For example, you can remotely start and stop recording and playback of your HyperDeck as
well as performing other common jog and shuttle functions. The full list of supported RS-422
commands is in the following section named 'supported RS-422 commands'.
5 4 3 2 1
9 8 7 6
RS-422 remote pin connections
Remote port on HyperDeck Extreme 8K HDR
Supported RS-422 Commands
Command
0 - System Control
0x00 0x11 DeviceTypeRequest
1 - Slave Response
0x20 0x00 Stop
0x20 0x01 Play
0x20 0x02 Record
0x20 0x04 StandbyOff
0x20 0x05 StandbyOn
0x20 0x0F Eject
0x20 0x10 FastFwd
0x21 0x11 JogFwd1
0x22 0x11 JogFwd2
Receive Receive
(–) (+)
2 7
Reply
NTSC: 0xF0E0
PAL: 0xF1E0
24P: 0xF2E0
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Acknowledge
Transmit Transmit
(–) (+)
8 3
No Remote Notes
Enabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Treated as N=1;
Disabled
Same as JogFwd1
RS-422 Control
Ground
Pins
1, 4, 6, 9
