Released
Product Manual 35219V1
(Revision -, 10/2024)
Original Instructions
MicroNet XT™ Control
Manual 35219 consists of four volumes:
(35219V1, 35219V2, 35219V3, & 35219V4)
Installation and Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroNet XT Control and is the answer not in the manual?

Questions and answers

Related Manuals for Woodward MicroNet XT Control

Summary of Contents for Woodward MicroNet XT Control

  • Page 1 Released Product Manual 35219V1 (Revision -, 10/2024) Original Instructions MicroNet XT™ Control Manual 35219 consists of four volumes: (35219V1, 35219V2, 35219V3, & 35219V4) Installation and Operation Manual...
  • Page 2 Revisions— A bold, black line alongside the text identifies changes in this publication since the last revision. Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly undertaken.

  • Page 3: Table Of Contents

    3.1.3 Troubleshooting .......................... 19 4. P ....................20 HAPTER OWER UPPLIES 4.1. MicroNet XT Control Power Supply Low Voltage 24 VDC ..............20 4.1.1 Specifications ..........................21 4.1.2 Installation ..........................22 4.1.3 Input Power Wiring ........................23 4.1.4 Troubleshooting .......................... 26 5. M XT CPU ....................
  • Page 4 9.2. Product Service Options ........................83 9.3. Returning Equipment for Repair ......................84 9.4. Replacement Parts ..........................84 9.5. Engineering Services ........................... 84 9.6. Contacting Woodward’s Support Organization ..................85 9.7. Technical Assistance ........................... 86 A. E ................87 PPENDIX...
  • Page 5 Figure 5-7. Simple Teamed NIC Setup ....................... 33 Figure 5-8. Simple Un-teamed NIC Setup ....................34 Figure 5-9. Teamed Network with No Direct Connection to MicroNet XT Control CPU ......35 Figure 5-10. Factory Reset Button ......................37 Figure 6-1. MicroNet XT DIO 32/16 Module ....................38 Figure 6-2.
  • Page 6 Table 5-3. MicroNet XT Control CPU Module Front Panel LEDs ............... 29 Table 5-4. MicroNet XT Control CPU Module Ethernet Connector (RJ45) Ports #1-4 (10/100/1000) ..32 Table 5-5. MicroNet XT Control CPU Module CPU OK and COMMS LED Flash Codes......36 Table 6-1.

  • Page 7: Warnings And Notices

    Released Manual 35219V1 MicroNet XT Control Warnings and Notices Important Definitions This is the safety alert symbol used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 8: Personal Protective Equipment

    Released Manual 35219V1 MicroNet XT Control The engine, turbine, or other type of prime mover should be equipped with an overspeed shutdown device to protect against runaway or damage to the prime mover with possible personal injury, loss of life, or property damage.

  • Page 9: Electrostatic Discharge Awareness

    Do not touch the components or conductors on a printed circuit board with your hands or with conductive devices. To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715 , Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.

  • Page 10: Regulatory Compliance

    Released Manual 35219V1 MicroNet XT Control Regulatory Compliance European Compliance for CE Marking These listings are limited only to those units bearing the CE Marking: EMC Directive: Declared to Directive 2014/30/EU of the European Parliament and of the Council of 26 February 2014 on the harmonization of the laws of the Member States relating to electromagnetic compatibility (EMC) and applicable amendments.

  • Page 11: Special Conditions For Safe Use

    This equipment is to be installed by professional service personnel according to the instructions given in this manual. The MicroNet XT Control shall not be installed in areas where the microenvironment exceeds Pollution Degree 2, as defined in IEC 60664-1.
  • Page 12 Installation must be provided by professional service personnel according to the instructions given in this manual. The MicroNet XT Control must be installed inside a metal enclosure or cabinet to meet the EMC Directive requirements. Reference Chapter 8 for considerations regarding the installation location and EMC Compliance specific cabinet construction requirements.

