 24 RTN Jumper TB15 Fuse 100 mA 250 V Figure 8-31—Self-powered 4–20 mA Signal Wiring to Simplex Dataforth FTM...
Page 232: Figure 8-33-Analog Output Signal Wiring To Simplex Dataforth Ftm
MicroNet TMR Manual 26167V1 Analog Output Connection The Analog Output circuit doesn’t use a plug-in module. No jumper connections are required. See Figure 8-33 for an example of wiring a 4–20 mA output device. +24 V MicroNet™ Module I/O Lockout Analog Output Dataforth®...
Page 233 Manual 26167V1 MicroNet TMR 8.7.5—Troubleshooting Each Dataforth 24/8 Analog Module has a red Fault LED that is turned on when the system is reset. During initialization of a module, which occurs after every CPU reset, the CPU turns the Fault LED on. The CPU then tests each module using diagnostic routines built into the software.
Page 234 MicroNet TMR Manual 26167V1 3. Verify that there are no or minimal AC components to the Analog Input signal. AC components can be caused by improper shielding. 4. Check the wiring. If the inputs are reading full scale, look for a loose...
Page 235 Manual 26167V1 MicroNet TMR 4–20 mA Analog Inputs If a 4–20 mA analog input is not functioning properly, verify the following: 1. Verify that the correct Dataforth plug-in module is installed. 2. Check that the cable is shielded and the shield is properly grounded.
Page 236 MicroNet TMR Manual 26167V1 Analog Outputs If an analog output is not functioning properly, verify the following: 1. Check that the cable is shielded and the shield is properly grounded. 2. Check the load resistance to ensure that it is not greater than 600 ohms.
Page 237: Analog Combo Module
Manual 26167V1 MicroNet TMR 8.8—Analog Combo Module 8.8.1—Module Description Each High Density Analog Combo module contains circuitry for four speed sensor inputs, eight analog inputs, four analog outputs, and two proportional actuator driver outputs. Each speed sensor input may be from a magnetic pick- up or from a proximity probe, each analog input may be 4–20 mA or 0–5 V, and...
Page 238 MicroNet TMR Manual 26167V1 8.8.2—Module Specifications Digital Speed Sensor Inputs Number of channels: Update time: 5 ms MPU Input Ratings Input frequency: 100 - 25000 Hz Input amplitude: 1-25 Vrms Input impedance: 2000 Ohms Isolation voltage: 500 Vrms Resolution: 12 bits minimum over chosen frequency range Accuracy: 0.03% full scale, minimum...
Page 239 Manual 26167V1 MicroNet TMR 4–20 mA Analog Output Ratings Number of channels: Update time: 5 ms Driver: Pulse Width Modulated (PWM) PWM frequency: 6.14 kHz Filter: 3 poles at 500 ms Current output: 4–20 mA current output range: 0 - 25 mA...
Page 240: Figure 8-36-Simplex System Configuration Example
MicroNet TMR Manual 26167V1 There are two configurations of the Analog Combo Modules. One has the analog inputs configured for 4–20 mA and the other is configured for 0–5 V. See Appendix A for specific part numbers. In a simplex system, each Analog Combo module is connected through two Low Density analog cables to one Analog Combo FTM.
Page 241: Figure 8-37-Mpu/Proximity Interface Wiring To The Analog Combo Ftm
Manual 26167V1 MicroNet TMR When a speed sensor input channel has been wired as either MPU or proximity probe input, the unused MPU/Prox must be jumpered at the FTM. When an input channel is not used, both the MPU and Prox inputs must be jumpered.
Page 242 MicroNet TMR Manual 26167V1 A proximity probe may be used to sense very low speeds. With a proximity probe, speed can be sensed down to 0.5 Hz. When interfacing to open collector type proximity probes, a pull-up resistor is required between the supplied proximity probe voltage and the proximity probe input to the FTM.
