L I
AYOUT DENTIFICATION
W
IRING
Please be careful when connecting the four cable wires. Improper wiring will damage the
internal circuitry.
P
Microprocessor-Controlled Electro-Pneumatic Regulator
E A S Y P R O G R A M M I N G G U I D E
# W C
IN IRE OLOR
1 Brown
2 White
3 Blue
4 Black
D
ESCRIPTION
Supply Voltage
Input Signal
Ground
Monitor Output
.