  • Page 13: Chapter 1. General Information

    Modbus, and other protocols are included so that the user can interface the control to existing or new plant level systems. The MicroNet XT Control is available in a 14 slot chassis. Each chassis has dedicated slots for the power supply module and CPU module. The power supply architecture supports simplex or redundant power supply modules.

  • Page 14: Chapter 2. Micronet Xt Control Systems

    PS1 and PS2. 2.1.2. Simplex CPU The MicroNet XT Control system used in simplex mode must have a single CPU module that is located in slot A1 of the chassis. 2.1.3. Simplex Inputs and Outputs Figure 2-2 shows the flow of analog and discrete input signals from the field to the application.

  • Page 15: Redundant Inputs

    Released Manual 35219V1 MicroNet XT Control Figure 2-2. Input Flow Figure 2-3 shows the flow of outputs from the application to the field. Figure 2-3. Output Flow 2.1.4. Redundant Inputs Two levels of redundancy are available. The first involves wiring two external input devices to two separate input channels, see Figure 2-4.

  • Page 16: Redundant Outputs

    Released Manual 35219V1 MicroNet XT Control The second level is wiring two external input devices to two separate I/O modules. See Figure 2-5. In the event of a failure in one of the sensors, connections, cables, or I/ O modules, a valid input is still available.

  • Page 17: Chapter 3. Chassis Configurations

    Chapter 3. Chassis Configurations The MicroNet XT Control system is developed around the chassis, power supply module(s), and CPU module. The MicroNet XT supports connectorized field wiring through module connectors. The terminal connectors are keyed for orientation to prevent incorrect insertion when plugging into the module J- connector ports.

  • Page 18: Chassis Outline Drawing

    Released Manual 35219V1 MicroNet XT Control 3.1.1.1 Power Supply Slots (PS1, PS2) The MicroNet XT system uses one or two 2-slot wide power supplies. The first power supply module goes in the left side of the chassis in the slots designated as PS1.

  • Page 19: Figure 3-3. Micronet Xt 14-Slot Chassis Mounting Footprint Dimensions

    Released Manual 35219V1 MicroNet XT Control Figure 3-3. MicroNet XT 14-Slot Chassis Mounting Footprint Dimensions Woodward...

  • Page 20: Figure 3-4. Micronet Xt 14-Slot Chassis Ground Locations

    There are two ground connections on the XT chassis. The recommended ground connection point for the MicroNet XT Control is under the chassis, as shown in Figure 3-4. As an alternative, the ground on the side of the chassis can be used.

  • Page 21: Troubleshooting

    Released Manual 35219V1 MicroNet XT Control The chassis of the control must also be electrically bonded to ground in order to maintain EMC compliance. EMC Compliance Electrical bonding is accomplished by providing a low impedance strap or large surface area contact between any two, or more, metal...

  • Page 22: Chapter 4. Power Supplies

    Chapter 4. Power Supplies The MicroNet XT Control system supports the low voltage power supply module. Each power supply module is 2 slots wide and resides in the left 2 slots of the chassis for simplex power supply systems. Redundant power supply systems include a second power supply in the right 2 slots of the chassis.

  • Page 23: Specifications

    Released Manual 35219V1 MicroNet XT Control 4.1.1 Specifications For a particular system configuration, use the MicroNet XT Power Program to calculate the output current requirements as a function of the Chassis, CPUs, and I/O modules used in the system. Table 4-2. MicroNet XT LVPS Module Specification (24 VDC Input) 18 –...

  • Page 24: Installation

    If at any time during this procedure the defined or expected result is not achieved, begin system troubleshooting. 1. Verify that the entire MicroNet XT Control system has been installed. 2. Verify correct wiring and polarity on the connector. 3. For systems with a single LVPS module installed: 3.1 Turn the power on to the LVPS module and verify that the POWER IN and OUT LEDs on front...

