Post-Installation Tasks
# enclosure show summary
Enclosure Model No.
-------- ---------
1 DD9500
2 ES30
3 ES30
4 ES30
5 ES30
-------- ---------
5 enclosures present.
Data Domain ES30 Expansion Shelf and FS15 SSD Shelf Hardware Guide
124
6a SAS
6b SAS
6c SAS
6d SAS
9a SAS
9b SAS
9c SAS
9d SAS
---- ----------
The output shows:
The online status for each SAS connection, such as 2a, 3a, 6a
l
The offline status for each SAS connection, such as 2b, 3b, 6b
l
After the shelves have been connected, the same command also displays the
l
connected enclosure IDs for each port. The status changes to online.
2. After adding any enclosure/shelf, enter the disk show state command to
verify the disk state.
# disk show state
Enclosure Disk
1
--------- ----------------------------------------------
1 .
2 U
3 s
4 U
5 A
--------- ----------------------------------------------
Legend State
------ ----------------------------
. In Use Disks
s Spare Disks
R Spare (reconstructing) Disks
v Available Disks
K Known Disks
U Unknown Disks
F Failed Disks
A Absent Disks
------ ----------------------------
Total 64 disks
Note
Run the storage add command to add disks in the U state to the Data
Domain system.
3. Verify that the Data Domain system recognizes each attached enclosure/shelf
by entering the enclosure show summary command:
Serial No. State
-------------- ------ ------
NVT10133200020 Online
APM00133825711 Online
APM00120900626 Online
APM00123706119 Online
APM00133825239 Online
-------------- ------ ------ -------
