TDE MACNO DVS200 User Manual page 82

Freq
Freq sel 1
Freq sel 3
FWD(RUN) or
REV
Code Name
F.100 Frequency ref 0
F.101 Frequency ref 1
F.102 Frequency ref 2
F.103 Frequency ref 3
F.104 Frequency ref 4
F.105 Frequency ref 5
F.106 Frequency ref 6
F.107 Frequency ref 7
Code LCD display
F.116 Jog frequency
Code Name
F.200 Ramp resolution
82 • Chapter 7 - Parameters Description
Selectable through
"MltFreq Channel 1" (F.060)
"MltFreq Channel 2" (F.061)
Freq ref 2
Freq ref 1
Freq ref 0
Freq sel 2
Figure 7.5.3: Multispeed Frequencies
[Code] & Function.
[Code] & LCD select.
[Code] & Function.
[0] 0.01s (From 0.01s to 99.99s)
[1] 0.1s From (0.1s to 999.99s)
[2] 1s From (1s to 9999s)
Freq ref 3
Freq ref 4
Freq ref 4
Default MIN
0 -F.020
0 -F.020
0 -F.020
0 -F.020
0 -F.020
0 -F.020
0 -F.020
0 -F.020
Max ref freq (F.020)
Default MIN
1 -500
Default MIN
1 0
Freq ref 6
Freq ref 7
t
MAX Unit Variation
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
F.020 Hz 0.1
MAX Unit Variation
500 Hz 0.1
MAX Unit Variation
2
User Manual
IPA
311
312
313
314
315
316
317
318
IPA
327
IPA
328