Page 243: Figure 8-38-Current Input Wiring For An Analog Combo Module Ftm
Manual 26167V1 MicroNet TMR CABLE MicroNet Module Loop Powered Transducer .01uF Ch. 1 Anti- AI_01 aliasing Filter .01uF Ch. 2 Anti- Self Powered AI_02 aliasing Transducer Filter +24V .01uF SHLD Ch. 3 -Input Anti- AI_03 aliasing Filter +Input +24V .01uF SHLD Ch.
Page 244: Figure 8-18-Voltage Input Wiring For An Analog Combo Module Ftm
MicroNet TMR Manual 26167V1 Only self-powered voltage transducers should be used on voltage input channels. The full scale range must not exceed 5 volts. Refer to Figure 8-39 for 0–5 Vdc voltage transducer input wiring. CABLE MicroNet Module .01uF Ch. 1...
Page 245 (25 Hz) signal consisting of a 5 millisecond pulse modulated onto the DC actuator-drive current to reduce sticking due to friction in linear type actuators. Woodward TM-type actuators typically require dither. Dither amplitude is variable through the application software. See Figure 8-40 for an example of actuator wiring.
Page 246: Figure 8-40-Analog Output And Actuator Wiring For An Analog Combo Ftm
MicroNet TMR Manual 26167V1 CABLE MicroNet Module .01uF SHLD I/O Lockout Ch. 1 +Output Analog AO_01 Output -Output Feedback .01uF Analog Ch. 2 Output Output AO_02 Device .01uF 24 COM SHLD +Output Ch. 3 AO_03 -Output .01uF SHLD Ch. 4...
Page 247 Manual 26167V1 MicroNet TMR Fault Detection (I/O) In addition to detecting module hardware faults, the application program may detect I/O faults. Analog Input Faults. The application software may set a high and low latch setpoint to detect input faults. Speed Sensor Input Faults. The application software may set a high and low latch setpoint to detect input faults.
Page 248 MicroNet TMR Manual 26167V1 Proximity Probes If a proximity probe input is not functioning properly, verify the following: 1. Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14.
Page 249 Manual 26167V1 MicroNet TMR 11. If replacing the module does not fix the problem, replace the FTM. See instructions for replacing the FTM in Chapter 15. The FTM does not contain any active components on the MPU inputs, so replacing it should be the last option.
Page 250: 34 Ch High Density Versatile Input Module (Hdvim)
MicroNet TMR Manual 26167V1 If replacing the module does not fix the problem, replace the FTM. See instructions for replacing the FTM in Chapter 15. The FTM does not contain any active components on the MPU inputs, so replacing it should be the last option.
Page 251: Figure 8-41-34 Channel Hdvim Module
Manual 26167V1 MicroNet TMR Figure 8-41—34 Channel HDVIM Module 8.9.2—Module Specifications Thermocouple/4–20 mA Analog Inputs Number of channels: Current range: 0-24 mA (if configured for 4–20 mA) Voltage range: ±72.8 mV (if configured for thermocouple) Input impedance: 103 ohms (±1%) for 4–20 mA inputs...
Page 252 MicroNet TMR Manual 26167V1 Operational Input common mode voltage range: ±11 V minimum Maximum Non-operational common mode voltage range: ±40 V minimum Anti-aliasing filter: 2 poles at 10 ms (channel 11 has 2 poles at 5 Resolution: 15 bits 4–20 mA Input Accuracy: 1.1% FS (4–20 mA)
Page 253 Manual 26167V1 MicroNet TMR RTD/4–20 mA Analog Inputs Number of channels: Input type: 100 or 200 ohm 3-wire Max. input current: 24 mA, if configured for 4–20 mA Max. input resistance: 781, if configured for RTD RTD source current: 1 mA...
Page 254: Figure 8-42-Simplex System Configuration Example
MicroNet TMR Manual 26167V1 In a Simplex system, each 34 Ch HDVIM module is connected through two high density 62 conductor analog cables to two 34 Ch HDVIM FTMs. All inputs on the module are accessible on the FTM, and the channels are labeled to correspond to their software locations (e.g., analog input 1 on the FTM will be analog input 1...
