DD880 systems
DD990 systems
Figure 74 DD660/DD690 rear panel
Note
DD OS 5.7 and later releases do not support the DD880 systems.
DD880 systems have either two or three dual-port SAS cards installed. The ports are
1a, 1b; 2a, 2b; and 3a, 3b. See the table and associated information in
rules and guidelines
on page 21 for configuration information.
SAS HBA ports
Figure 75 DD880 rear panel
DD990 systems have three dual-port SAS cards installed (in slots 4, 5, or 9) and
Extended Retention Systems for the DD990 have four dual-port SAS cards installed
(in slots 4, 5, 8, or 9) .
There are 11 HBA/PCI cards that are numbered 1-11 from right to left. On each card,
the topmost port is "a", for example eth2a.
Data Domain-Specific Installation
Shelf cabling
DD880 systems
