- Page 1 Doc. no. AS*-OMX0006 PRODUCT NAME SPEED CONTROLLER WITH ONE-TOUCH FITTING PUSH-LOCK TYPE / JAS SERIES MODEL/ Series/ Product Number JAS-L***-**...
-
Page 2: Table Of Contents
Contents 2 ～ 3 1．Safety Instructions 4 ～ 8 2．Specific Product Precautions 3．Application 4．Specifications 5．Malfunctions and Countermeasures 6．Construction... -
Page 3: Safety Instructions
Speed Controller with One-touch Fitting Push-Lock Type / JAS Series Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Safety Instructions
Speed Controller with One-touch Fitting Push-Lock Type / JAS Series Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. -
Page 5: Specific Product Precautions
Design/ Selection 2. Specific Product Precautions Design/ Selection Warning (6)Check if PTFE can be used in application. Warning PTFE powder (Polytetrafluoroethylene resin) is included in the seal material of the male thread (1)Confirm the specifications. type piping taper thread. Confirm that the use of Do not operate at pressures, temperatures, etc., it will not cause any adverse effect on the system. - Page 6 Mounting Mounting Warning Warning (6)Check the degree of rotation of the needle (12) Insert the hexagon wrench into the end of valve. the hexagonal hole of the stud when The Products in this catalog are retainer type so removing and mounting the speed that the needle is not removed completely.
- Page 7 Mounting Piping Threads with Sealant Caution Caution For M5,10-32UNF (1)If the fitting is tightened with excessive First, tighten it by hand, then give it an additional torque, a large amount of sealant will seep 1/6 turn to 1/4 turn with a hexagon wrench. out.
- Page 8 Precautions for One-Touch Tube Fittings Recommended Piping Conditions Mounting/ Piping (1)When connecting piping to the One-touch fitting, use a pipe length Caution with sufficient margin, in (1)Connection and disconnection of tube from accordance with the piping one-touch fitting conditions shown in Figure 1. ①...
- Page 9 Maintenance Air Supply Warning Warning (1)Perform maintenance inspection (4)Use clean air according to the procedures indicated in the Do not use compressed air that contains operation manual. chemicals, synthetic oils that include organic If handled improperly, malfunction or damage of solvents, salt, corrosive gases, etc., as it can machinery and equipment may occur.
-
Page 10: 3．Application
3. Application This product is designed to control the speed of a pneumatic actuator. 4.Specifications Fluid Proof pressure 1.05 MPa Maximum operating pressure 0.7 MPa Minimum operating pressure 0.05 MPa Ambient and fluid temperature -5 to 60 C (No freezing) (note 1) Applicable tube materials Nylon, soft nylon, polyurethane, FEP, PFA... -
Page 11: 6．Construction
6.Construction ⑮ Meter-in ⑯ Component Parts Description Material Note Body A Body B Needle Knob Stopper Stainless steel Needle guide Brass Electroless nickel plated Disk seal HNBR Stud Brass Electroless nickel plated O-ring O-ring O-ring Cassette Seal O-ring Only Meter-in Gasket NBR/Stainless steel Seal... - Page 12 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2019 SMC Corporation All Rights Reserved...