Page 255: Figure 8-43-Wiring Diagram For 34 Ch Hdvim Ftm
Manual 26167V1 MicroNet TMR Figure 8-43—Wiring Diagram for 34 Ch HDVIM FTM For MicroNet controls using this module to be CE compliant, the power supply used for the FTM "LOOP POWER" must be isolated, protected, and CE marked to EN61000-6-2 and EN61000-6-4 EMC standards.
Page 256 MicroNet TMR Manual 26167V1 4–20 mA Inputs For a 4–20 mA input signal, the 34 Ch HDVIM module uses a 100 ohm resistor across the input. All 4–20 mA inputs may be used with two-wire ungrounded (loop powered) transducers or isolated (self-powered) transducers. All Analog inputs have 11 Vdc of common mode rejection.
Page 257: Figure 8-44-Analog Input Interface Wiring To The 34 Ch Hdvim Module For Thermocouple Inputs
Manual 26167V1 MicroNet TMR 8.9.4—FTM Reference See Chapter 12 for complete 34 Ch HDVIM FTM field wiring information. See Appendix A for proper Module, FTM, and cable part numbers. Figure 8-44—Analog Input Interface Wiring to the 34 Ch HDVIM Module for Thermocouple Inputs Figure 8-45—Analog Input Interface Wiring to the 34 Ch HDVIM Module for...
Page 258 MicroNet TMR Manual 26167V1 8.9.5—Troubleshooting Each 34 Ch HDVIM module has a red fault LED that is turned on when the system is reset. During initialization of a board, which occurs after every CPU reset, the CPU turns the Fault LED on. The CPU then tests the board using diagnostic routines built into the software.
Page 259: Current Input Modules
8.10—Current Input Modules There are three different 8 Ch Current Input modules available from Woodward. These consist of the 8 Ch Current Input (4–20 mA) module, Non-Standard 8 Ch Current Input (4–20 mA) module, and the 8 Ch Current/Voltage Input Module.
Page 260: Figure 8-48-8 Channel Current Input (4-20 Ma) Module
MicroNet TMR Manual 26167V1 Figure 8-48—8 Channel Current Input (4–20 mA) Module 8.11.3—Installation The modules slide into card guides in the control's chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel.
Page 261: Figure 8-49-8 Ch Current Input (4-20 Ma) Module Configuration
Manual 26167V1 MicroNet TMR Power Supply Power Supply Current Input Low Density Analog Cable Analog Input FTM Figure 8-49—8 Ch Current Input (4–20 mA) Module Configuration Field Wiring See Chapter 12 for complete wiring connections for the Analog Input FTM. See Figure 8-50 for transducer wiring.
Page 262: Figure 8-50-Analog Input Wiring For An 8 Ch Current Input (0-25 Ma) Module
MicroNet TMR Manual 26167V1 CABLE MicroNet Module -15V +15V 15V1 .01uF Loop Powered Transducer 7.5V Anti- AI_01 aliasing Filter -15V +15V 15V2 .01uF 7.5V Anti- Self Powered AI_02 aliasing Transducer Filter -15V +15V +15V 15V3 .01uF SHLD Ch. 3 7.5V...
Page 263: Figure 8-51-8 Ch Current Input (0-25 Ma) Module Block Diagram
Manual 26167V1 MicroNet TMR This MUX, under control of the microprocessor, selects the channel to be read. The analog output of this MUX is converted to a digital value by the A/D converter, and passed to the microcontroller. The microcontroller makes any necessary corrections to this value and stores the result in the Dual-Port RAM.
Page 264 MicroNet TMR Manual 26167V1 Limits have been set for the expected readings when the on-board microcontroller reads each voltage reference. If the reading obtained is outside these limits, the system determines that the input channel, A/D converter, or the channel's precision-voltage reference is not functioning properly. If this happens, the micro-controller flags that channel as having a fault condition.