  • Page 25: Input Power Wiring

    Released Manual 35219V1 MicroNet XT Control 4.2 Turn the power on to the second LVPS module and verify that the POWER IN and OUT LEDs on front panel are green. 4.3 Turn the power off to the first LVPS module and verify that the POWER IN and OUT LEDs on front panel of second LVPS module are still green.
  • Page 26 (1) It is up to the end installer to determine amperage rating that will be consumed by the MicroNet XT Control. (2) At no time may the calculated MicroNet XT Control power consumption (total draw of CPU and I/O modules) exceed 110% of 375W.
  • Page 27 Released Manual 35219V1 MicroNet XT Control The XT Power Supplies module’s power wires must remain in intimate contact with each other along their length: twisted together at a rate of at least one or two twists per meter is sufficient.

  • Page 28: Troubleshooting

    Released Manual 35219V1 MicroNet XT Control 30 x 0.116 = 3.48 V. It is very important to ensure the voltage at module input terminal is within the product power input specification to achieve the maximum performance. Note that the control’s power supplies are not equipped with input power switches.

  • Page 29: Chapter 5. Micronet Xt Cpus

    MicroNet XT Control Chapter 5. MicroNet XT CPUs The MicroNet XT Control supports one CPU module in the first slot to the right of the power supply (PS1) in the chassis (Slot A1). Table 5-1. MicroNet XT Control CPU Module Part Numbers...

  • Page 30: Specifications

    Front Panel Indicators Refer to Table 5-3 Service Ports 2, Woodward use only Module Reset Reset switch provided A functional block diagram of the module is shown in Figure 5-2. Figure 5-2. MicroNet XT Control CPU Module Block Diagram Woodward...

  • Page 31: Cpu Front Panel Indicators

    Released Manual 35219V1 MicroNet XT Control 5.1.2 CPU Front Panel Indicators Table 5-3. MicroNet XT Control CPU Module Front Panel LEDs Name Description GREEN – CPU status OK CPU OK CPU Module RED – CPU fault. STATUS, Actively flashes CPU fault CPU OK LED codes when applicable.

  • Page 32: Figure 5-3. Micronet Xt Control Cpu Reset Buttons

    Released Manual 35219V1 MicroNet XT Control Figure 5-3. MicroNet XT Control CPU Reset Buttons 5.1.2.3. Gbit Ethernet Ports There are four Gbit Ethernet Ports (RJ45) available to the application software, labeled ENET1 through ENET4, as shown in Figure 5-1 and Figure 5-3. These ports are full duplex, auto switching, and do not require the use of an Ethernet shield box.

  • Page 33: Figure 5-4. Micronet Xt Control Cpu Service Port Interface

    Refer to Figure 5-5 and Figure 5-6 for connector pinout. For debug use, a Woodward PN 5417-1344, USB to serial debug cable is required to attach these ports to a PC. These ports are to be used by trained field service personnel only! Figure 5-5.

  • Page 34: Installation

    ETHERNET CABLES—Max cable length is 100 meters. For robust operation, double shielded (SSTP) Cat5e (or better) Ethernet cables are required for customer installations. (Woodward PN 5417-394, 10 feet) Table 5-4. MicroNet XT Control CPU Module Ethernet Connector (RJ45) Ports #1-4 (10/100/1000) Board Connection Description Pin 1 – TD1+ Pin 2 –...

  • Page 35: Figure 5-7. Simple Teamed Nic Setup

    Released Manual 35219V1 MicroNet XT Control For detailed instructions on using AppManager to configure the control ports, refer to the “Network Setup Instructions for the Control” section of the software manual (35219 V3). 5.1.4.2 Network Topologies As a rule, the MicroNet XT CPU should not be directly connected to a workstation with a teamed network setup.

  • Page 36: Figure 5-8. Simple Un-Teamed Nic Setup

    Released Manual 35219V1 MicroNet XT Control Figure 5-8. Simple Un-teamed NIC Setup Note: A teamed network can be a part of an industrial control system and play an important part in load balancing and failover as a complete system. However, NO DIRECT CONNECTION to a MicroNet XT CPU by a teamed NIC IP address should be part of the network configuration.

  • Page 37: Figure 5-9. Teamed Network With No Direct Connection To Micronet Xt Control Cpu

    Released Manual 35219V1 MicroNet XT Control Figure 5-9. Teamed Network with No Direct Connection to MicroNet XT Control CPU Woodward...

