Menu H - Hidden; Virtual I/O Commands - TDE MACNO DVS200 User Manual

Bit 1 = 1
Bit 2 = 2
Bit 3 = 4
Bit 4 = 8
Bit 5 = 16
Bit 6 = 32
Bit 7 = 64
Bit 8 = 128
The setting of the bits at “0”, will mean the disabling of the respective function.
Bit 1 = 1 Virtual function digital output 1 Enabled
Bit 2 = 2 Virtual function digital output 2 Enabled
Bit 3 = 4 Virtual function digital output 3 Enabled
Bit 4 = 8 Virtual function digital output 4 Enabled
Code Name
H.000
H.010
122 • Chapter 7 - Parameters Description
Virtual command 1 Enabled
Virtual command 2 Enabled
Virtual command 3 Enabled
Virtual command 4 Enabled
Virtual command 5 Enabled
Virtual command 6 Enabled
Virtual command 7 Enabled
Virtual command 8 Enabled
[Code] & Function. Default MIN MAX
0 0 255
0 0 255
I.000…I.007
Unit Variation IPA
1000
1002
User Manual
