MicroCal VP-ITC User Manual page 30

VP-ITC MicroCalorimeter User's Manual
Save Run File. Displays the file save dialog box which allows saving of the currently displayed
run parameters. By saving the run parameters to a setup file (*.inj) they may be reloaded and
reused in the future by selecting Load Run File as described above
Display Run Parameters. Displays the current run parameters for the run in progress. This
button is available only when the VP-ITC is in a non-idle state.
Update Run Parameters. Updates the current run parameters for the run in progress. When the
ITC is in a non-idle state, this button must be clicked to realize the change of any run
parameters. This button is available only when the VP-ITC is in a non-idle state.
Note: Only run parameters that have not yet been applied on the run in progress may be
updated, all others will be ignored (e.g. after the stirring has commenced for an experiment,
changes to the experimental stir speed will be ignored.
Start. Click this button to start an ITC experiment, using the parameters entered into the ITC
Controls Window.
Stop. This button terminates the current run. Available only when the VP-ITC is in a non-idle
state.
Compact/Standard Mode Button
Clicking this button will shrink VPViewer's Main Window and change
the icon to the Compact Mode (as shown below). VPViewer's Main
Window size cannot be manually adjusted. It has only 2 sizes, the
compact mode size and the standard size. Clicking on the Standard Mode button will restore the
window to its original size.
20