Page 265: Non-Standard 8 Ch Current Input (4-20 Ma) Module
Manual 26167V1 MicroNet TMR 8.12—Non-Standard 8 Ch Current Input (4–20 mA) Module 8.12.1—Module Description Each Non-Standard 8 Ch Current Input (4–20 mA) Module utilizes the same circuitry that the 8 Ch Current Input (4–20 mA) module uses. Seven of the eight double-ended channels of this module are fully isolated.
Page 266: Figure 8-53-Non-Standard 8 Channel Current Input (4-20 Ma) Module Configuration
MicroNet TMR Manual 26167V1 8.12.2—Specification Number of Channels: Input Range: 0–25 mA Accuracy: 0.5% of full scale Temperature Coefficient: 12 ppm/degrees C Anti-aliasing filter 2 poles at 12 ms (Channels 1-6) Anti-aliasing filter 2 poles at 5 ms (Channels 7-8) (Channel 8 is the derivative of channel 7.)
Page 267 Manual 26167V1 MicroNet TMR Field Wiring See Chapter 12 for complete wiring connections for the Non-standard Analog Input FTM. See Figure 8-54 for transducer wiring. The first six analog inputs may be used with two-wire ungrounded (loop powered) transducers or isolated (self-powered) transducers. The seventh channel can be used with a self powered transducer only.
Page 268: Figure 8-54-Analog Input Wiring For A Non-Standard 8 Ch Current Input
MicroNet TMR Manual 26167V1 CABLE MicroNet Module -15V +15V 15V1 .01uF Loop Powered Transducer 7.5V Anti- AI_01 aliasing Filter -15V +15V 15V2 .01uF 7.5V Anti- Self Powered AI_02 aliasing Transducer Filter -15V +15V +15V 15V3 .01uF SHLD Ch. 3 7.5V...
Page 269 Manual 26167V1 MicroNet TMR This MUX, under control of the microprocessor, selects the channel to be read. The analog output of this MUX is converted to a digital value by the A/D converter, and passed to the microcontroller. The microcontroller makes any necessary corrections to this value and stores the result in the Dual-Port RAM.
Page 270: Voltage Input Modules
See instructions for replacing the FTM in Chapter 15. 8.13—Voltage Input Modules There is one voltage input module available from Woodward. 8.14—8 Channel Voltage Input (0–10 Vdc) Module 8.14.1—Module Description Each 8 Ch Voltage Input (0–10 Vdc) Module has eight channels for 0–10 Vdc...
Page 271: Figure 8-55-8 Channel Voltage Input (0-10 Vdc) Module
Manual 26167V1 MicroNet TMR Figure 8-55—8 Channel Voltage Input (0–10 Vdc) Module 8.14.2—Specification Number of Channels: Input Range: 0–10 Volts Accuracy: 0.5% of full scale Temperature Coefficient: 12 ppm/degrees C Anti-aliasing filter 2 poles at 12 ms (Channels 1-8) Module interface:...
Page 272: Figure 8-56-8 Ch Voltage Input (0-10 Vdc) Module Configuration
MicroNet TMR Manual 26167V1 In a simplex system, each 8 Ch Voltage Input module is connected through one analog cable to one FTM. All of the I/O are accessible on the FTM. Power Supply Power Supply Voltage Input Low Density Analog Cable Analog Input FTM Figure 8-56—8 Ch Voltage Input (0–10 Vdc) Module Configuration...
Page 273: Figure 8-57-Voltage Input Wiring For An 8 Channel Voltage Input (0-10 Vdc) Module
Manual 26167V1 MicroNet TMR CABLE MicroNet Module .01uF Anti- 0-10VDC AI_01 aliasing Transducer Filter .01uF SHLD +Input Ch. 2 Anti- AI_02 aliasing Filter -Input .01uF SHLD +Input Ch. 3 Anti- AI_03 aliasing Filter -Input .01uF SHLD +Input Ch. 4 Anti-...
Page 274: Figure 8-58-8 Ch Voltage Input (0-10 Vdc) Module Block Diagram
MicroNet TMR Manual 26167V1 This MUX, under control of the microprocessor, selects the channel to be read. The analog output of this MUX is converted to a digital value by the A/D converter, and passed to the microcontroller. The microcontroller makes any necessary corrections to this value and stores the result in the Dual-Port RAM.