  • Page 38: Troubleshooting

    0.25 seconds, flashes and pauses with one second pauses between the two numbers and a three second pause before the code repeats. Flash code definitions are module specific. Table 5-5. MicroNet XT Control CPU Module CPU OK and COMMS LED Flash Codes Number of...

  • Page 39: Figure 5-10. Factory Reset Button

    • Verify cabling meets CAT-5e or better performance specs. • Verify cables are shielded properly per Woodward spec (using inner foil and outer braid). Refer to Chapter 8. • Verify each cable is connected to the desired port and the cable is labeled with correct port number.

  • Page 40: Chapter 6. Discrete I/O Modules

    Chapter 6. Discrete I/O Modules The MicroNet XT Control supports discrete input/output modules, sometimes called “digital I/O modules”. These modules can read discrete inputs, such as level switches, toggle switches, and relay contacts, and they can drive discrete outputs for field devices such as relays.

  • Page 41: Discrete Input Specifications

    Released Manual 35219V1 MicroNet XT Control 6.1.1 Discrete Input Specifications Table 6-3. Discrete Input Specifications Number of Channels Operating Temperature Range -40 °C to 70 °C DI Channel Input Voltage 0 - 32 VDC DI Channel Input Current 3 to 7 mA at 24 VDC, typical 4 mA <...

  • Page 42: Installation

    • Discrete inputs are not individually isolated, they are isolated as a group from the discrete outputs and from the rest of the MicroNet XT Control. • If an external 24 VDC source is used, the common for the external 24 VDC must be tied to the discrete input common (DI_COM), see Figure 6-12.

  • Page 43: Module Wiring

    Released Manual 35219V1 MicroNet XT Control • The built-in contact power output (CPWR) power supply is dedicated for use with DI channels only. The power supplies are isolated from each other, so the CPWR power supply cannot power the DIO channels (DIO-1 through DIO-16) and the RPWR power supply can’t power the DI channels (DI-1...

  • Page 44: Figure 6-4. Special Nylon Wiring Tool

    Released Manual 35219V1 MicroNet XT Control Each I/O module ships with a special nylon tool to assist with wiring the connectors, see Figure 6-4. The connectors have spring loaded terminals. To insert a wire into the connector, slide the long end of the tool along the exposed spring on the side of the connector, pressing down firmly.

  • Page 45: Figure 6-7. Inserting The Keying Element Into The Module Connector

    Released Manual 35219V1 MicroNet XT Control Figure 6-7. Inserting the Keying Element into the Module Connector The MicroNet XT DIO 32/16 module connector pinouts are shown in Figure 6-8. Figure 6-8. DIO 32/16 Module Connector Pinout I/O Module Signal, Power, and Common Wire Cabling New installations require coil and wetting voltage power and common wires to be routed with signal wires and shielding of DI/DO, power, and return wires as bundles, as are applicable.

  • Page 46: Figure 6-9. Dio 32/16 Module Relay Module Wiring

    Released Manual 35219V1 MicroNet XT Control The shielding options items listed must be grounded to the cabinet housing where the MicroNet XT system is installed and are electrically continuous between the field device and the cabinet. (Except in installations where cable shielding crosses an Intrinsically Safe boundary of a Hazardous Atmosphere.) Unshielded discrete I/O wire groups or cables may only be used inside the cabinet, or for cabling that is restricted to very short distances, ≤30m cables, when there is a secondary shield, and in retrofit...

  • Page 47: Field Wiring

    Released Manual 35219V1 MicroNet XT Control 6.1.5. Field Wiring 6.1.5.1 Discrete Input Field Wiring Figure 6-10 shows the discrete input wiring for a system using the module internal power supply. Figure 6-11 shows the wiring for a system using an external power supply.

