5.3. The control section

5.3.1. The A313-XX control card

LED
D1
D2
D3
Connector
A 3 1 3 X X
C1
C2
C3
C4
S1
Jumper
J5
J7
User Manual
Figure 5.3.1.1: The A313-XX control card
S1
Table 5.3.1.1: LEDs, jumpers and connectors on the A313-XX
Colour
yellow Lit = drive power
Flashing = parameters changed but not saved
Off = attempting to change unmodifiable parameter in Run
green Lit = Run command enabled and active
red Lit = drive in alarm state
PIN N°
6 Programming key connector
6 Keypad connector
7 Control terminals
3 Serial line terminals
4 Slot for optional serial line
Default
0 Transforms analog voltage input into current input
0 Links control card 0V to ground
J5 - J7
Function
Function
Function