Page 275: Current Output Modules
Manual 26167V1 MicroNet TMR Limits have been set for the expected readings when the on-board microcontroller reads each voltage reference. If the reading obtained is outside these limits, the system determines that the input channel, A/D converter, or the channel's precision-voltage reference is not functioning properly. If this happens, the micro-controller flags that channel as having a fault condition.
Page 276: Ch Current Output (4-20 Ma) Module
MicroNet TMR Manual 26167V1 8.16—8 Ch Current Output (4–20 mA) Module 8.16.1—Module Description Each 8 Ch Current Output (4–20 mA) Module has eight channels for outputting 0–25 mA. The module is connected through one Low Density Analog cable to one Analog Input FTM for field wiring connections.
Page 277: Figure 8-60-8 Ch Current Output (4-20 Ma) Module Configuration
Manual 26167V1 MicroNet TMR 8.16.2—Specification Number of Channels: Current range: 0–25 mA Maximum load resistance: 600 ohms max. Analog Channel bandwidth: 500 Hz min. Module interface: VMEbus Output update time: 1 ms Resolution: 12 bit Accuracy: 0.1% of full scale @25 degrees C...
Page 278 MicroNet TMR Manual 26167V1 There are 8 analog output channels of 4–20 mA with a full scale range of 0–25 mA. All Analog Outputs can drive a maximum load of 600 ohms (load + wire resistance). See Figure 8-61 for analog output connection. Each output monitors the output source current for fault detection.
Page 279: Figure 8-61-Analog Output Wiring For An 8 Channel Current Output (4-20 Ma)
Manual 26167V1 MicroNet TMR CABLE MicroNet Module .01uF SHLD +Output Ch. 1 I/O Lockout AO_01 -Output Analog Output .01uF Feedback Analog Output Ch. 2 Output AO_02 Device 24 COM .01uF SHLD +Output Ch. 3 AO_03 -Output .01uF SHLD +Output Ch. 4...
Page 280: Figure 8-62-Current Output ( 4-20 Ma) Module Block Diagram
MicroNet TMR Manual 26167V1 The microcontroller monitors the output current of each channel and alerts the system if a fault is detected. The current-output drivers can be disabled by the system. If a fault, which prevents the entire card from operating is detected by either the microcontroller or the system, the FAULT LED will illuminate.
Page 281: Ch Current Output (0-1 Ma) Module
Manual 26167V1 MicroNet TMR 8.17—8 Ch Current Output (0–1 mA) Module 8.17.1—Module Description Each 8 Ch Current Output (0–1 mA) Module has eight channels for outputting 0– 1 mA. The module is connected through one Low Density Analog cable to one Analog Input FTM for field wiring connections.
Page 282: Voltage Output Modules
MicroNet TMR Manual 26167V1 8.17.2—Specification Number of Channels: Current range: 0 – 1.25 mA Maximum load resistance: 10 k max. Analog Channel bandwidth: 500 Hz min. Module interface: VMEbus Output update time: 1 ms Resolution: 12 bit Accuracy: 0.1% of full scale @25 °C...
Page 283: Ch Voltage Output (0-5 Vdc ) Module
Manual 26167V1 MicroNet TMR 8.19—8 Ch Voltage Output (0–5 Vdc ) Module 8.19.1—Module Description Each 8 Ch Voltage Output (0–5 Vdc) Module has eight channels for outputting 0– 5 Vdc. The module is connected through one Low Density Analog cable to one Analog Input FTM for field wiring connections.
Page 284: Figure 8-65-8 Ch Voltage Output (0-5 Vdc) Module Configuration
MicroNet TMR Manual 26167V1 8.19.2—Specification Number of Channels: Current range: 0–6.25 V Minimum load resistance: 500 ohms Analog Channel bandwidth: 500 Hz min. Module interface: VMEbus Output update time: 1 ms Resolution: 12 bit Accuracy: 0.1% of full scale @25 °C...