  • Page 48: Relay Box Module-8 Channel

    Released Manual 35219V1 MicroNet XT Control 6.1.6 Relay Box Module—8 Channel This relay module is for use in ordinary or non-hazardous locations only. The MicroNet XT DIO 32/16 module supports 6A and 10A relay modules. They can be ordered with a cable (3 m length) that has the relay connector on one end and open (flying) leads on the other end.
  • Page 49 Released Manual 35219V1 MicroNet XT Control Relay contacts for VAC signals (115 VAC, 2 Amps) shall be connected to a control circuit equipped with the transformer or other source of supply providing double or reinforced insulation from the main circuits.

  • Page 50: Troubleshooting

    Released Manual 35219V1 MicroNet XT Control 6.1.7 Troubleshooting Each module contains a status LED that can illuminate GREEN or RED, to annunciate the module health. A green LED indicates the module is healthy and operational. A red LED indicates the module is in IOLOCK, initializing, in HALT mode, or has a fault.
  • Page 51 Released Manual 35219V1 MicroNet XT Control Table 6-9. DIO LED Indications of Failure (cont’d.) Number of Status LED Flashes Failure Bootloader 4, 10 NULL-pointer Dereference Continued 4, 11 Destructive Unlock Failed 4, 12 Flash Loader Initialization Failed 4, 13 Invalid Bootloader Part Number...
  • Page 52 Released Manual 35219V1 MicroNet XT Control • Verify each DI(+) wiring is functional by setting each input HIGH (>16 V DC) and then LOW (<8 V DC). Verify that the voltage at the module changes. • When possible, consider using a shielded DIN cable.

  • Page 53: Chapter 7. Analog I/O Modules

    Chapter 7. Analog I/O Modules The MicroNet XT Control supports modules for analog inputs and outputs. Inputs include 4 – 20 mA inputs, 0-5V inputs, RTD and thermocouple inputs, and Speed inputs. Outputs include 4 – 20 mA and 0 –...

  • Page 54: Specifications

    Released Manual 35219V1 MicroNet XT Control 7.1.1. Specifications 7.1.1.1 Common Ratings Table 7-1. Flex AIO Module General/Common Specifications Operating Temperature Range -40 °C to 70 °C 7.1.1.2 Speed Sensor Input Specifications Table 7-2. Flex AIO Module Speed Sensor Specifications Number of Channels...
  • Page 55 Released Manual 35219V1 MicroNet XT Control 7.1.1.3 4 - 20 mA/0 – 5 V Input Specifications Table 7-3. Flex AIO Module 4 – 20 mA/0-5 V Specifications Number of Channels Up to 8 AI Input Range (0 to 25) mA or 0-6 V, set in GAP application...
  • Page 56 Released Manual 35219V1 MicroNet XT Control RTD Curve Types Table 7-6. Flex AIO Module RTD Curve Types European Curve (100 EU, 200 EU) American Curve (100 US, 200 US) per IEC 60751 spec per ITS-90 update R0 =100 Ω or 200 Ω platinum R0 =100 Ω...

  • Page 57: Figure 7-2. Flex Aio Module Block Diagram

    Released Manual 35219V1 MicroNet XT Control 7.1.1.6 4 – 20 mA/0 – 200 mA Proportional Actuator Output Specifications Table 7-9. Flex AIO Module Proportional Actuator 4 – 20 mA/0 – 200 mA Output Ratings Number of Channels 2 (each with readbacks)

  • Page 58: Installation

    Released Manual 35219V1 MicroNet XT Control 7.1.2. Installation The Flex AIO modules slide into card guides in the control's chassis and plug into the backplane. They are secured with screws at the top and bottom. Each mounting screw should be torqued to 6 Nm (53 lb- in) but can also be hand-tightened.
  • Page 59 Released Manual 35219V1 MicroNet XT Control 7.1.2.1.3 RTD Inputs The first 4 analog input channels can be configured as RTD inputs. See Figure 7-12 for RTD input connection. The RTD type (100 or 200 Ohm) and curve type (American or European) are configured in software.

  • Page 60: Module Wiring

    Released Manual 35219V1 MicroNet XT Control 7.1.2.1.4 Thermocouple Inputs All eight analog input channels can be configured as Thermocouple inputs. See Figure 7-13 for thermocouple input connection. The thermocouple type is configured in software. The module contains individual cold junction (CJ) compensation sensors for each of the 8 channels to support directly wiring T/C sensors to the module.

  • Page 61: Figure 7-4. Special Nylon Wiring Tool

    Released Manual 35219V1 MicroNet XT Control Each connector plug is equipped with an integrated strain relief tab. The strain relief tab can be removed if desired by sliding it down the center line of the connector. Wiring can be secured to the strain relief tab by running zip ties through the provided holes in the tab.

  • Page 62: Figure 7-6. Removing Connector Plug Keying Tab

    Released Manual 35219V1 MicroNet XT Control To troubleshoot or check terminated wiring, the exposed metal springs can be used as probing test points. Additionally, each I/O module also ships with coding elements. Coding is optional and allows the customer to key each connector uniquely so that they cannot be plugged into the wrong module position, both between J1 and J2 and across modules.

  • Page 63: Field Wiring

    Released Manual 35219V1 MicroNet XT Control The MicroNet XT Flex AIO module connector pinouts are shown in Figure 7-8. Figure 7-8. Flex AIO Module Connector Pinouts 7.1.4. Field Wiring Figure 7-9 shows the Flex AIO module wiring for MPU and proximity probe sensors.

  • Page 64: Figure 7-10. Flex Aio Module Self And Loop Powered Analog Input Wiring

    Released Manual 35219V1 MicroNet XT Control Self-Powered Wiring Loop Powered Wiring Figure 7-10. Flex AIO Module Self and Loop Powered Analog Input Wiring Figure 7-11 shows the Flex AIO module voltage input wiring. Figure 7-11. Flex AIO Module Voltage Input Wiring Figure 7-12 shows the Flex AIO module wiring for 2 and 3 wire RTD inputs.

  • Page 65: Troubleshooting

    Released Manual 35219V1 MicroNet XT Control Figure 7-14. Flex AIO Module Proportional Actuator Output Wiring shows the Flex AIO module wiring for a proportional actuator driver outputs. Figure 7-14. Flex AIO Module Proportional Actuator Output Wiring External wiring connections for reverse-acting controls are identical to those for direct-acting controls.
  • Page 66 Released Manual 35219V1 MicroNet XT Control Table 7-11. Flex AIO LED Indications of Failure Number of Status Failure LED Flashes Main Application 1, 2 Tick Slip Fault 1, 3 MFT Timing Fault 1, 4 Rate Group Key Fault 1, 5...
  • Page 67 Released Manual 35219V1 MicroNet XT Control 7.1.5.2 Fault Detection In addition to detecting MicroNet XT Flex AIO Module hardware faults, the application software may detect I/O channel faults. Analog I/O Faults: The module monitors the I/O control voltage and annunciates faults. The application software determines the course of action in the event of a fault.
  • Page 68 Released Manual 35219V1 MicroNet XT Control • Measure the input voltage on the terminal block, compare to the GAP configured threshold voltage. • Measure the frequency. It should be in the range of 0.1 Hz to 35 kHz. • If using Prox Power, verify that wiring is correct and isolation between sensors is maintained.
  • Page 69 Released Manual 35219V1 MicroNet XT Control • Check to ensure that the load wiring is isolated. Verify each AO(+,–) is not shorted to another output channel. Verify each AO(+,–) is not shorted to another analog input channel. Verify each AO(+) terminal is not shorted to PS(+), PS(–), EARTH.

  • Page 70: Chapter 8. Installation And Replacement Procedures

    8.1.3. Unit Location Consider the following when selecting a cabinet location to mount the MicroNet XT Control: • Make sure the MicroNet XT Control unit(s) are mounted in a dry location, protected from water and condensation. • Make sure the ambient temperature of the system location is not lower than -40 °C (-40 °F) or higher than 70 °C (131 °F) and that the relative humidity is not over 95%, non-condensing.