Page 285 Manual 26167V1 MicroNet TMR There are 8 analog output channels of 0–5 Vdc with a full scale range of 0-6.25 Vdc. All Analog Outputs can drive a minimum load of 500 ohms (load + wire resistance). See Figure 8-66 for analog output connection. Each output monitors the output source voltage for fault detection.
Page 286: Figure 8-66-Analog Output Wiring For An 8 Channel Voltage Output (0-5 Vdc) Module
MicroNet TMR Manual 26167V1 CABLE MicroNet Module .01uF +24 V SHLD +Output Ch. 1 I/O Lockout AO_01 -Output Analog Output .01uF Ch. 2 Analog Output AO_02 Output Device Feedback 24 COM .01uF SHLD +Output Ch. 3 AO_03 -Output .01uF SHLD +Output Ch.
Page 287: Figure 8-67-8 Ch Voltage Output (0-5 Vdc) Module Block Diagram
Manual 26167V1 MicroNet TMR Figure 8-67—8 Ch Voltage Output (0–5 Vdc) Module Block Diagram If an analog output is not functioning properly, verify the following: 1. Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14.
Page 288: Ch Voltage Output (0-10 Vdc) Module
MicroNet TMR Manual 26167V1 8.20—8 Ch Voltage Output (0–10 Vdc) Module 8.20.1—Module Description The 8 Ch Voltage Output (0–10 Vdc) Module is the same as a 8 Ch Voltage Output (0–5 Vdc) Module with different feedback gain to scale the output for 0–...
Page 289: Thermocouple Input Modules
Manual 26167V1 MicroNet TMR 8.20.2—Specification Number of Channels: Current range: 0 – 12.5 V Maximum load resistance: 500 ohms min. Analog Channel bandwidth: 500 Hz min. Module interface: VMEbus Output update time: 1 ms Resolution: 12 bit Accuracy: 0.1% of full scale @ 25 °C...
Page 290: Ch Tc (Fail Low) Module
MicroNet TMR Manual 26167V1 8.22—8 Ch TC (Fail Low) Module 8.22.1—Module Description There are eight fully isolated thermocouple channels on this module. Each channel receives a signal from a thermocouple. These signals can be from an E, J, K, R, S, or T type thermocouple. The same module can read all types of thermocouples.
Page 291 Manual 26167V1 MicroNet TMR 8.22.2—Specification Number Channels: 8 double ended, fully isolated, thermocouple input channels 1 cold junction channel. (Type E, J, K, R, S, and T thermocouples must conform to the common commercial specification published in the Annual Book of ASTM Standards with voltage predictions in line with N.I.S.T.
Page 292: Figure 8-70-8 Ch Tc (Fail Low) Module Configuration
MicroNet TMR Manual 26167V1 Power Supply Power Supply Input Low Density Analog Cable TC Input FTM Figure 8-70—8 Ch TC (Fail Low) Module Configuration See Figure 8-71 for Thermocouple field wiring connections. 8.22.4—FTM Reference See Chapter 12 for TC Input FTM information. See Appendix A for proper Module, FTM, and cable part numbers.
Page 293: Figure 8-71-8 Ch Tc Input (Fail Low) Module Field Wiring
Manual 26167V1 MicroNet TMR CABLE MicroNet Module .01uF Anti- TC_01 aliasing Filter .01uF SHLD +Input Ch. 2 Anti- TC_02 aliasing Filter -Input .01uF SHLD +Input Ch. 3 Anti- TC_03 aliasing Filter -Input .01uF SHLD +Input Ch. 4 Anti- TC_04 aliasing...
Page 294: Figure 8-72-Thermocouple Input Block Diagram
MicroNet TMR Manual 26167V1 8.22.5—Troubleshooting The board performs on-line temperature compensation and hardware diagnostics. To do this, once per minute, it reads two known voltages for each channel. These values are checked against certain limits to determine if a hardware fault has occurred. These values are also used to determine software scaling constants used for temperature compensation.
Page 295 Manual 26167V1 MicroNet TMR The CPU also tells this module in which rate group each channel is to run, as well as special information. At run time, the CPU then periodically broadcasts a "key" to all I/O cards, telling them which rate groups are to be updated at that time.
Page 296: Ch Tc (Fail High) Module
MicroNet TMR Manual 26167V1 8.23—8 Ch TC (Fail High) Module 8.23.1—Module Description There are two types of the Thermocouple (Fail High) modules. The standard module is the same as the 8 Ch TC (Fail Low) Module except when a failure is detected, the signal will indicate a full scale value.
Page 297: Rtd Input Modules
Manual 26167V1 MicroNet TMR Thermocouple Types and ranges: T/C TYPE LOW END °C (°F) HIGH END °C (°F) -40  C (-40  F) 1050  C (1922  F) -40  C (-40  F) 1600  C (29125  F) -40 ...
Page 298: Ch Rtd Input (10 Ohm)
MicroNet TMR Manual 26167V1 8.25—8 Ch RTD Input (10 ohm) 8.25.1—Module Description The eight channels of this module are semi-isolated. The channels are isolated from the control common but not from each other. Each channel receives a signal from an RTD. This signal must be from a 10 Copper RTD with the following temperature to Resistance relationship: T=(R*25.95)-(234.5)
Page 299: Figure 8-75-8 Ch Rtd Module Configuration
Manual 26167V1 MicroNet TMR 8.25.2—Specification Number of Channels: 8 semi-isolated, RTD channels Input Type: 3 wire (Must conform to 10 ohm copper RTD temperature/resistance relationship (Alpha = .00427)) Temperature range: 40 to +300 °C Module interface: VMEbus Output: Linearized temperatures in °C...
Page 300 MicroNet TMR Manual 26167V1 8.25.4—FTM Reference See Chapter 12 for complete field wiring information for the 8 Ch RTD Input (10 ohm) FTM. See Appendix A for part number Cross Reference for modules, FTMs, and cables. 8.25.5—Troubleshooting The board performs on-line temperature compensation and hardware diagnostics.
Page 301: Figure 8-76-8 Ch Rtd Input Module Field Wiring
Manual 26167V1 MicroNet TMR CABLE MicroNet Module .01uF Current Source RTD_01 Sense .01uF Shld Ch. 2 +Input Current Source RTD_02 -Input Sense .01uF Shld Ch. 3 +Input Current Source RTD_03 -Input Sense .01uF Shld Ch. 4 +Input Current Source RTD_04...
Page 302: Figure 8-77-Rtd Input Block Diagram
MicroNet TMR Manual 26167V1 This MUX, under control of the microprocessor, selects the channel to be read. The analog output of this MUX is converted to a digital value by the A/D converter, and passed to the microcontroller. The microcontroller uses a lookup table to linearize the RTD reading and stores the result in the Dual-Port RAM.
Page 303: Ch Rtd Input (100 Ohm)
Manual 26167V1 MicroNet TMR Limits have been set for the expected readings when the on-board microcontroller reads each voltage reference. If the reading obtained is outside these limits, the system determines that the input channel, A/D converter, or the channel's precision-voltage reference is not functioning properly. If this happens, the micro-controller flags that channel as having a fault condition.
Page 304: Figure 8-78-8 Channel Rtd Input Module (100 Ohm)
MicroNet TMR Manual 26167V1 Figure 8-78—8 Channel RTD Input Module (100 ohm) 8.26.2—Specification Number of Channels: 8 semi-isolated, RTD channels Input Type: 3 wire (Must conform to (Deutsche Institut for Normung) DIN standard for 100 ohm European curve (Alpha = .00385) or American curve 100 ohm curve (Alpha = .00392))
Page 305: Ch Rtd Input (200 Ohm)
Manual 26167V1 MicroNet TMR 8.26.3—Installation See 8 Ch RTD Input (10 ohm) Module. 8.26.4—FTM Reference See Chapter 12 for complete field wiring information for the 8 Ch RTD Input (100 ohm) FTM. See Appendix A for part number Cross Reference for modules, FTMs, and cables.
Page 306: Ch Rtd Input (500 Ohm)