  • Page 71: Installing A Cpu Or I/O Module Into An Unpowered Chassis

    Released Manual 35219V1 MicroNet XT Control HOT SURFACES—The surface of this product can become hot enough or cold enough to be a hazard. Use protective gear for product handling in these circumstances. Temperature ratings are included in the specification section of this manual.

  • Page 72: Installing A Micronet Xt Power Supply Module

    AC signals, or floated, galvanically isolated, from the local ground. MicroNet XT Control is designed to have the DC termination of shields to ground at the control and float or AC terminate the shield at the opposite end (the field end). The cabinet installation wiring also requires that the IO signal shielding be either AC or DC terminated at the boundary of the cabinet where cables and wiring transition from outside the cabinet to inside it.
  • Page 73 The preferred installation is to shield the DIO wiring groups. The cabling in installation environments for the MicroNet XT Control typically also has a secondary shield around the bundled wire shields, the bundled signal cable shields, or the signal cable bundles. The outer shield may be identical to the inner shield, or it may be provided by items like metal conduit or enclosed cable trays, braided steel wire armor, the skid structure package, or similar shielding.

  • Page 74: Wiring Notes

    MicroNet XT may be needed. A power line filter is not expected to be needed but may be needed if there is noisy equipment in the cabinet beyond the MicroNet XT, or there is sensitive equipment collocated with the MicroNet XT control. Woodward...

  • Page 75: Figure 8-2. Cable Shield Termination Diagram

    Released Manual 35219V1 MicroNet XT Control Control Cable bundle Shield Field • Option Option • • Option Option Control Option Option Option Cabinet at • Entrance/Exit Distribution • Point • • • • Control • • • Figure 8-2. Cable Shield Termination Diagram...

  • Page 76: Grounding And Grounding Concerns

    Released Manual 35219V1 MicroNet XT Control 8.3.3. Grounding and Grounding Concerns Ground or grounds must first address implementation of safety ground requirements. It is also possible to meet the safety ground requirements and maintain a very good EMC ground. Do not connect chassis ground or PE ground to any I/O signal reference, common, or return.

  • Page 77: Cable Entry And Exit (Transition) Locations

    Released Manual 35219V1 MicroNet XT Control Ground Noise Interference Transient ground bounce is the most common ground interference noise. Transient ground bounce is caused when a nearby lightning strike equalizes its charge, or when high current switched inductive loads dump their stored energy.

  • Page 78: Equipment Zoning (Segregation)

    Released Manual 35219V1 MicroNet XT Control If shields are AC coupled at both ends, remote and local, shield capacitors should be rated at great than or equal to 750 VDC standoff voltage. Capacitors used for AC shield termination must be less than 20 mΩ ESR.

  • Page 79: Input Power Routing And Filtering

    Released Manual 35219V1 MicroNet XT Control 8.3.6. Input Power Routing and Filtering • Input power must enter the cabinet and be routed separately from all other circuits. • Input power must route directly to controls that are industrial compliant. •...

  • Page 80: Unshielded I/O

    Released Manual 35219V1 MicroNet XT Control Field I/O Cable without Field I/O Module in Cabinet, Remote Located • Ground I/O cable shield, direct, at the I/O module If over braid shielded, ground over braid shields to cabinet - connect inner braid shields at I/O module termination point.

  • Page 81: Installation Of Other Equipment, Fans, Meters, Etc

    8.4.1. EMC Cabinet Indication The MicroNet XT Control is required to be installed into a standard metal cabinet or enclosure. As the system grows beyond a single controller, is used in a harsh EMC environment, or used in an area where equipment in the application environment is sensitive to electric, magnetic, or electromagnetic energy, it is recommended to use an EMC rated cabinet.

  • Page 82: Shields And Grounding

    Released Manual 35219V1 MicroNet XT Control MicroNet XT emissions levels are designed to not have issues with typical equipment; however, very sensitive receivers or measurement equipment will often need greater protection than is afforded by meeting the intended initial limitations on emissions.