MicroNet TMR Manual 26167V1 8.27.2—Specification Number of Channels: 8 semi-isolated, RTD channels Input Type: 3 wire (Must conform to (Deutsche Institut for Normung) DIN standard for 200 ohm European curve (Alpha = .00385) or American curve 200 ohm curve (Alpha = .00392))
Page 307: Figure 8-80-8 Channel Rtd Input Module (500 Ohm)
Manual 26167V1 MicroNet TMR Figure 8-80—8 Channel RTD Input Module (500 ohm) 8.28.2—Specification Number of Channels: 8 semi-isolated, RTD channels Input Type: 3 wire (Must conform to (Deutsche Institut for Normung) DIN standard for 500 ohm European curve (Alpha = .00385) or American curve 500 ohm curve (Alpha = .00392))
Page 308: Ch Mpu/Proximity Module
MicroNet TMR Manual 26167V1 8.28.3—Installation See 8 Ch RTD Input (10 ohm) Module. 8.28.4—FTM Reference See Chapter 12 for complete field wiring information for the 8 Ch RTD Input (500 ohm) FTM. See Appendix A for part number Cross Reference for modules, FTMs, and cables.
Page 309: Figure 8-81-4 Channel Mpu/Proximity Module
Manual 26167V1 MicroNet TMR 8.29.2—Specification Number Channels: Input Type: MPU/Proximity Detector (factory selected by part number) Input Frequency Range: MPU: 50 Hz to 25 KHz Prox: 0.04 Hz to 2 KHz Input Amplitude: MPU: 1 Vrms min, 25 Vrms max, Freq > 20 Hz...
Page 310: Figure 8-82-4 Ch Mpu/Proximity Module
MicroNet TMR Manual 26167V1 8.29.3—Installation The modules slide into card guides in the control's chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel. Also at the top and bottom of the module are two handles which, when toggled (pushed outward), move the modules out just far enough for the boards to disengage the motherboard connectors.
Page 311 Manual 26167V1 MicroNet TMR 8.29.4—FTM Reference See Chapter 12 for complete field wiring information for the 4 Ch MPU/Proximity FTM. See Appendix A for part number Cross Reference for modules, FTMs, and cables. 8.29.5—Troubleshooting Speed ranges are selected from the GAP and the signal is pre-scaled accordingly.
Page 312: Figure 8-83-Mpu And Proximity Probe Interface Wiring
MicroNet TMR Manual 26167V1 CABLE MicroNet Module +24VDC +5VDC .01uF MPU_01 JPR 3 MPU #1 JPR 1 +24V .01uF Shld MPU/PROX_02 Ch. 2 +Input -Input +24V .01uF Shld MPU/PROX_03 Ch. 3 +Input +24VDC +5VDC -Input +24VDC .01uF JPR 23 PROX_04...
Page 313: Figure 8-84-Digital Speed Sensor Module Block Diagram
Manual 26167V1 MicroNet TMR Figure 8-84—Digital Speed Sensor Module Block Diagram The CPU also tells this module in which rate group each channel is to run, as well as special information. At run time, the CPU then periodically broadcasts a "key"...
Page 314 MicroNet TMR Manual 26167V1 Proximity Probes If a proximity probe input is not functioning properly, verify the following: 1. Check that the cable is shielded and the shield is properly grounded per the Shields and Grounding section in Chapter 14.
Page 315: Revision History
Manual 26167V1 MicroNet TMR Revision History Changes in Revision J—  Minor correction in section 5.1.5  Corrected Figure 7-7 Changes in Revision H—  Updated Compliance information.  Updated front panel indicator tables and related information as marked with change bars.
Page 316 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.

Woodward MicroNet TMR Installation And Operation Manual

Warnings and Notices

Electrostatic Discharge Awareness

Regulatory Compliance

Chapter 1. General Information

Chapter 2. Micronet TMR Systems

Chapter 3. Chassis Configurations

Chapter 4. Power Supplies

Chapter 5. CPU

Cpus

Chapter 6. Communication

Chapter 7. Discrete I/O Modules

Chapter 8. Analog I/O Modules

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Woodward MicroNet TMR

Summary of Contents for Woodward MicroNet TMR