  • Page 83: Replacement Procedures

    Fully remove the module: Remove the module by pulling it straight out and putting it into a conductive plastic bag. (Woodward P/N 4951-041). Inspect and partially install module: Prior to installing a replacement module, verify that all connector pins are parallel and straight.
  • Page 84 Released Manual 35219V1 MicroNet XT Control bottom module brackets in the chassis card guides and pushing the module straight in until it is approximately 25 mm (1 inch) from the backplane. Do not make contact with the chassis backplane mating connectors.

  • Page 85: Chapter 9. Product Support And Service Options

    • An Authorized Independent Service Facility (AISF) provides authorized service that includes repairs, repair parts, and warranty service on Woodward's behalf. Service (not new unit sales) is an AISF's primary mission. A current list of Woodward Business Partners is available at https://www.woodward.com/en/support/industrial/service-and-spare-parts/find-a-local-partner...

  • Page 86: Returning Equipment For Repair

    • The unit serial number, which is also on the nameplate 9.5. Engineering Services Woodward offers various Engineering Services for our products. For these services, you can contact us by telephone, by email, or through the Woodward website. • Technical Support •...

  • Page 87: Contacting Woodward's Support Organization

    Woodward’s worldwide locations, depending upon the product and application. This service can assist you with technical questions or problem solving during the normal business hours of the Woodward location you contact. Emergency assistance is also available during non-business hours by phoning Woodward and stating the urgency of your problem.

  • Page 88: Technical Assistance

    MicroNet XT Control 9.7. Technical Assistance If you need to contact technical assistance, you will need to provide the following information. Please write it down here before contacting the Engine OEM, the Packager, a Woodward Business Partner, or the Woodward factory: General...

  • Page 89: Appendix A. Environmental Specifications

    18–24 months. Humidity Woodward H2 - 5 cycles 25–60 °C at 95% RH non-condensing (one cycle per day), powered on for the purpose of non-condensing Vibration RV5 Random Vibration limits of (control room): 1.04 Grms (10-500 Hz), 2...

  • Page 90: Appendix B. Micronet Xt Hardware And Software Compatibility

    Released Manual 35219V1 MicroNet XT Control Appendix B. MicroNet XT Hardware and Software Compatibility • Upgrading from one control platform to another typically requires hardware or CPU changes and a coder conversion. • During upgrades, it is always recommended to verify that the...
  • Page 91 Released Manual 35219V1 MicroNet XT Control Appendix Table B-3. Module Compatibility Matrix Simplex Notes Module Compatibility Main Chassis ⚫ 14 slot Chassis (5453-1219) Power Supplies ⚫ XT Power Supply Low Voltage (5466-1320) CPU Modules ⚫ XT Control CPU (5466-1300) I/O Modules ⚫...

  • Page 92: Appendix C. Acronyms

    Discrete Output DPDT Double Pole/Double Throw DRAM Dynamic Random Access Memory Digital Signal Processor Electronic Industry Alliance Woodward Actuation Family (Electric Motor) EM-35 Woodward Actuation Model (Electric Motor) Electromagnetic Compatibility Electromagnetic Interference Europäische norm (European Norm) Electrostatic Discharge European Union...
  • Page 93 Released Manual 35219V1 MicroNet XT Control Force of Gravity Woodward Graphical Application Program(mer) Ground Woodward Gas Valve Family Human Machine Interface Hertz (cycles per second) High Density High Voltage HVAC High Voltage Alternating Current International Electro technical Commission IEEE Institute of Electronic & Electrical Engineers...
  • Page 94 Secure Socket Tunneling Protocol Shielded Twisted Pair SYSCON System Controller Thermocouple TCP/IP Transmission Control Protocol/Internet Protocol Total Harmonic Distortion Woodward Actuator Family (Torque Motor) TM100 Woodward Actuator Model (Torque Motor) Triple Modular Redundant Transmit Universal Serial Bus UART Universal Asynchronous Receive/Transmit...

  • Page 95: Revision History

    Released Manual 35219V1 MicroNet XT Control Revision History Rev- • New manual Woodward...

  • Page 96: Declarations

    Released Manual 35219V1 MicroNet XT Control Declarations Woodward...
  • Page 97 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.
